Page 1: User Manual
Mobile Thermal Transfer Printer User Manual MPT8/MPT8E Xiamen Hanin Electronic Technology Co.Ltd. ADD: Room 305A,Angye Building, Pioneering Park, Torch High-tech Zone, Xiamen, China 361009 Tel.： +86-(0)592-5885993 Fax: +86-(0)592-5885992 Web: www.hprt.com... - Page 2 2.Change the flash of memory;(P8) 2015.08.20 Lin Yun Yang Kaiqu Ren Xiaowei 3.Add the information of fonts and resolution of MPT8E.(P8) 2015.12.01 1.Modify the resolution of MPT8E.(P8) Lin Yun Yang Kaiqu Ren Xiaowei 1.Modify the layout of printer 2016.03.21 Lin Yun Yang Kaiqu Ren Xiaowei specification.
- Page 3 Copyright This manual is printed in 2016, the copyright belongs to Xiamen Hanin Electronic Technology Co. Ltd. Printed in China 1.9 Version...
-
Page 4: Table Of Contents
CONTENTS Manual Information.........................1 Important Safety Instructions......................2 Chapter 1 Introduction........................5 1.1 Packing List.........................5 1.2 Appearance and Component.....................6 Chapter 2 Specification........................8 Chapter 3 Installation & Usage...................... 10 3.1 Ribbon Loading........................ 10 3.2 Loading Media......................... 11 3.3 Removing Media......................11 3.4 Battery Charging...................... -
Page 5: Manual Information
MPT8/MPT8E User Manual MANUAL INFORMATION This user manual contains basic information for product usage as well as for emergency measures that may be required. ※ The following separate manuals provide more detailed content on various technological issues and areas. 1.Windows Driver Manual This manual provides information on the installation instructions and main functions of the Windows Driver. -
Page 6: Important Safety Instructions
MPT8/MPT8E User Manual IMPORTANT SAFETY INSTRUCTIONS In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. 1.Safety Precautions 1) Be sure to use the specified battery and power charger provided by our company,connection to an improper power charger may cause fire, explosion or damage to the printer. - Page 7 MPT8/MPT8E User Manual 4.Battery Safety Precautions 1) Ignore the following instructions may cause battery overheating, fire, explosion, damage and/or performance, and reduced product life. 2) Do not allow water, sea water from entering or leaking into the battery. If the batteries...
- Page 8 MPT8/MPT8E User Manual 5.Other Precautions The copyright for this user manual and various other manuals is property of the HPRT Corporation. Any copying or conversion into electronic firm and saving of this material without the express written permission of HPRT Corporation. is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability.
-
Page 9: Chapter 1 Introduction
MPT8/MPT8E User Manual CHAPTER 1 INTRODUCTION 1.1 Packing List Standard Accessories Printer Power Adapter Power Cord USB Cable Quick Start Guide Ribbon Note: the AC Adapter and Power Cord vary by local or region. Rev. 1.9 www.hprt.com... -
Page 10: Appearance And Component
MPT8/MPT8E User Manual 1.2 Appearance and Component Rev. 1.9 www.hprt.com... - Page 11 MPT8/MPT8E User Manual Touch Type Buttons 1）【Power】Button Function Description ① Power on function Long touch【POWER】button, printer will power on. ② Get into the menu mode function When printer is already powered on, long touch the【POWER】button to enter main menu.
-
Page 12: Chapter 2 Specification
MPT8/MPT8E User Manual CHAPTER 2 SPECIFICATION Table 2-1 General Specification (1/2) Type MPT8 MPT8E Item Parameter Thermal-transfer (standard), Direct thermal (optional) Print Method Resolution 203dpi (8dots/mm) 305dpi (12dots/mm) Printing Printing Width 198mm Parameter Print Speed Max.20mm/s Interface USB, Bluetooth Darkness... - Page 13 MPT8/MPT8E User Manual Table 2-1 (Continued) (2/2) Item Parameter Ribbons Max. Diameter ≤ф14.5mm Operating Condition 0℃～40℃，20%～85%RH Physical Storage Condition -20℃～60℃，5%～95%RH Specification Dimensions 310.5(L)×63(W)×38.5(H)mm Weight 797.5g(include ribbon) Accessories USB cable, serial cable Emulation ESC/POS Software Driver Windows XP/Vista/7/8/10 WinCE, Win Mobile, Android, iOS Rev.
