USING THE SYSTEM

Using the Remote Control

Mute
Menu Enter
Bass Treble
GSPK29IP
CR2025X1
Reset
OPEN
Play and Pause iPod.
Play/Pause
To go back to the previous menu.
Menu
Menu
To confirm the chosen menu item, or to confirm the
Enter
selected song/photo/video when iPod is used .
Bass +/-
Increase or decrease the bass level.
steps -10 to +10
Bass
Increase or decrease the treble level.
steps -10 to +10
Treble
Treble +/-
Increase or decrease the music volume when the audio
Volume
source is playing.
Up/Down
steps 0-30
Reset
Reset Reset's the bass and treble to 0
Play songs/album in a shuffled order, or to turn off the shuffle function.
Shuffle
Repeat Repeat one song, all songs in the album, or to turn off the repeat
function.
5
Power
Turn the audio source on/off.
on/off
Cuts the sound, press again to resume.
Mute
Press to skip press to go previous song;
press and hold to rewind through the
Previous current track.
Quick press to skip to next/previous track,
/Next
or hold to fast forward/rewind
during play back."
Press or hold to scroll though iPod menus
Menu Up
/Down
USING THE SYSTEM
Your iPod navigation controls are fully functional while it is docked in the system.
Your iPod volume jog wheel changes the headphone volume only. It has no effect on
the Sound Dock system.
To replace the remote control battery
Changing the remote control battery is the only regular maintenance that is
required. You may also clean the system as needed.
Replace the remote control battery when it stops operating (normally every year or two), or its range
seems reduced. Use only a Lithium Cell CR2025, Duracell, Eveready, Energizer, Maxell, Toshiba, or
Shun Wo Cr2032 3-volt lithium battery. Keep in mind that lighting and other room conditions, in
addition to battery age, can affect the operating range of an infrared remote control.
Figure 6: Inserting a new battery

TROUBLESHOOTING

In case of malfunction, please power off the system immediately and check the unit according
to following table. If the problem still exists, please contact the dealer.
Symptom Problem
iPod does not dock
properly
iPod / Audio source
is not responding
3.5mm headphone cable
isn't connected properly
Power cable is not
connected
Power isn't turned on
No Sound
Volume Level too low
6
Solution
- Please ensure proper insert is placed for your
iPod. (Refer to "Selecting the correct insert" on
page 3).)
- Unplug the iPod from the docking station to see
any obstructions in the connector or in your iPod.
- Connect 3.5mm headphone cable to the audio
source. Make sure the signal cable is inserted
firmly into the correct jack & is fully connected
in the "line-out", "audio-out", or the headphone
jack on your sound card or other audio source.
- Make sure the GSPK29iP is plugged in and the
LED is illuminated.
- Make sure the GSPK29iP is with battery and the
battery is working if GSPK29iP is not plugged in.
- Press the "Power" button, if there is no change
on the indicator of the iPod, please press the
"Power" button again.
- The volume level might be too low, press
"Volume" button on the panel to adjust.
