X‐PIN & X‐PROX
Install Guide
The  X‐PIN  is a  single  door  controller  which  uses  PIN  only.  The  X‐PROX  is  a single
door controller that uses PIN and proximity technology. All electronics are within
the housing of the reader. The X‐PIN and X‐PROX can be connected to a door con‐
tact and request to exit button to allow the system to send a signal to a sounder in
case the door has been forced or left open.


VDC
Input Voltage
VAC
Maximum
Heater On
Input Current
Heater Off
(12vDC)
Standby In‐
Heater On
put Current
Heater Off
(12vDC)
Maximum Relay Current
REX Input
Aux Input
Max Proximity Read
Range
Proximity Card Compati‐
bility
LED Indicators
Operating Temperatures
Outdoor Usage
Dimensions
Weight
X‐PIN
12vDC‐24vDC
12vDC‐24vDC
12vDC‐24vAC
16vDC‐24vAC
130mA
610mA
70mA
550mA
2A
Normally Open
Normally Open
Normally Open
Normally Open
N/A
SP‐SHL, SP‐ISO,
N/A
SP‐KEY, SP‐DISC
Two 3 Coloured
Two 3 Coloured
LED
‐20°C to 60°C
‐20°C to 60°C
Meets IP64
Meets IP64
120mm (H) x 76mm (W) x 22mm (D)
521g
www.sensoraccess.co.uk
X‐PROX
145mA
625mA
85mA
365mA
2A
65mm
LED


Advertisement

loading
Need help?

Need help?

Do you have a question about the X-PIN and is the answer not in the manual?

Questions and answers

Summary of Contents for Sensor Access X-PIN

  • Page 1 X‐PIN & X‐PROX  Install Guide  The  X‐PIN  is a  single  door  controller  which  uses  PIN  only.  The  X‐PROX  is  a single  door controller that uses PIN and proximity technology. All electronics are within  the housing of the reader. The X‐PIN and X‐PROX can be connected to a door con‐ tact and request to exit button to allow the system to send a signal to a sounder in  case the door has been forced or left open.      X‐PIN  X‐PROX  VDC  12vDC‐24vDC  12vDC‐24vDC  Input Voltage  VAC  12vDC‐24vAC  16vDC‐24vAC  Maximum  Heater On  130mA  145mA  Input Current  Heater Off  610mA  625mA  (12vDC)  Standby In‐...
  • Page 2 X‐PIN & X‐PROX  Install Guide  Colour  Description  Red  V Input  Black  Ground  Green  REX/BL  White  In/Monitor  Purple  Lock : Com  Grey  Lock : N.O.  Brown  Lock : N.C.  Blue  Aux : Com  Yellow  Aux : N.O.  Orange  Aux : N.C.  MODES OF OPERATION    Normal Mode (Default)   • Mode indicator is green.   In normal mode, the door is locked until a valid primary code is presented to the controller. The controller can  only be programmed in normal mode.   Secure Mode   • Mode indicator is red.   Only secure and master users can access the premises in secure mode.   USER LEVELS    The X‐PIN & X‐PROX Access Control units accept up to 500 users and provide entry via the use of codes or cards.   Normal User ‐ A normal user only has a primary code and is granted access only when the controller is in its nor‐ mal or bypass mode  Secure User ‐ A secure user must have a primary and secondary code assigned, and the two codes must not be  the same. (please see User Manual for more information) www.sensoraccess.co.uk ...
  • Page 3 X‐PIN & X‐PROX  Install Guide  SWITCHING OPERATONAL MODES    From Normal to Secure Mode / From Secure Mode to Normal  The default factory setting for the normal / secure code is 3838    1) Enter the normal / secure code  • Mode indicator will flash red (normal to Secure) or flash Green (Secure  to Normal)    2) Depress the # key to confirm the Mode change  • Mode indicator is red to confirm in Secure mode/ or green to confirm  Normal Mode  STANDARD METHOD FOR ENROLLING    1) Enter the programming mode.    2) Depress 7 to enter Menu 7.  • The Door indicator will turn orange.     3) Enter the 3‐digit user slot number into the memory (from 001 to 500) so as to enroll  a primary or secondary code.  • For example, the user slot 003 represents user no. 3.     4) At this time three possibilities exist:  a.  If the selected slot has no primary code, the Mode indicator will flash green,     indicating that the controller is ready to accept a primary code.     b.  If the selected slot already has a primary code, but no secondary code, the Mode    indicator will flash red, indicating that the controller is ready to accept a second‐    ary code.    c.  ...
  • Page 4 X‐PIN & X‐PROX  Install Guide  DELETING CODES  When deleting a user slot, both the primary code and the secondary code are erased.    1) Enter the programming mode.    2) Depress 8 to enter Menu 8.  • The Mode indicator will turn red.     3) Enter the 3‐digit user slot code to be deleted.    • The Mode indicator will flash red, indicating the controller is waiting for a programming code  to confirm the deletion.  If the user slot is empty, a long beep will be heard and the controller will return to its  normal mode.     4) Enter your programming code to confirm the deletion. If the programming code is valid, three beeps will be  heard  and the controller will return to its normal mode.  If the programming code is invalid, a long beep will be heard and the controller will return to its normal mode.  For the full User Manual please go to:  public.sensoraccess.co.uk  Sensor Access Technology Ltd  Sensor House  10‐11 Lewes Road  Brighton  East Sussex  BN2 4JZ  Tel: 01273 242 355  Fax: 01273 235 030  support@sensoraccess.co.uk   www.sensoraccess.co.uk ...
