- Page 1 Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide Intel® NUC Kit NUC5i3MYHE Intel® NUC Kit NUC5i5MYHE User Guide...
-
Page 2: Before You Begin
If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Installation Precautions When you install and test the Intel NUC, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: ... -
Page 3: Installing And Removing Memory
To open the Intel NUC chassis, follow these steps: 1. Unscrew the four corner screws on the bottom cover of the chassis and lift the cover. Installing and Removing Memory Intel NUC Kits NUC5i3MYHE and NUC5i5MYHE have two 204-pin DDR3L SO-DIMM sockets. Memory requirements: ... - Page 4 8. Replace the computer’s cover and reconnect the AC power cord. Installing a 30mm M.2 Wireless Adapter Only the following wireless adapters have been evaluated for regulatory compliance for use with the Intel NUC Kits NUC5i3MYHE and NUC5i5MYHE in all regions: ...
- Page 5 Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide CAUTION When installing an M.2 wireless adapter on the Intel NUC, ensure that the adapter is fully seated in the connector before you power on the system. If the adapter is not fully seated in the connector, an electrical short may result across the connector pins.
- Page 6 Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide 5. Secure the wireless card to the motherboard with the standoff (C). 6. Remove the black tape holding the two wireless antennas. 7. Remove the clear plastic protective sleeve from the antenna wires (D).
- Page 7 8. Attach the antenna leads to the connectors on the wireless card (E). Install an M.2 SSD Intel NUC Kits NUC5i3MYHE and NUC5i5MYHE support 80mm and 42mm M.2 SSDs. For a list of tested M.2 SSDs, go to the Tested Peripherals page on the Support site.
- Page 8 Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide 4. Secure the card to the standoff with the small silver screw (C). Install a 2.5” SSD or Hard Drive For a list of tested 2.5” hard drives, go to the Tested Peripherals page on the Support site.
-
Page 9: Close The Chassis
Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide 3. Flip the chassis cover back into place over the motherboard (B). Close the Chassis After all components have been installed, close the Intel NUC chassis. - Page 10 1. Using the four small black screws that were included in the box, attach the VESA bracket to the back of the monitor or TV. 2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC.
-
Page 11: Install An Operating System
Refer to Supported Operating Systems for a list of Intel-validated Windows* operating systems, as well as versions of Linux that have been reported as compatible by Intel NUC owners. Refer to Operating System Installation for system requirements and installation steps. - Page 12 Intel NUC Kit NUC5i3MYHE & NUC5i5MYHE User Guide Install Intel NUC Drivers To download the latest Microsoft* Windows* drivers and BIOS updates, go to Download Center: Links: Intel® NUC Kit NUC5i3MYHE Intel® NUC Kit NUC5i5MYHE Drivers are available for the following features: ...
