- Page 1 PRIVILEGE SERIES D/A CONVERTER User manual 1/16...
-
Page 2: Table Of Contents
Table of Contents Introduction............................3 Contact.............................3 Document overview.........................3 FRONT PANEL...........................5 REAR PANEL............................6 CONNECTIONS..........................7 DISPLAY AND MENU STRUCTURE....................8 QUICK GUIDE..........................8 1. START UP DISPLAY.........................9 2. MAIN SCREEN .........................9 3. STANDBY MODE........................10 4. INPUT NAME SETTING......................10 5. PHASE SELECTION........................11 6. LOCK STATUS........................12 7. RING LEDS..........................12 8. -
Page 3: Introduction
ORPHEUS MEDIA SARL Avenue des Sciences 3 1400 Yverdon-les-Bains Phone : +41 24 423 9088 Fax : +41 24 424 9089 E-mail: info@orpheuslab.com Web: www.orpheuslab.com Document overview This document is the user manual for the Orpheus Media Privilege series D/A Converter. 3/16... - Page 4 UNPACKING First check and identify the contents of your preamplifier package, as listed below: ● D/A Converter ● CD User manual Read this before operating your unit ● Please read this manual carefully, to assure proper operation and the possible performance. ●...
-
Page 5: Front Panel
INFRARED REMOTE CONTROL SENSOR Receives signals from the remote control transmitter. Compatible with all Orpheus remontes controls transmitter. DISPLAY Displays the input selection, as well as the setup menus. POWER Lights red when the unit is in standby mode. -
Page 6: Rear Panel
REAR PANEL OUTPUTS Analogue balanced right and left channel outputs on XLR connectors. Unbalanced right and left channel outputs on RCA connectors. INPUT TOSLINK FORMAT ➁ Digital data stream input using an optical connector for TOSLINK format. INPUT BNC FORMAT ➂... -
Page 7: Connections
CONNECTIONS Digital data stream inputs from CD drive / Balanced analogue stereo output to preamp player or other source with digital output. or integrated amp. Unbalanced analogue stereo output to preamp or integrated amp. R : right channel L : left channel A : AES/EBU S : S/PDIF B : BNC... -
Page 8: Display And Menu Structure
DISPLAY AND MENU STRUCTURE SETUP AND OPERATIONS QUICK GUIDE POWER ON Flip the main power switch on the lefthand side of the rear panel from 0 to 1. MAIN SCREEN After switching on the unit, the display windows shows the start up screen shortly. It then switches to the default screen which shows input selection for listening. -
Page 9: Start Up Display
1. START UP DISPLAY REFERENCE SERIES DA CONVERTER The start up display is shown approximatively 3 seconds when main power is switched on. It is then replaced by the main screen. 2. MAIN SCREEN Input selected SPDIF 1 Input selected The main screen is the default display during normal operation. -
Page 10: Standby Mode
SETUP MENU From main screen press on the button to enter setup menu. To choose between the setup menu options turn to right or left with the button until the desired option is displayed. 3. STANDBY MODE SETUP> STANDBY Pressing on the button the unit in to standby mode. Pressing any navigation button resumes normal operations. -
Page 11: Phase Selection
RENAMING Each input can have any individually defined name. The name can be a word with a combination of up 10 letters or numbers. MOVING CURSOR SETUP>NAME>SPDIF1> SPDIF 1 Turn to right or left to switch from one position to the other. Press on the button to select the position to change the character. -
Page 12: Lock Status
6. LOCK STATUS SETUP> LOCK STATUS To enter LOCK STATUS mode press on the button. This function gives the possibility to enable or disable the Upsampling details (lock status) . When this function is enable, the upsampling detail is show at every changement of status. To select an input turn to left or right until the chosen lock status is displayed. -
Page 13: Night Mode
9. NIGHT MODE SETUP> NIGHTMODE To enter night mode press on the button. When night mode is in position ON the display turns off automatically approx. 3 seconds after pressing any control button. The unit is still operation and the display lighting is reactivated by pressing any control button. To set night mode turn to right or left until the chosen mode is displayed. -
Page 14: Specifications
SPECIFICATIONS D/A Converter is a 2 channel 24/384kHz upsampler and digital to analogue conversion unit. D/A Converter features software based Q5™ sample rate conversion technology. Each incoming data stream is converted into a high definition 24bit/384kHz signal prior to being converted to the analogue domain. - Page 15 Media sàrl. IMPORTANT NOTICE ORPHEUS Media sàrl reserve the right to make changes to their products or discontinue any product or service without notice. Adequate operating safeguards must be used to minimize hazards. Reproduction of user manual information is permissible only if it is without alteration and is accompanied by all relevant conditions, limitations and notices.
- Page 16 LIMITED WARRANTY CERTIFICATE ORPHEUS Media guarantees that the product described below is free of defective material and workmanship. The warranty extends for a period of one year form original purchase date, but at maximum two years form manufacturing date. ORPHEUS Media agrees to repair or replace defective parts or the complete unit at its option, provided that the equipment is returned exclusively to the original dealer.
