Yamaha CD-S300 Service Manual
Hide thumbs Also See for CD-S300:

Advertisement

This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known
and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifi cations are subject to change without notice or obligation to retrofi t. Should any discrepancy appear to exist, please contact the
distributor's Service Division.
WARNING:
IMPORTANT:
■ CONTENTS
TO SERVICE PERSONNEL ........................................2-3
FRONT PANEL ...............................................................5
REAR PANELS ...........................................................5-6
REMOTE CONTROL PANEL ..........................................7
SPECIFICATIONS / 参考仕様 .........................................8
INTERNAL VIEW ............................................................9
TEST MODE / テストモード ................................... 13-14
1 0 1 1 4 6
COMPACT DISC PLAYER
CD-S300
SERVICE MANUAL
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury,
destruction of expensive components, and failure of the product to perform as specifi ed. For these reasons, we advise
all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or
the appointed service representative.
The presentation or sale of this manual to any individual or fi rm does not constitute authorization, certifi cation or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
UPDATING FIRMWARE /
ファームウェアの書き込み ..................................... 16-21
DISPLAY DATA .............................................................22
IC DATA ...................................................................23-30
PIN CONNECTION DIAGRAMS .............................31-32
BLOCK DIAGRAM ........................................................33
PRINTED CIRCUIT BOARDS .................................34-40
SCHEMATIC DIAGRAMS .......................................41-45
REPLACEMENT PARTS LIST ................................47-55
REMOTE CONTROL .....................................................56
Copyright © 2009
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'09.09

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha CD-S300

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    CD-S300 ■ TO SERVICE PERSONNEL AC LEAKAGE 1. Critical Components Information WALL EQUIPMENT TESTER OR OUTLET UNDER TEST EQUIVALENT Components having special characteristics are marked must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only)
  • Page 3 CD-S300 Laser Emitting conditions: 1) When the Top Cover is removed, and the STANDBY/ON SW is turned to the “ON” position, the laser component will emit a beam for several seconds to detect if a disc is present. During this time (5-10 sec.) the laser may radiate through the lens of the laser pick-up unit.
  • Page 4: Prevention Of Electrostatic Discharge

    CD-S300 ■ PREVENTION OF ELECTROSTATIC DISCHARGE Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor “chip” components. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).
  • Page 5: Front Panel

    CD-S300 ■ FRONT PANEL R, T, A, G, L, J models ■ REAR PANELS R model T model A model...
  • Page 6 CD-S300 G model L model J model...
  • Page 7: Remote Control Panel

    CD-S300 ■ REMOTE CONTROL PANEL CDX8...
  • Page 8: Specifications / 参考仕様

    CD-S300 ■ SPECIFICATIONS / 参考仕様 ■ Audio Section / オーディオ部 Output Level / 出力レベル (1 kHz, 0 dB) ..................2.0 ±0.3 V “iPod” is a trademark of Apple Inc., registered in U.S. and other countries. “Made for iPod” means that an electronic accessory has been designed Signal to Noise Ratio / 信号対雑音比...
  • Page 9: Internal View

    CD-S300 ■ INTERNAL VIEW OPERATION (7) P.C.B. (R, L models) OPERATION (5) P.C.B. OPERATION (9) P.C.B. MAIN P.C.B. OPERATION (4) P.C.B. OPERATION (6) P.C.B. OPERATION (10) P.C.B. Loader mechanism ass'y OPERATION (8) P.C.B. OPERATION (2) P.C.B. OPERATION (3) P.C.B. OPERATION (1) P.C.B.
  • Page 10: Disassembly Procedures / 分解手順

    CD-S300 ■ DISASSEMBLY PROCEDURES / 分解手順 (Remove parts in the order as numbered.) (番号順に部品を取り外してください。 ) Disconnect the power cable from the AC outlet. AC 電源コンセントから、電源コードを抜いてください。 1. Removal of Top Cover 1. トップカバーの外し方 Remove 4 screws ( ① ) and 2 screws ( ② ). (Fig. 1) a.
  • Page 11 CD-S300 Remove 4 screws ( ④ ) and 2 screws ( ⑤ ). (Fig. 2) c. ④ のネジ 4 本、⑤ のネジ 1 本を外します。 (Fig. 2) d. Remove CB6, CB304, CB803 and CB807. (Fig. 1) d. CB6、CB304、CB803、CB807 を外します。 (Fig. 1) Release 2 hooks and then remove the front panel e.
  • Page 12 CD-S300 When checking the P.C.B.s: P.C.B. をチェックする場合には: • Spread the rubber sheet and the cloth. Then place ・ ゴムシートと布を敷き、 その上に本機を置いてチェッ this unit on the cloth and check it. (Fig. 4) クします。 (Fig. 4) • Connect the ground point (ST701) of the front panel ・...
  • Page 13: Test Mode / テストモード

