- Page 1 OWNER’ S MANUAL PAV-9 MOTORIZED 7 ” ” IN-DASH LCD COLOR MONITOR WITH AM/FM STEREO RADIO...
- Page 2 Any changes or modifications in construction of this device that is not expressly approved by the party responsible for compliance could void the user’ s warranty.
- Page 3 WARNING The exclamation point within an equilateral triangle and “WARNING”are intended to alert the user to the presence of important operating instructions. Failure to heed the instruction will result in severe injury or death DO NOT WATCH VIDEO WHILE DRIVING Watching the video may distract the driver from looking ahead of the vehicle and cause and accident.
- Page 4 CAUTION The exclamation point within an equilateral triangle and “CAUTION” ” are intended to alert the user to the presence of important operating instructions. Failure to heed the instruction can result in injury or material damage. DO NOT RAISE THE VOLUME EXCESSIVELY Keep the volume at a level where you can still hear outside noises while driving.
-
Page 5: Fuse Replacement
CAUTION The exclamation point within an equilateral triangle and “CAUTION” ”are intended to alert the user to the presence of important operating instructions. Failure to heed the instruction can result in injury or material damage. Operation of some of the functions of this unit is very complex. Because of this, it was deemed necessary to place these functions into a special SETUP screen. - Page 6 INTRODUCTION MONITOR ① POWER ON/ OFF BUTTON ② MODE SELECTION BUTTON ③ AS/ATM BUTTON ④ SOUND MUTE BUTTON ⑤ VOLUME UP/DOWN ADJUST BUTTON ⑥ SEARCH UP/DOWN BUTTON ⑦ OPEN/CLOSE BUTTON ⑧ TILT UP/DOWN BUTTON ⑨ BAND SELECTION BUTTON...
-
Page 7: Remote Control
REMOTE CONTROL ① POWER ON/ OFF BUTTON ② MODE SELECTION BUTTON ③ AS/ATM BUTTON ④ SOUND MUTE BUTTON ⑤ VOLUME UP/DOWN ADJUST BUTTON ⑥ SEARCH UP/DOWN BUTTON ⑦ OPEN/CLOSE BUTTON ⑧ MANUAL MEMORY BUTTON ( MENU IN TV MODE) ⑨ CHANNEL UP/DOWN BUTTON ⑩... - Page 8 REMOTE CONTROL UNIT Replacing battery Applicable battery : Use two “AAA” sized dry batteries. 1. Opening the battery cover. Push and slide the cover in the arrow direction, and the cover will be removed. 2. Replacing the battery. Remove the old batteries. Insert new ones matching the (+) and polarities as shown in the diagram inside the unit.
-
Page 9: Basic Operation
POWER ON / OFF 1. POWER ON 1) Press the POWER button to turn the power on and the monitor will open. When the monitor is opened, it requires a password as pictured above. Press the number button of the remote control to input “0000” and then the last mode will be displayed. 2) You can also turn the power on by pressing the OPEN/CLOSE button. -
Page 10: To Change Password
TO CHANGE PASSWORD 1. Press the menu button repeatedly while in radio mode or AV mode until the volume menu is selected. The monitor displays following picture. 1. Press the search up/down button to select “password” to change the password. 2. -
Page 11: Closing The Monitor
CLOSING THE MONITOR 1. Hold the left and right upper side of the monitor and set the left and right angle of the monitor parallel with the front of the unit as the picture above. 2. Press OPEN/CLOSE button or power button then the monitor will be closed. NOTE 1. - Page 12 ADJUSTING THE SLIDE POSITION 1. Press the MENU button repeatedly on the radio or remote until the USER SELECT menu is displayed. 2. Press the SEARCH UP/DOWN button to select MOVE 3. Press the VOLUME ▶ button to select FORWARD. The monitor will slide one step to the left.
-
Page 13: Selecting Mode
SELECTING MODE Press the MODE button to select the desired mode. Each time you press the button, the mode changes as follows. RADIO -> AV1 -> AV2 -> AV3 (CD/DVD CHANGER) -> AV4 (TV) NOTE 1. AV3 has only a video input. 2. -
Page 14: Normal Mode
ADJUSTING THE TV/VIDEO PICTURE MODE (ASPECT) Each time you press A (ASPECT) button, the picture mode switches between Normal, Full, Zoom and Wide. NOTE You can also select the picture mode manually by pressing the function button on the unit as follows. -
Page 15: Radio Control
Press the OPEN/CLOSE button to turn the power on and open the monitor. The monitor shows following picture NOTE 1. Each time you press the MENU button on RADIO MAIN MENU screen, the menu on the screen changes as follows. RADIO SUB ->... - Page 16 AUTO MEMORY OF STATION 1. Press the AS/ATM button for at least 2 seconds. The frequency on the display continues to change while the auto memory is in progress. The tuner will automatically seek and can store up to 30 stations in each band in order of frequency signal. They can be stored in FM 1 : 30, FM 2 : 30, AM 1 : 30 and AM 2 : 30 stations (total 120 stations).
