14. Technical specifications
Device
Power supply
AC 220 - 230 V / 50 Hz
Weight
approx. 1 kg
Vertical pivoting radius
180 °
Copy of Instruction Manual
Dimensions incl. softbox
approx. 60 cm x 40 cm x 49 cm
(HxWxD)
Accessories
Lamp, front diffuser, instruction
manual
Lamp
Spiral Daylight
(energy-saving lamp), which
1 x 50 W
comply to EN 60357 Page
3155
Colour temperature
5400 K
Socket
E27
Permitted operation
-10 °C to + 40 °C
temperature
Daylight 250 with Softbox 40 x 60 cm
Storage conditions
Dry and dust-free in carton at
-20 °C to +50 °C
Gewerbering 26
86666 Burgheim
Tel. +49 84 32 / 9489-0
Fax. +49 84 32 / 9489 - 8333
eMail:
info@foto-walser.de
www.foto-walser.de
16
1
Advertisement
Related Manuals for walimex Daylight 250
Summary of Contents for walimex Daylight 250
- Page 1 Colour temperature 5400 K Socket Permitted operation -10 °C to + 40 °C temperature Daylight 250 with Softbox 40 x 60 cm Storage conditions Dry and dust-free in carton at -20 °C to +50 °C Gewerbering 26 86666 Burgheim Tel. +49 84 32 / 9489-0 Fax.
-
Page 2: Accessories And Options
Switch on and off of the device and the lamp…………..………………...12 Transportation and storage ............12 Solve problems ................13 Part of the device Item number Maintenance ................13 Lamp (walimex Spiral Daylight 50 W) 16233 10.1 Continuous inspections ..............13 10.2 Cleaning ................... 14 10.3... - Page 3 What you should do? every change operation The walimex Daylight 250 with Softbox 40 x 60 cm is a powerful, energy- Check, if the lamp is screwed in firmly saving continuous light, which is especially developed for ambitious In case of damage: beginners and professional users in film and studio photography.
- Page 4 How to understand the instruction manual Solve problems Markings on the device Problem Possible reason Remedy This marking mean, that your device meets the safety Device is switched on, Power cord is not Plug in the power requirements of all relevant European Directives. but has no function plugged or plugged cord correctly...
- Page 5 Operation of the device Important safety notes Adjust tilt angle WARNING 1. Loose fastening screw for tilt lever. Risk of eye injury The optical radiation of the lamp could blind your eyes and lead to 2. Adjust required tilt angle. afterimages, if persons and animals look into the lamp directly.
- Page 6 Screw in and out of lamp humidity or moisture. A short-circuit can warm up the conductors, so that there isolation will melt or even melt thoroughly. This could lead to fire. WARNING − Please just use the original cables, which are included in delivery. Danger of cutting and splitting through breaking or bursting lamp They are aligned for your device and guarantee the necessary safety Don´t let the lamp fall down.
- Page 7 − Please just use accessories and spare parts, which are conform to the WARNING Please note the safety notes in the respective chapters throughout required specifications. operation. See Technical Specifications. − Lamps, which are damaged or deformed through heat, should be •...
- Page 8 − Please just use lamps, which comply to EN 60357 Page 3155. Unpack and check the device 1. Please unpack your device carefully. 2. Please check, if the delivery is complete. • 1 Daylight 250 with softbox o 1 Lamp o 1 Front Diffuser o 1 Carrying Bag •...