    CD-S300 ■ TEST MODE / テストモード ● Starting test mode ● テストモードの起動 When starting the test mode, check the FL display テストモードの起動時に、FL ディスプレイとインジケー and indicators for display/indication condition. ターの表示状態をチェックします。 1. While pressing the “CD/USB”, “ ” (Skip/ 1. 本機の下図に示す CD/USB キー、...
  • Page 14 CD-S300 ● Operation Procedure of Test Mode ● テストモード時の操作 Function list of remote control keys / リモコンキーの機能一覧 Key code / Key / キー Function / 機能 キーコード OPEN/CLOSE 79-01 Disc tray open/close / ディスクトレイ オープン/クローズ 79-11 Laser on / レーザー オン 79-12 Laser off / レーザー オフ...
  • Page 15: Factory Mode / ファクトリーモード

    CD-S300 ■ FACTORY MODE ● Starting Factory Mode ● ファクトリーモードの起動 While pressing the “ ” (Play) and the “ ” (Stop) 本機の下図に示す (再生) キーと (停止) キー keys of this unit as shown in the figure below, press を押しながら (電源)スイッチを押して電源を入 the “ ” (Power) switch to turn on the power.
  • Page 16: ファームウェアの書き込み

    CD-S300 ■ UPDATING FIRMWARE / ファームウェアの書き込み After replacing the following parts with the replacement 下記の部品をサービス部品に交換した場合、下記の手順 parts, update the latest firmware according to the により最新のファームウェアの書き込みを行ってくださ following procedure. い。 MAIN P.C.B. MAIN P.C.B. Microprocessor (IC305) of MAIN P.C.B. Microprocessor (IC305) of MAIN P.C.B.
  • Page 17 CD-S300 ● Connection ● 接続 1. Set the switch (SW7) of RS232C conversion 1. RS232C 変換アダプターのスイッチ (SW7) FLASH adaptor to the “FLASH UCOM” position. (Fig. 1) UCOM 側に設定します。 (Fig. 1) 2. Connect the writing port (CB902 of OPERATION 2. 本機の書き込み用ポート (OPERATION P.C.B. の...
  • Page 18 CD-S300 ● Operation procedures ● 操作方法 1. Connect the power cable of this unit to the AC 1. 本機の電源コードを AC コンセントに接続します。 outlet. 2. 本機の (電源)スイッチを押して電源を入れ 2. Press the “ ” (Power) switch of this unit to turn on ます。 the power.
  • Page 19 CD-S300 6. Click [Setting], and set the baud rate. (Fig. 4) 6. [Setting]をクリックし、通信速度の設定を行い ます。 (Fig. 4) Select 115200 bps for the baud rate and 40 ms for the program intervals. Reduce the baud rate if a transmission error occurs frequently.
  • Page 20 CD-S300 9. When writing of the firmware is completed, the 9. ファームウェアの書き込みが完了すると、以下の screen appears as shown below. (Fig. 6) 画面が表示されます。 Click [OK]. (Fig. 6) [OK]をクリックします。 (Fig. 6) 10. Click [Exit] to end FlashSta.exe. (Fig. 6) 10. [Exit]をクリックし、FlashSta.exe を終了します。 (Fig. 6)...
  • Page 21 CD-S300 ● Initializing the EEPROM (IC304 of the MAIN ● EEPROM(MAIN P.C.B. の IC304)の初期化 P.C.B.) Be sure to initialize the EEPROM (IC304 of the MAIN ファームウェアのアップデート後、下記の手順で P.C.B.) by using the procedure below after updating EEPROM(MAIN P.C.B. の IC304)を必ず初期化して the firmware, otherwise the set up information (CD/ ください。でなければ、設定情報(CD/USB モード、...
  • Page 22: Display Data

    CD-S300 ■ DISPLAY DATA ● V701: 14-ST-68GINK (OPERATION P.C.B.) ● PIN CONNECTION Pin No. Connection VFL VDDH VDD OSC RESET Pin No. Connection Pin No. Connection Q14G Q13G Note: 1) F1, F2 ..Filament 2) NP ..No pin 3) NX ..No extended pin 4) GND ..GND pin 5) VFL ..VFD driving voltage sink pin 6) VDD ..
  • Page 23: Ic Data

