- Page 1 Console MVD DC Service manual CL23420 to CL23423 English www.mundoclima.com...
-
Page 2: Table Of Contents
Service manual MVD DC Indoor units Content 1. Features ..............2 2. Specifications ............4 3. Dimensions ..............5 4. Service Spaces ............6 5. Piping Diagrams ............7 6. Wiring Diagrams ............8 7. Capacity Tables ............9 8. Electrical Characteristics ......... 13 9. -
Page 3: Features
Service manual MVD DC Indoor units 1. Features Console type Compact unit body, space saving, nice-looking appearance 1.2.1. this unit body is very thin and harmonious with room. It is elegant and space saving. 1.2.2. The EXV is fixed inside of the indoor unit, Compact unit body. Flexible installation. - Page 4 Service manual MVD DC Indoor units Air outlet from 2 optional directions: Quick cooling mode: air supplying from both top and bottom Normal cooling mode: from top only Normal heating mode: air supplying from both top and bottom Anti-cold fan mode: from top only Air inlet from 4 directions: Bottom, Top, and right/left side, for better ventilation.
-
Page 5: Specifications
Service manual MVD DC Indoor units 2. Specifications Model MVD-22Z/DHN1-B MVD-28Z/DHN1-B MVD-36Z/DHN1-B MVD-45Z/DHN1-B Power supply V- Ph-Hz 220-240V~, 1Ph, 50Hz Capacity Cooling Input Rated current 0.09 0.11 0.11 0.20 Capacity Heating Input Rated current 0.09 0.11 0.11 0.20 Model RD-280-20-8A RD-280-20-8A RD-280-20-8A RD-280-20-8A... -
Page 6: Dimensions
Service manual MVD DC Indoor units 3. Dimensions 700mm 210mm Main dimension: Outer Length: 700mm, Height: 600mm, Depth: 210mm Filter length: 550mm Gas tube: 12.7mm Ф Liquid tube: 6.35mm Ф... -
Page 7: Service Spaces
Service manual MVD DC Indoor units 4. Service Spaces There is enough room for installation and maintenance. The outlet and the inlet are not impeded, and the influence of external air is the least. The air flow can reach throughout the room. The connecting pipe and drainpipe could be extracted out easily. -
Page 8: Piping Diagrams
Service manual MVD DC Indoor units 5. Piping Diagrams motor flare nut gas side heat exchanger flare nut liquid side... -
Page 9: Wiring Diagrams
Service manual MVD DC Indoor units 6. Wiring Diagrams... -
Page 10: Capacity Tables
Service manual MVD DC Indoor units 7. Capacity Tables 7.1 Cooling TC: total capacity SC: sensible capacity WB: wet-bulb temperature DB: dry-bulb temperature ℃ Indoor temperature ( /DB) Indoor Outdoor 14/20 16/23 18/26 19/27 20/28 22/30 24/32 Unit size temperature ℃... - Page 11 Service manual MVD DC Indoor units 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0 37.0 39.0 42.0 44.0 46.0...
- Page 12 Service manual MVD DC Indoor units 7.2 Heating TC: total capacity WB: wet-bulb temperature DB: dry-bulb temperature Indoor temperature (℃ DB) Outdoor temperature 16.00 18.00 20.00 21.00 22.00 24.00 Indoor Unit size ℃ (kW) -19.8 1.46 1.46 1.46 1.46 1.46 1.46 -18.8 1.56...
- Page 13 Service manual MVD DC Indoor units -16.7 3.15 3.15 3.15 3.15 3.15 3.15 -14.7 3.25 3.25 3.25 3.25 3.25 3.25 -13.00 -12.60 3.35 3.35 3.35 3.35 3.35 3.35 -11.00 -10.50 3.50 3.50 3.50 3.50 3.50 3.50 -10.00 -9.50 3.65 3.65 3.65 3.65 3.65...
-
Page 14: Electrical Characteristics
Service manual MVD DC Indoor units 8. Electrical Characteristics Indoor Unit Power Supply Model Voltage Min. Max. MVD-22Z/DHN1-B 220-240 0.25 0.012 0.0135 MVD-28Z/DHN1-B 220-240 0.25 0.015 0.0158 MVD-36Z/DHN1-B 220-240 0.25 0.015 0.0158 220-240 0.25 0.030 0.0296 MVD-45Z/DHN1-B Remark: MCA: Min. Current Amps. (A) MFA: Max. -
Page 15: Sound Levels
Service manual MVD DC Indoor units 9. Sound Levels 9.1 Test condition Note: 1, During actual operation, these values are normally somewhat higher as a result of ambient conditions. 2, Semi-anechoic chamber conversion value, measured at a point which is 1m in front of the unit and 1.5m under the unit. 9.2 Test value Model MVD-22Z/DHN1-B... -
Page 16: Accessories
Service manual MVD DC Indoor units 10. Accessories 10.1 Standard accessories Name Quantity Shape Usage Owner’s manual Installation manual Pipe insulation material Heat insulation Flexible hose tube For drain water pipe connection Hook Fittings for installing the indoor unit Mounting screw(ST3.9x12-C-H) Remote controller Control the indoor units Remote controller holder... - Page 17 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 81 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