-
Page 17: Radio Band
RADIO BAND 1. Press the SEARCH UP/DOWN button to select RADIO BAND. 2. When RADIO BAND is selected, press the VOLUME ◀ or ▶ button, the band switches as follows. FM 1 -> FM 2 -> AM 1 -> AM 2 3. - Page 18 SETTING THE NAVIGATION 1. Connect a NAVIGATION system to the AV1 or AV2 input terminals on the rear of the unit. 2. Press the MODE button to select radio mode. 3. Press the MENU button to select following picture. 4. Press the SEARCH UP/DOWN button to select NAVIGATION. 5.
-
Page 19: Wiring Connection
SETTING THE CAMERA IN 1. Connect a back up camera video output to the AV1,2 or 3 video input terminals on the rear of the unit. * When the DVD changer is connected to AV3 video input, the rear view camera can be connected only to AV1 or AV2 video input. - Page 20 When a CD or DVD changer is connected to this unit with the 8 pin DIN cable, AV3 mode will change to DISC CHANGER mode and the DISC CHANGER control menu is displayed on the screen. 1. Press the MODE button to select DISC CHANGER (AV3) mode. Each time you press this button, the display changes as follows.
-
Page 21: Track Number
TRACK NUMBER 1. Press the SEARCH UP/DOWN button to select TRACK NUMBER. 2. Each time you press CH UP button, the next track will be selected and the displayed track number increases by one. 3. Each time you press CH DOWN button, the previous track will be selected and the displayed track number decreases by one. - Page 22 DIRECT CD/DVD CHANGER CONTROL In the DISC CHANGER mode, you can directly control CD/DVD changer functions just by pressing the buttons on the remote control of the monitor unit. STOP ■ button : To make the playing of the disc stop. PAUSE button : To stop the playing of the disc.
- Page 23 VOLUME ADJUSTMENT OF EACH CHANNEL You can adjust the volume level of each channel of the radio or AV sources connected to this unit. ADJUSTING THE VOLUME OF EACH CHANNEL 1. Press the MENU button repeatedly on radio or AV mode until VOLUME MENU is selected.
- Page 24 FINE FREQUENCY AND TILT/SLIDE POSITION 1. Press the MENU button when the monitor shows following picture. The monitor shows following picture 2. Press SEARCH UP/DOWN button to select the items that you want to adjust. 3. Press the VOLUME ◀ or ▶ button to adjust the level of the selected item. ADJUSTMENT CENTER...
-
Page 25: Screen Control
SCREEN CONTROL 1. Press the MENU button when the monitor shows following picture. The monitor shows following picture 2. Press SEARCH UP/DOWN button to select the items that you want to adjust. 3. Press the VOLUME ◀ or ▶ button to adjust the level of the selected item. - Page 26 1. Press the SEARCH UP/DOWN button to select COLOR SYSTEM for the video source on PICTURE mode. 2. Press the VOLUME ◀ or ▶ button to select PAL or NTSC for the video source. NOTE To select the color system for the TV when the TV tuner box is connected to the AV4 input of this unit, 1.
- Page 27 VOLUME CONTROL ON AV MODE To adjust audio level of AV system on AV mode. 1. Press the VOLUME ◀ or ▶ button. The monitor shows following picture. 2. Press SEARCH UP/DOWN button to select the items that you want to adjust. 3.
-
Page 28: Warning Screen
WARNING SCREEN The monitor shows following warning picture when the parking brake is not set or when driving to prevent accidents that may be caused while watching the screen. The monitor shows the warning picture only and does not show any other pictures, but you can enjoy the sound only by adjusting the volume. - Page 29 AV INPUT FACE PLATE OF THE UNIT 3.5mm AV input on the front face of the unit is same input with AV1 input on NOTE the rear of the unit. If the sources are not connected to both input terminals, the front 3.5mm input has priority over the AV1 input.
-
Page 30: Installation
PRECAUTIONS Choose the mounting location carefully so that the unit will not interfere with the normal driving functions of the driver. Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight or hot air from the heater or where it would be subject to dust, dirt or excessive vibration. -
Page 31: Basic Connections
BASIC CONNECTIONS Tel mute-Activated with Ground 1. Be sure that the PARKING SENSOR WIRE must be grounded or opened. NOTE If it is connected to ACC (B+), the unit can be damaged. 2. Do not ground the POWER ANTENNA or REMOTE TURN ON wire. If it is grounded, the unit can be damaged. - Page 32 CONNECTING PAVNAVC2 TO NAVIGATION & PAV-9...
- Page 33 CONNECTING TO CD CHANGER AND TV TUNER BOX...
-
Page 34: Specifications
AM SECTION USA BAND Frequency Range Frequency Step EUROPEAN BAND Frequency Range Frequency Step Intermediate Frequency Usable Sensitivity Image Rejection Ratio IF Rejection Ratio FM SECTION Frequency Range Frequency Step Manual Tuning Seek Tuning Intermediate Frequency Usable Sensitivity Image Rejection Ratio IF Rejection Ratio CD CHANGER Signal/Noise Ratio... -
Page 35: 12 Month Limited Warranty
12 MONTH LIMITED WARRANTY Applies to Audiovox Video products AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company’... - Page 36 128-6892 PRINTED IN KOREA...
