two occupants at one time having a 230 pounds. 2 ...
Page 3
PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty.
Page 4
PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION'S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.
SAFETY ZONE 13'-4" 6' R 7'-0" Height 8'-0" 26'-8" 13'-4" 7'-8" 19'-8" MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 160". SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING.
TOOLS REQUIRED TAPE MEASURE DRILL 1/2” & 7/16’’ SOCKETS HAMMER ADJUSTABLE & WRENCH WRENCH SCREWDRIVER LADDER CARPENTER SAFETY GLASSES 1/8" DRILL BIT & PLIERS SQUARE 1/4" DRILL BIT INCLUDED HARDWARE 3/8 x 5" carriage bolts (x4) 3/8" Flat Washer (x18) 3/8 x 4"...
Page 7
COMPONENTS 4" Dia. x 93" Plastic-coated Post (x1) 3-1/4" Dia. x 93" Plastic-coated Post (x4) 1-1/2" Dia. x 49" A-Frame Brace (x2) Swing Beam Bracket Right (x2) Swing Beam Under Beam (x2) Swing Hangers (x4) Swing Beam Bracket Left (x2) Beam Clamp (slotted) (x4) Anchor It (x4) Anchor It Strap (x4)
Page 8
45" 90° 1/8" pilot holes 3-1/4 Dia. x 93" Plastic-Coated Posts (x2) Temporary carriage bolts 1/4 x 2-1/2" Panhead Screw 1/4" lock washer 1/4" flat washer A-Brace Weep Holes Note: Fasteners should be snug at this point. You will assemble two A-frame post assemblies. 1.
Page 9
Center bracket on posts Plastic sleeve may extend past cap edge, but locate bracket flush to cap edge. Flush with edges of caps 1/8" predrill 1/4" predrill Carefully mark center Fig. 1 Fig. 2 Fig. 3 Edges still touch of all four holes 3/8 x 2-1/2"...
Page 10
3/8 x 4" Carriage bolt 3/8" lock nut 3/8" flat washer 1. Carefully flip the A-frame over. 2. Remove any wood or plastic material in hole openings. Attach two brackets to the post as shown. Tighten fasteners slightly snug at this point. Do NOT fully tighten. 3.
Page 11
T-nut Correct orientation S l o Beam Clamp Swing Hanger 1-1/4" Screws 1. Remove any wood or plastic material in hole openings. Tap T-nuts into holes as shown. 2. Insert Hangers through Beam Clamp and into T-nuts. 3. Use screwdriver as lever to help seat hanger securely into slotted beam clamp. Secure slotted clamp with screws.
Page 12
3/8" lock nut 3/8" flat washer This hole empty. 3/8 x 5" Carriage bolt 1. Remove any wood or plastic material in hole openings. Locate the swing beam between the brackets and attach as shown. HINT: Loosen bolts in 3-1/4" posts to help align holes for 5" bolts if necessary. Tighten fasteners slightly snug at this point.
Page 13
3/8" lock nut 3/8" flat washer 3/8 x 5" Carriage bolt 1. Carefully swing the A-frame assembly up and insert a second bolt. Attach as shown. Tighten fasteners slightly snug at this point. Do NOT fully tighten.
Page 14
3/8" lock nut 3/8" flat washer 3/8 x 5" Carriage bolt 1. Locate the second A-frame assembly and remove any wood or plastic material in hole openings. Attach to swing beam as shown. HINT: Loosen bolts in 3-1/4" posts to help align holes for 5" bolts if necessary. Tighten fasteners slightly snug at this point.
Page 15
3/8" lock nut 3/8" flat washer 3/8 x 5" Carriage bolt Tighten ALL Lock nuts 3/8" flat washer until 2 threads minimum 3/8" lock washer extend past nut. 3/8 x 2-1/2" Lag screw 1/4" Pre-drill Swing A-Frame up 1. Carefully swing the A-frame up and insert a second bolt. Attach as shown. Tighten fasteners slightly snug at this point.
Page 16
Plastic-coated end. Swing Seat Assembly 1. Take one length of chain and place the outermost link of chain through the Security Link as shown. 2. Place the Security Link through the Grommet of the swing seat as shown. 3. Tighten the threaded sleeve of the Security Link with a suitably sized wrench so that the seat is securely attached and the Security Link cannot be easily loosened.
Page 17
Plastic-coated end. Ring-Trap Combo Assembly 1. Attach Security Link to chain oriented as shown. 2. Attach Security Link to gym ring as shown. Attach second set of Security Links (3) links up. Attach Trapeze Bar as shown. 3. Tighten all Security Links closed with wrench.
Page 18
Affix Label as shown using (4)1/2" Screws Fold up 5/16” Washer 1-1/2” Anchor-It Lag Screw Strap Anchor-It 1 At locations circled above, twist the Anchor-It into the ground until only the loop is exposed. 2. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using any of the holes in the strap that work best.
Page 20
Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced customer service representatives who have actually built a swing set themselves. @ Swing-N-Slide Inc. 2015 Printed in USA...