    CD-S300 ■ IC DATA IC2: LC786922E-01UY-E (MAIN P.C.B.) CMOS LSI compact disc player IC CLOCK GENERATOR EFMIN LRSY PCN Output Control RFOUT DATACK EFMlN LRSY Audio Output DATA 8FS DIGITAL FILTER/ RFOUT DATACK SLICE Control 1 bit DAC LEVEL PHLPF...
  • Page 24 CD-S300 Function State During a Reset Detail of Function Name 36 DVDD — — Digital system power supply 37 DVSS — — Digital system ground / This pin must be connected to the 0 V level 38 DVDD15 High Digital circuit power supply capacitor connection 39 VVDD3 —...
  • Page 25 CD-S300 IC7: LC87F1HC8A (MAIN P.C.B.) CMOS LSI Interrupt control Standby control FROM USB PLL Clock generator X’tal SIO0 Bus interface Port 0 SIO1 B register Port 1 SIO4 C register SIO9 Port 2 Timer 0 Port 3 Timer 1 Port 7...
  • Page 26 CD-S300 Pin No. Function Name Detail of Function Option 5, 20, 40 VSS1, VSS2, VSS3 – - power supply 8, 19 VDD1, VDD2 – + power supply VDD3 – USB reference voltage 21, 22, 23, 24, 25, 26, 27, 28 I/O •...
  • Page 27 CD-S300 Pin No. Function Name Detail of Function Option 1, 46, 47, 48 Port 7 I/O • 4-bit I/O port P70 to P73 • I/O specifiable in 1-bit units • Pull-up resistors can be turned on and off in 1-bit units •...
  • Page 28 CD-S300 IC305: R5F212CASNFP (MAIN P.C.B.) Single chip 16-bit microprocessor I/O ports Port P0 Port P1 Port P2 Port P3 Port P4 Port P5 Peripheral functions UART or System clock clock synchronous serial I/O generation circuit (8 bits x 3) Timers...
  • Page 29 CD-S300 Pin No. Function Name Detail of Function EEP_WP Wright protection of EEPROM (IC304) EEP_SDA Serial data to EEPROM (IC304) DAC_/CS Chip select to audio DAC (IC302) DAC_SCL Serial clock to audio DAC (IC302) DAC_SDA Serial data output to audio DAC (IC302) OCD_MODE Input High -->...
  • Page 30 CD-S300 Pin No. Function Name Detail of Function DSP_/RST Reset signal to CD-DSP REG_READY0 Input R_RDY signal from CD-DSP SUB_READY0 Input S_RDY signal from CD-DSP KEY_O/C KEY_USB KEY_PLAY POFF_detect Detect PRIMARY_POWER_OFF condition KEY_0 Detect KEY_0 signal on front-panel STOP, PAUSE, O/C...
  • Page 31: Pin Connection Diagrams

    CD-S300 ■ PIN CONNECTION DIAGRAMS • ICs BD5229G-TR BD9870FPS-E2 KIA7805API KIA79M05PI-U OUTPUT INPUT LA6565-TE-L-E LC786922E-01UY-E LC87F1HC8A-F5AL1-E LE24C023M-TLM-E MFI341S2161 NJM2068D-D PCM1780DBQR R1172S331B-E2-F R5523N001A-TR-F R5F212CASNFP TC7SH08F TC7SH08FU...
  • Page 32 CD-S300 • Diodes 1SS355 2A02-05 XO MAZ8047GHL 4.9V Anode Anode Anode Anode Cathode Cathode Cathode Cathode MTZJ5.6B 5.6V RB050LA-40TR TP MTZJ6.2B 6.2V RB501V-40 MTZJ7.5B 7.5V MTZJ8.2A 8.2V Anode Anode MTZJ30A 30V Cathode Cathode • Transistors 2SA1037K 2SA1708 2SC2412K 2SC3852 2SD1938F...
  • Page 33: Block Diagram

    CD-S300 ■ BLOCK DIAGRAM Front section V701 D702, 703, 751 SW701-708 U701 OPERATION (1) – (3) POWER Indicator CB752 → FL-Display Pure Direct Indicator Front Panel Keys USB connector USB Indicator SCHEMATIC DIAGRAM D+/D- → Loader Mechanism Unit USB+5 MAIN...
  • Page 34: Printed Circuit Boards

