13. Disposal and environment protection
Your device should be disposed free of charge at the local disposal points.
14. Technical specifications
Device
Power supply
Weight
Vertical pivoting radius
Dimensions incl. Octagon
Softbox (HxWxD)
Accessories
Lamps
Spiral Daylight
(energy-saving lamp), which
comply to EN 60357 Page 3155
Colour temperature
Socket
Permitted operation
tempearture
Storage conditions
AC 220 - 230 V / 50 Hz
approx. 3 kg
180 °
approx. 80 cm x 80 cm x 49 cm
Lamps, front diffuser, rear diffuser
3 x 24 W
5200 - 5500 K
E27
-10 °C to + 40 °C
Dry and dust-free in carton at
-20 °C to +50 °C
16
Copy of Instruction Manual
Daylight 360 with Octagon Softbox Ø 80 cm
Gewerbering 26
86666 Burgheim
Tel. +49 84 32 / 9489-0
Fax. +49 84 32 / 9489 - 8333
eMail:
info@foto-walser.de
www.foto-walser.de
1
