P645QUADO
User's instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
www.lightemotion.com.au
Advertisement
Related Manuals for Light Emotion P645QUADO
Summary of Contents for Light Emotion P645QUADO
- Page 1 WWW.LIGHTEMOTION.COM.AU P645QUADO User’s instruction manual This manual contains important information about the safe installation and use of this product Please read this instruction manual carefully before installing or operating Please keep these instructions in a safe place for future reference...
-
Page 2: What Is Included
Congratulations on the purchase of your P645QAUDO by Light Emotion. We are confident that you will be satisfied with your purchase. We have prepared this manual to assist you with the care and operation of this item. This product uses 15 4in1 5W LEDs to produce vivid colours that the user can control in many ways. -
Page 3: Installation
• Always make sure that you are connecting to the proper voltage and that the line voltage you are connecting to is not higher than that stated on the rear panel of the fixture. • This is an IP65 rated outdoor fixture. To prevent damage to the waterproof seal, do not pull the product apart yourself. -
Page 4: Dmx Terminator
MAINTENANCE & PERIODIC CHECKS: CAUTION: Some maintenance and checks may require the product to be opened and should only be done by qualified persons. Warranty may be void if damage has been caused by improper maintenance Perspex lenses should be wiped with a clean moist cloth to remove dust and residue. - Page 5 Black Out mode: Press “BLACK OUT” to turn the LED lights on/off. Select program Mode: Use PROG button to select auto run mode / built in programs mode. LEDs will indicate you current mode. When red LEDs are on after you press PROG, unit is in built in programs mode.
- Page 6 1) Set DMX mode: Press the DMX mode button, then RGBW LEDs will flash 2-3 times then press the “+” or “-” buttons to select different DMX address. You also can press SET ADDR to set up DMX address. 2) Set DMX address: Press SET ADDR, then use number button to set DMX address.
-
Page 7: Specification
SPECIFICATION: Weight: 6.2kg • Size: 28.5 × × 3 1.5cm • Power input: AC100V-240V/50HZ-60HZ • Wattage: 95W • LEDS: 15PCS 5W (4 in one) • Beam angle of LEDs: 40 degree • 3PIN female and male XLR socket,4PIN female and male power socket •...