    CD-S300 POINT A XL1 (Pin 72 of IC2) POINT B XL2 (Pin 6 of IC7) ■ PRINTED CIRCUIT BOARDS POINT C XL301 (Pin 10 of IC305) POINT D 1 / IC306 (2 pin), 2 / IC306 (1 pin) MAIN P.C.B.
  • Page 35 CD-S300 MAIN P.C.B. (Side B) IC304 • Semiconductor Location Ref no. Location D301 D303 D304 D305 D309 IC304 Q301 Q304...
  • Page 36 CD-S300 OPERATION (1) P.C.B. (Side A) OPERATION (2) P.C.B. OPERATION (3) P.C.B. (Side A) (Side A) MAIN (CB6) ① ② ③ CB753 W751 MAIN (CB304) W701B iPod/USB indicator OPERATION (8) (CB807) CB752 iPod/USB FLGND ACFL1 POWER ACFL2 indicator W703 CB701...
  • Page 37 CD-S300 OPERATION (1) P.C.B. (Side B) OPERATION (2) P.C.B. OPERATION (3) P.C.B. (Side B) (Side B) OPERATION (4) P.C.B. (Side B) • Semiconductor Location Ref no. Location IC702 Q601 Q602 Q603 Q604 Q701 Q702 Q703 Q704 Q705 Q706...
  • Page 38 CD-S300 OPERATION (5) P.C.B. (Side A) OPERATION (7) P.C.B. (Side A) R, L models T, A, G, J models YELLOW ORANGE RED BROWN GRAY BROWN GRAY YELLOW ORANGE W805B W806A W802A W801A W805A W804A W803A W804B W803B W802B W801B WHITE...
  • Page 39 CD-S300 OPERATION (5) P.C.B. (Side B) OPERATION (7) P.C.B. (Side B) R, L models OPERATION (6) P.C.B. (Side B) OPERATION (9) P.C.B. OPERATION (10) P.C.B. (Side B) (Side B) • Semiconductor Location Ref no. Location Q901...
  • Page 40 CD-S300 OPERATION (8) P.C.B. OPERATION (8) P.C.B. (Side A) (Side B) OPERATION (5) (CB804) W807 • Semiconductor Location Ref no. Location M2GND D801 D802 M1GND D803 DGND D804 IC802 D805 IC803 AGND D806 P_MUTE D807 D808 D809 MAIN (CB301) D810...
  • Page 41: Schematic Diagrams

    CD-S300 SCHEMATIC DIAGRAMS MAIN 1/2 SWITCH/ BUFFER ANALOG OUT CURRENT LIMITER DIGITAL OUT iPod/USB IN CD IN Page 43 to OPERATION (3)_W751 CD CONTROLLER USB INTERFACE iPod/USB IN To Loader mechanism unit To Loader mechanism unit No replacement part available.
  • Page 42 CD-S300 MAIN 2/2 Page 43 Page 44 to OPERATION (1)_CB701 to OPERATION (9)_CB901 DIGITAL OUT OPTICAL OUTPUT DIGITAL COAXIAL DC/DC CONVERTER 12.2 IC301 IC309 IC309 IC309 IC309 IC309 MICROPROCESSOR CB308 CB301 12.2 IC303 IC305 IC307 Page 45 to OPERATION (8)_CB806 LINER -5.0...
  • Page 43 CD-S300 OPERATION 1/3 OPERATION (1) -3.4 -26.5 -26.5 -26.5 -26.4 -21.7 Page 45 -21.7 to OPERATION (8)_CB807 -21.7 W702 W701A W701B POWER indicator PURE DIRECT Page 42 indicator to MAIN_CB304 OPERATION (2) CB701 OPERATION (3) CB753 W703 Key detection for A/D port...
  • Page 44 CD-S300 OPERATION 2/3 CB901 Page 42 Writing port to MAIN_CB310 CB902 OPERATION (9) 3 dB AMP. L.P.F. CB601 IC601 -5.0 -4.5 -4.5 CB601 -4.5 -5.0 Page 42 to MAIN_CB303 ANALOG OUT OUTPUT ANALOG OUT L -5.0 -4.5 -4.5 IC602 IC602...
  • Page 45: Schematic Diagrams

    CD-S300 OPERATION 3/3 OPERATION (8) 12.0 12.0 -0.1 12.0 -0.1 12.0 12.0 CB806 12.1 OPERATION (6) POWER ON/OFF IC801 12.0 Page 42 to MAIN_CB301 OPERATION (10) -5.0 -4.5 11.8 IC802 11.8 -0.1 12.0 AC21.2 -0.1 12.0 CB801 CB802 CB804 W807 -0.1...
  • Page 46: Replacement Parts List

