  • Page 1: Service Manual

    FS-3040MFP FS-3140MFP SERVICE MANUAL Published in July 2010 842LX111 2LXSM061 Rev.1...

  • Page 2: Maintenance Mode

    2LW/2LX CONTENTS 1-1 Specifications 1-1-1 Specifications ........................1-1-1 1-1-2 Parts names .......................... 1-1-5 (1) Overall ..........................1-1-5 (2) Operation panel ........................ 1-1-6 1-1-3 Machine cross section ......................1-1-7 1-2 Installation 1-2-1 Installation environment......................1-2-1 1-2-2 Unpacking..........................1-2-2 (1) Unpacking......................... 1-2-2 (2) Removing the tapes......................1-2-3 1-2-3 Installing the expansion memory (option) ................

  • Page 3: Assembly And Disassembly

    (1) Precautions........................1-5-1 (2) Drum..........................1-5-1 (3) Toner ..........................1-5-1 (4) How to tell a genuine Kyocera Mita toner container ............1-5-2 1-5-2 Outer covers .......................... 1-5-3 (1) Detaching and refitting the right cover and left cover ............1-5-3 1-5-3 Paper feed section......................... 1-5-6 (1) Detaching and refitting the paper feed assembly (paper feed roller and pickup roller) ..
  • Page 4 2LW/2LX 1-5-11 Document processor ......................1-5-47 (1) Detaching and refitting the DP rear cover and DP front cover ........1-5-47 (2) Detaching and refitting the DP drive PWB..............1-5-48 (3) Detaching and refitting the DP forwarding pulley assembly and DP separation pad assembly................... 1-5-49 1-6 Requirements on PWB Replacement 1-6-1 Upgrading the firmware ......................
  • Page 5 2LW/2LX 2-4 Appendixes 2-4-1 Appendixes ..........................2-4-1 (1) Wiring diagram ......................... 2-4-1 (2) Repetitive defects gauge ....................2-4-3 (3) Maintenance kits....................... 2-4-4 (4) Firmware Environment Commands .................. 2-4-5...

  • Page 6: Specifications

    2LW/2LX-1 1-1-1 Specifications Basic functions Item Specifications Type Desktop Printing method Electrophotography by semiconductor laser, single drum system Originals Sheet, Book, 3-dimensional objects (maximum original size: Folio/Legal) Original feed system Contact glass: fixed Paper weight Cassette 60 to 120 g/m (Duplex: 60 to 120 g/m MP tray 60 to 220 g/m...
  • Page 7 2LW/2LX-1 Item Specifications Photoconductor a-Si drum (diameter 30 mm) Image write system Semiconductor laser (1 beam) Charging system Contact charger roller method (positive charging) Developing system Mono component dry developing method Toner replenishing: Automatic from the toner container Transfer system Transfer roller (negative-charged) Separation system Small diameter separation, discharger brush (negative-charged)
  • Page 8 2LW/2LX Document processor functions Item Specifications Original feed method Automatic feed Supported original types Sheet originals Original sizes Maximum: Legal/A4 Minimum: Statement/A5 Original weights Simplex: 50 to 120 g/m Duplex: 50 to 110 g/m Loading capacity 50 sheets (50 to 80 g/m ) maximum Dimensions 490 (W) ×...
  • Page 9 2LW/2LX Item Specifications 1-sided: Scanning speed B/W 35 images/min Color 13 images/min (A4 landscape, 600 dpi, Image quality: Text/Photo original) Ethernet (10 BASE-T/100 BASE-TX) Interface USB2.0 (Hi-Speed USB) Network protocol TCP/IP PC transmission Transmission system SMB Scan to SMB FTP Scan to FTP, FTP over SSL E-mail transmission SNMP Scan to E-mail TWAIN scan...

  • Page 10: Parts Names

    2LW/2LX 1-1-2 Parts names (1) Overall Figure 1-1-1 1. Platen (contact glass) 12. Paper width guides 23. Tel connector (T1) * 2. Original size Indicator plate 13. Cassette 24. DP top cover 3. Operation panel 14. Paper width guides (MP tray) 25.

  • Page 11: Parts List

    FS-3040MFP+ FS-3140MFP+ PARTS LIST Published in April 2011 2MFPL070 First Edition...
  • Page 12 CONTENTS FIG. 1 Covers ..............2 FIG. 16 Electrical Components ..........32 FIG. 2 Frames 1 ..............4 FIG. 17 Operation Section ...........34 FIG. 3 Frames 2 ..............6 FIG. 18 Document Processor 1 ...........36 FIG. 4 Paper Cassette ............8 FIG.
  • Page 13 FIG. 1 Covers 2MF/2MG...
