Icom ic-m506 Service Manual page 24

[CONNECT UNIT]
REF PARTS
NO. NO.
C1 4030016790 S.CER C1005 JB 1E 103K-T
J1 6510030290 CON ICOM-CCBPM08MCC <ODS>
J2 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M)
EP2 6910019100 S.BEA MPZ1608S101AT
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
• NMEA2000 UNIT (UX-232)
[MAIN UNIT]
H/V
REF PARTS
7.8/13.5
NO. NO.
IC1 1140017121 S.IC
IC2 1110007780 S.IC
8.5/18.3
IC3 1130016110 S.IC
6.3/13.1
Q1 1510001090 S.TRA
Q2 1590004070 S.TRA
Q3 1510001151 S.TRA
Q4 1530004140 S.TRA
D1 1750001810 S.DIO
X1 6050013880 S.XTA
R1 7030005050 S.RES ERJ2GEJ 103 X (10K)
R3 7030005240 S.RES ERJ2GEJ 473 X (47K)
R4 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R5 7410001230 S.ARR EXB28V101JX
R11 7030009140 S.RES ERJ2GEJ 272 X (2.7K)
R12 7030005090 S.RES ERJ2GEJ 104 X (100K)
R13 7030005050 S.RES ERJ2GEJ 103 X (10K)
R14 7030005050 S.RES ERJ2GEJ 103 X (10K)
R15 7030005090 S.RES ERJ2GEJ 104 X (100K)
R16 7030005090 S.RES ERJ2GEJ 104 X (100K)
R17 7410001330 S.ARR EXB24V101JX
R19 7030010040 S.RES ERJ2GEJ-JPW
R21 7030005050 S.RES ERJ2GEJ 103 X (10K)
R22 7030008290 S.RES ERJ2GEJ 183 X (18K)
R23 7030005530 S.RES ERJ2GEJ 100 X (10)
R24 7030008290 S.RES ERJ2GEJ 183 X (18K)
R25 7030005240 S.RES ERJ2GEJ 473 X (47K)
C1 4030016930 S.CER C1005 JB 1A 104K-T
C2 4030016930 S.CER C1005 JB 1A 104K-T
C3 4030016930 S.CER C1005 JB 1A 104K-T
C4 4030016930 S.CER C1005 JB 1A 104K-T
C5 4030016930 S.CER C1005 JB 1A 104K-T
C6 4030016930 S.CER C1005 JB 1A 104K-T
C7 4030017460 S.CER C1005 JB 1H 102K-T
C8 4030019500 S.CER GRM21BB31A106KE18
C9 4030017460 S.CER C1005 JB 1H 102K-T
C10 4030016930 S.CER C1005 JB 1A 104K-T
C11 4030017660 S.CER C1005 CH 1H 330J-T
C12 4030017660 S.CER C1005 CH 1H 330J-T
C13 4030017460 S.CER C1005 JB 1H 102K-T
C25 4030017460 S.CER C1005 JB 1H 102K-T
J1 6510022692 S.CON 06FLT-SM2-TB(LF)(SN)(M)
J2 6510022022 S.CON 14FLT-SM2-TB(LF)(SN)(M)
J3 6510021441 S.CON B6B-ZR-SM4-TF(LF)(SN)
J4 6510019421 S.CON B8B-ZR-SM4-TF(LF)(SN)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5-10
DESCRIPTION M.
STM32F103RCT6(EX3572A1)
<TOMEN> T
NJU7704F3-28A-TE1-#ZZZH T
TC7WH14FK(TE85LF) *0 T
KTA2015Y-RTK/P T
LDTC144EET1G <SLVJ> T
L2SA1576AST1G <SLVJ> T
L2SC4081RT1G <SLVJ> T
L1SS400T1G <SLVJ> T
CR-984 (TQU5594) 8.0 MHz T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
(GRM40 B) T
T
T
T
T
T
T
T
T
T
T
S.=Surface mount
H/V
LOCATION
22.5/33.5
24.5/12.2
11.5/12.2
24.5/8.2
23.3/4.4
10.3/8.2
11.5/4.3
9.6/2.8
21.9/22.1
24.1/10.2
22.7/7.7
23.1/6.2
19.8/14.9
21.8/25.2
11.2/16.1
10.4/39.7
12.8/17.9
12.8/18.8
30.8/35.4
17.8/14.9
13.3/43.6
10.0/6.3
9.6/5.0
14.4/2.7
12.2/6.8
8.5/8.2
14.2/30.0
26.1/25.2
30.8/30.3
30.8/37.1
19.2/41.8
1.8/43.4
1.7/28.2
27.7/9.3
26.3/8.6
13.3/11.8
20.3/18.9
23.3/18.9
14.4/1.8
16.2/10.7
13.0/47.3
17.5/6.5
7.6/37.0
7.6/20.0