    CD-S300 ■ REPLACEMENT PARTS LIST • ELECTRICAL COMPONENT PARTS WARNING ● Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally installed. ● 印のある部分は、安全確保部品を示しています。部品の交換が必要な場合、パーツリストに記載されている部品を使用し てください。 ● 部品価格ランクは、予告なく変更することがあります。 ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS: C.A.EL.CHP...
  • Page 47 CD-S300 P.C.B. MAIN Ref No. Part No. Description Remarks Markets 部 品 名 ランク WS176200 P.C.B. MAIN PCB MAIN WQ289300 CN 24P TE FFC/FPCコネクタ VB390100 CN.BS.PIN ベースピン VB390200 CN.BS.PIN コネクタベースポスト VB390100 CN.BS.PIN ベースピン CB301 VK217300 CN FJリセプタクル CB303 VQ962800 CN.BS.PIN ウエハー CB304 VM859600 CN.BS.PIN FFCコネクター...
  • Page 48 CD-S300 P.C.B. MAIN Ref No. Part No. Description Remarks Markets 部 品 名 ランク WG251600 C.CE.CHP 4.7uF 6.3V チップセラコン US135100 C.CE.CHP 0.1uF チップセラコン WP258700 C.CE.CHP 2.2uF チップセラコン C80-81 US135100 C.CE.CHP 0.1uF チップセラコン C82-83 US060500 C.CE.CHP 50V B チップセラコン UF418100 C.EL.CHP 100uF 6.3V チップケミコン...
  • Page 49 CD-S300 P.C.B. MAIN and P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク IC306 YA514A00 IC BD5229G-TR リセットIC PJ301 V2283400 JACK.PIN ピンジャック * Q1 WS074200 TR 12A01C PNP トランジスタ Q301 VV556500 TR 2SA1037K Q,R,S トランジスタ Q304 VV556400 TR 2SC2412K Q,R,S トランジスタ...
  • Page 50 CD-S300 P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク C812 UR267470 C.EL 47uF ケミコン C813 UR04A100 C.EL 10000uF ケミコン C814-815 UR267220 C.EL 22uF ケミコン C816 WQ785400 C.EL 6800uF ケミコン C817 UR249100 C.EL 1000uF ケミコン C818 WJ608900 C.MYLAR...
  • Page 51 CD-S300 P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク ST801-802 V4040500 SCR.TERM スクリューターミナル ST901-902 V4040500 SCR.TERM スクリューターミナル SW701-708 WD483100 SW.TACT SKRGAAD010 タクト SW SW801 V8377400 SW.POWER SY16-52-4 パワースィッチ SW802 WH813600 VOLT.SELCT VSA-14-3 電圧切替器 * T801 YA770A00 TRANS.PWR 電源トランス...
  • Page 52 CD-S300 Carbon Resistors Value 1/4W Type Part No. 1/6W Type Part No. Value 1/4W Type Part No. 1/6W Type Part No. 1.0 Ω HJ35 3100 HF85 3100 11 kΩ HF45 7110 HF45 7110 ✻ 1.8 Ω 3180 12 kΩ 7120...
  • Page 53 CD-S300 R, L models • OVERALL ASS'Y 6 (5) 6 (7) 6 (9) 6 (6) 1-25 6 (2) 1-25 1-16 6 (4) 1-18 1-25 6 (3) 6 (10) 6 (1) 1-11 1-15 1-17 6 (8) 1-17 200-1 1-25 1-14 1-25...
  • Page 54 CD-S300 Ref No. Part No. Description Remarks Markets 部 品 名 ランク Ref No. Part No. Description Remarks Markets 部 品 名 ランク MF115200 FLEXIBLE FLAT CABLE 15P 200mm P=1.25 カード電線 * 203 WS184100 POWER CABLE 1.5m 1pc 電源コード * 1-11 WR787900 FRONT PANEL フロントパネル...
  • Page 55: Remote Control

    CD-S300 ■ REMOTE CONTROL SCHEMATIC DIAGRAM PANEL KEY LAYOUT KEY CODE Customer Function Data Code Code CD/USB PURE DIRECT 3.3 ohms OPEN/CLOSE PROGRAM REPEAT RANDOM IR-LED DIMMER DISPLAY 47 uF/ 10 V TRKTC8050S 220 ohms 0.1 uF 15 pF 4 MHz...
  • Page 56 CD-S300 MEMO...
  • Page 57 CD-S300...
