This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
TO SERVICE PERSONNEL ...................................... 2-3
FRONT PANEL .............................................................. 5
REAR PANELS .......................................................... 5-7
REMOTE CONTROL PANEL ........................................ 8
INTERNAL VIEW ........................................................... 9
DISASSEMBLY PROCEDURES /
.......................................... 17
UPDATING FIRMWARE /
ファームウェアの書き込み
............................................................................ 18-24
1 0 1 0 9 2
SUPER AUDIO CD PLAYER
CD-S1000
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
...................................... 8-9
........... 10-16
Copyright © 2008
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
SERVICE MANUAL
IMPORTANT NOTICE
DISPLAY DATA ........................................................... 25
IC DATA ................................................................. 26-28
PIN CONNECTION DIAGRAMS ............................ 29-30
BLOCK DIAGRAM ....................................................... 31
PRINTED CIRCUIT BOARDS ................................ 32-40
SCHEMATIC DIAGRAMS ...................................... 41-45
REPLACEMENT PARTS LIST .............................. 47-56
REMOTE CONTROL .................................................... 57
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'08.05
