- Page 1 Signature Pad Omega User manual signotec GmbH Am Gierath 20 b 40885 Ratingen, Germany +49 (0) 2102 53575 - 10 www.signotec.com info@signotec.de Version 1.1 as of 26 August 2016...
-
Page 2: Table Of Contents
GmbH based in Ratingen, Germany. Reproduction of this documentation, in part or in whole, is subject to prior written approval from signotec GmbH. All hardware and software names used are trade names and/or trademarks of their respective manufacturers/owners. - Page 3 Document History Version Date Person respon- Status/note sible 29. July 2016 Peter Oellers Document created 29. August 2016 Peter Oellers Several corrections © 2000 - 2016 signotec GmbH User manual Omega Pad Page 3 of 10...
-
Page 4: Thank You
The signotec LCD Signature Pad Omega was designed for the use in an office- or at the counter- environment and was tested in exactly these operating settings. The use of the device in other fields of application may damage it and is undertaken entirely at the user’s own risk. -
Page 5: Product
Ergonomic special pen with changeable cartridge and pen holder Status LED (= Light- Emitting Diode)/control lamp LCD (= Liquid Crystal Display) Cord USB-Cable (fixed installed) Back view Cord USB Cable (fixed installed) Pen holder © 2000 - 2016 signotec GmbH User manual Omega Pad Page 5 of 10... -
Page 6: Bottom View
Bottom view Pen holder USB cable (fixed installed) Nameplate with device name and serial number Mounting holes Cord © 2000 - 2016 signotec GmbH User manual Omega Pad Page 6 of 10... -
Page 7: Access To The Service Menu
Navigate accordingly by using the pen supplied. Connection types The signotec LCD Signature Pad Omega is available in two different versions (HID/FTDI). Switching the mode is not possible. Data transmission between pad and software is encrypted optimally. For this, signotec uses a unique RSA algorithm which generates a private key for every signing-process and encrypts the data with/by? AES-256. -
Page 8: Usb Connection
This driver deactivates this function for our signature pads, so that the device is always available. You can find the driver in the download section on www.signotec.com. Adjusting the brightness The configuration of the brightness of the device is carried out via the service menu. -
Page 9: Pen And Pen Holder
Alternatively, the calibration can be carried out via the signoSign/2 application software. Pen and pen holder The signotec pads are equipped with a robust and maintenance-free pen that does not require batteries. With its realistic size it gives the user an optimal writing experience. The pen can be attached to the pen holder. -
Page 10: General Safety Notes
10 Support – Contact The products and solutions from signotec are designed to make our customers satisfied users. If you should encounter an unexpected problem, you can turn to our support pages for the necessary help and support.
