RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifi cations and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
Page 3
SPECIFICATIONS: SWCBE Type: Waffl e Cone Baker 120V, 1,320 watts, 11 amp, NEMA 5-15P 208V, 990 watts, 4.8 amp, NEMA 6-15P 240V, 1,320 watts, 5.5 amp, NEMA 6-15P 230V 1,210 watts, 5.25 amp, CEE7-7 Approximate weight: installed - 29 Lb s (13 kg), shipping - 32 Lbs (14.5 kg) Dimensions: 10"...
CAUTION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. INSTALLATION For your protection, we recommend that a qualifi...
MAKING WAFFLES Turn the unit on and allow to pre-heat for 15 minutes with the grids closed. Once the baker has reached proper temperature you can proceed as follows: 1. Brush on releasing agent, if needed 2. Lift the lid, pour in mix and close. (Belgian units wait 10 seconds) 3.
Page 6
CLEANING For non-coated grids: Clean outside of baker every day that it is in use. Do not clean grids unless a buildup of carbon forms. In order to remove carbon from grids, unplug the unit, place ammonia soaked cloth over bottom grid, close and leave overnight. A nylon brush may then be used to remove the carbon buildup.
Page 7
LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
CONTROL PANEL OVERLAY IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. NI = NOT ILLUSTRATED Star Manufacturing International, Inc.
Page 17
SWB7R2E 2M-Z1753 CONTROL PANEL OVERLAY IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
Page 19
DRIP TRAY 2M-Z1753 CONTROL PANEL OVERLAY IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
Page 21
PARTS LIST June 29, 2006, Rev F SWCBE Waffl e Baker MODEL Number Part Unit Number Number Description 2I-Z0057 FOOT RUBBER 2E-Z3385 LEAD IN CORD 120V 15A B9-73028 LEAD IN CORD 240V B9-73029 LEAD IN CORD 230V CE B9-Z1723 COVER-BOTTOM...
Page 23
DRIP TRAY 2M-Z1753 CONTROL PANEL OVERLAY IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
