TROUBLESHOOTING
Symptom
Problem
No playable file on iPod
Your iPod is not charging
No Sound
After quickly undocking
or docking your iPod
iPod does not dock
properly
Volume level too high
Sound distortion
Sound source is distorted
System is not
Malfunction
Responding
7
Solution
- Make sure your iPod is on, and a track is
selected for playback.
- Make sure the power cable is securely plugged
in to a functioning wall socket. The symbol on
the small connector is matched with that on rear
panel of the GSPK29iP . (Refer to Figure 4 on
page 4.)
- Make sure your iPod is firmly seated in the dock.
- Remove your iPod from the dock, wait for 5
seconds, and return it to the dock.
- Unplug the power cable for 1 minute, then plug
it back to reset the system.
- Remove your iPod from the dock, wait briefly,
then reset it. You may need to do this for
few times.
- Decrease volume level by pressing on front
panel or on remote control.
- Distortion and noise are easily noticed with
high-powered speakers when playing poor
quality audio source, esp. WAV and MID files.
Try a different audio source such as a music CD
or change better quality audio player.
- If the volume buttons on the top of the unit
work, then check the remote control battery.
To reset: unplug the power and remove
batteries, after 1 minute plug back in
- Please contact customer service .

SPECIFICATIONS

Audio power(THD=10%): 3W RMS X 2
Speaker Units: 2'' 2
Frequency range: 120Hz 20kHz
Rated Load Impedance: 4 (Max 7W)
Notes:
1) The specifications listed above are for reference only.
2) The technical specifications of this device are subject to changes
without prior notice.
8
Power Rating: 100-240V 50/60Hz
Product Dimension : 250 45 mm
Net Weight: 530g