-
Page 14: Chapter 3 Installation & Usage
MPT8/MPT8E User Manual CHAPTER 3 INSTALLATION & USAGE 3.1 Ribbon Loading 1. Press the left and right cover open buttons with both hands simultaneously and lift the printer cover. 2. Hold the left and right ribbon's handhold vanes,then insert the ribbon as shown and push the ribbon down until it clicks. -
Page 15: Loading Media
MPT8/MPT8E User Manual 4. Close the printer cover. 3.2 Loading Media 1. Make sure the ribbon is properly loaded and the cover of the printer is closed. 2. Turn the printer power on. Long touch power button for about 2 seconds. -
Page 16: Battery Charging
MPT8/MPT8E User Manual 1. Open the printer cover. 2. Pull the media out of printer in either direction. 3. Close the printer cover. 4. Insert a new sheet of media and print again. 3.4 Battery Charging Printer’s battery is rechargeable Li-polymer battery. Although printer use automatic sleep and automatically wake up technology to save power, please turn the power off after using it. -
Page 17: Peripheral Connection
MPT8/MPT8E User Manual onnect the power cord to the adapter. 1. C 2. Connect the adapter to the power connector of the printer. 3. Plug the power cord into a power outlet. NOTE: Battery charging status shown as follows: Display Screen... -
Page 18: Bluetooth Connection
Note: When pairing, do not set many printers on, otherwise it can't figure out which one succeeds in pairing. After pairing, main devices with virtual Bluetooth interface (SMARTPHONE, POCKET PC, PALM, NOTEBOOK) can drive mobile thermal printer MPT8/MPT8E to printer through such virtual Bluetooth interface. Rev. 1.9... -
Page 19: Basic Function
MPT8/MPT8E User Manual 3.6 Basic Function 3.6.1 Power On Long touch POWER button, then release the button,printer will power on with below indications. 3.6.2 Power Off When printer is power on, long touch POWER button to enter menu mode, then enter first level menu by long touch FEED button. -
Page 20: Self Test
Look for Bluetooth setting, printer character and other information from self-test. 3.6.5 Hibernation To save power and prolong use time, MPT8/MPT8E use automatic sleep and automatically wake up technology. After turning on the printer, if there are not any operations in standby time, printer will enter standby mode and you can hear a beep from buzzer then screen extinct. -
Page 21: Menu Operation
MPT8/MPT8E User Manual 3.7 Menu Operation Main Menu Second Level Menu Third Level Menu Description Press and hold the FEED button, printer Power-Off will power off. Load Paper and Press the FEED button and then you Self Test Test can print self-test. - Page 22 MPT8/MPT8E User Manual 1. Long touch POWER button, printer will power on with below indications. 2. When the printer is off, press and hold the POWER button to menu mode then release the button the display screen will show main menu: (main menu include 5 items: Power Off, Self Test, Setting, Factory Mode, Back) 3.
- Page 23 MPT8/MPT8E User Manual 4) When you select the “Self Test” of the first level menu, press the FEED button to confirm, the printer’s display screen will show “Please put the paper”, if the printer detect the paper it will show “Please press confirm button to print”, after that press FEED button that the printer will print self-test page.
- Page 24 ⑤When you select "Paper Type" item, 0 means Fax , 1 means A4(or A4 copy paper), press the POWER button you can change the data bit setting, press the FEED button to save and exit. Switch of MPT8/MPT8E's thermal print and A4 print Switching mode:Menu—Setting—Paper Type—A4/Fax(thermal paper) The difference between two ways: 1.
-
Page 25: Buzzer Description
MPT8/MPT8E User Manual 3.8 Buzzer Description NOTE: After entering menu mode, all alarm sound from buzzer is closed, buzzer is used to remind key operation. Buzzer Description Long Short Keys operation Power on Cover open Power off Limit switch position is correct/Automatically feed Enter Standby mode 3.9 Icon Description... -
Page 26: Chapter 4 Interface
MPT8/MPT8E User Manual CHAPTER 4 INTERFACE 4.1 USB Interface Pin No. Signal Name VBUS Rev. 1.9 www.hprt.com... -
Page 27: Chapter 5 Clean Printer
MPT8/MPT8E User Manual CHAPTER 5 CLEAN PRINTER 5.1 Cleaning Head Printing quality might be degraded by dust, foreign substance, adhesive substance, or other pollution materials stuck in the printer head or inside the printer. When dirty, clean the print head as follows: ※NOTE:...
