DVR 993HD
Digital Camcorder

User Manual

© 2009-2013 Sakar International, Inc. All rights reserved.
Windows and the Windows logo are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Vivitar DVR 993HD

Summary of Contents for Vivitar DVR 993HD

  • Page 1: User Manual

    DVR 993HD Digital Camcorder User Manual © 2009-2013 Sakar International, Inc. All rights reserved. Windows and the Windows logo are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective companies.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction ..........................3 What’s Included ......................... 4 Parts of the Camcorder ......................5 Initial Camcorder Setup ......................5 Main Camcorder Modes ......................11 Camcorder Technical Specifications ..................12 Computer System Requirements ..................... 13 Using Your Digital Camcorder ....................14 Changing Camcorder Mode .....................

  • Page 3: Introduction

    This digital camcorder is a plug and play device. You can download the pictures and videos captured by your digital camcorder without the software by directly accessing the camcorder’s memory card from your computer. It is recommended however that you install the Vivitar Experience™ Image Manager Software to enjoy the full Vivitar Experience™.

  • Page 4: What's Included

    What’s Included 1. Digital Camcorder with Lens Cover 2. USB cable 3. TV Cable 4. Vivitar Experience Image Manager Software Installation CD 5. Lens Cover Strap 6. Lithium Battery 7. AC Charger 8. Hand Strap (not shown) Note: SD Memory Card not included.

  • Page 5: Parts Of The Camcorder

    Parts of the Camcorder Power Button 13. Shutter Button Display Button 14. HDMI Port MENU Button 15. USB Port MODE Button 16. Speaker (on the side) Self Timer / Left Button 17. LCD Screen Exposure (EV -) / Down Button 18.

  • Page 6: Initial Camcorder Setup

    Initial Camcorder Setup INSTALLING AND CHARGING THE INSTALLING THE MEMORY CARD BATTERY  Charge before using your camcorder for the first time.  To Charge the Lithium Battery:  Insert SD Memory card (up to 32GB) 1. Power off the camcorder. before use.
  • Page 7 POWERING THE DIGITAL CAMCORDER ON 1. LITHIUM BATTERY: Install and Charge the Lithium Battery.  Make sure the lithium battery has been charged and inserted properly.  To charge the lithium battery: - Connect the USB cable (supplied) to camcorder and the other end of the cable either to your computer USB slot or to the supplied AC Adapter (which you then plug into an electrical outlet).
  • Page 8 - Push the SD card until you hear a slight clicking sound. This indicates the SD card has been inserted correctly. See images below: 3 and 4. Note:  After the camera is powered on, the SD icon will appear on the LCD display. If you do not see the SD icon on the display, please check if the card was inserted properly.
  • Page 9 CAMERA SETTINGS: INITIAL SETUP When powering the digital camcorder ON for the first time the digital camcorder will take you through the initial setup. Setting the Language 1. You will first be prompted to select a language for the camcorder. The Language selection menu will appear.
  • Page 10 Setting the ViviLink Default Option Next you will be asked to “Confirm ViviLink Photo and Video Social Network site” to set the default ViviLink destination for photos and videos taken with your camcorder. The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying software application.

  • Page 11: Main Camcorder Modes

    Main Camcorder Modes Your camcorder has different modes for the various camcorder functions. You can switch modes by pressing the MODE button on your camcorder after the camcorder has been powered ON. VIDEO CAPTURE MODE Use this mode to capture videos with your digital camcorder. This is the default mode when the camcorder is powered ON.

  • Page 12: Camcorder Technical Specifications

    Camcorder Technical Specifications Image Sensor CMOS Sensor (16M) 4640 x 3480 pixels, (14MP) 4352 x 3267 pixels, (12M) 4032 x 3024 pixels, (10M) 3648 x 2736 pixels, Image Resolution (8MP) 3264 x 2448 pixels, (7MP HD) 3648 x 2048 pixels, (5MP) 2592 x 1944 pixels, (3MP) 2048 x 1536 pixels (default), (2MP HD) 1920 x 1080 pixels and (VGA) 640 x 480 pixels (FHD) 1440 x 1080, (HD) 1280 x 720 (default),...

  • Page 13: Computer System Requirements

    Computer System Requirements To be able to download photos and videos to your computer using the Vivitar Experience Image Manager Software, you will need the following minimum configuration: WINDOWS OS  Microsoft® Windows XP with Service Pack 3, Windows Vista with Service Pack 1 or Windows 7 ...

  • Page 14: Using Your Digital Camcorder

    Using Your Digital Camcorder  Make sure the rechargeable lithium battery is fully charged before the first use.  Make sure a proper SD card has been inserted correctly into your camcorder. Please see Initial Camcorder Setup for more information. POWERING THE CAMCORDER ON Press the POWER button to turn your camcorder ON.

  • Page 15: Changing Camcorder Mode

    Changing Camcorder Mode Your camcorder has three main modes: 1. Video Capture Mode - Use this mode to capture videos with your camcorder. 2. Photo Capture Mode - Use this mode to capture photos with your camcorder. 3. Playback Mode (for photos and videos) - Use this mode to view the photos and videos you have already taken with your camcorder.

  • Page 16: Camcorder Features: Vivilink, Led Light, Display

    The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying Vivitar Experience™ Image Manager application. A ViviLink destination can be assigned to a photo or video in Capture mode prior to capturing your image or in Playback Mode.

  • Page 17: Led Light

    5. Your selected ViviLink destination appears as an icon on the LCD screen and your camera is now ready to capture your photo or video with the selected ViviLink destination. Note: The ViviLink feature is deactivated by default and needs to be activated prior to capturing each photo or video.

  • Page 18: Video Capture Mode

    Video Capture Mode The Video Capture Mode allows you to capture videos with your digital video camcorder. When the digital video camcorder is first powered ON, the camcorder will be in Video Capture Mode. TAKING A VIDEO 1. Selecting the Scene with the LCD Display: While in Video Capture mode, use the LCD display to direct the camcorder at the scene you would like to capture.
  • Page 19 VIDEO CAPTURE MODE QUICK FUNCTION BUTTONS Your digital camcorder has a four-directional pad that functions as Quick Function buttons. Button Function Delete Right Opens the Delete menu to the ‘Delete This Video?’ option Left No Function in Video Mode Light Exposure (-3.0EV ~ +3.0EV) EV + Up Increases the Light Exposure + Light Exposure (-3.0EV ~ +3.0EV)
  • Page 20 VIDEO CAPTURE MODE MENUS The following are the menus that appear in your digital video camcorder’s Video Capture Mode: Note:  The selection icons appearing above indicate the default setting.  Once you change a setting, the setting is saved by your camcorder until you manually change the setting or restore the default factory settings.
  • Page 21 Scene Menu The ‘Scene’ menu allows you to choose scene settings that allow your camcorder to adapt properly to your current environment. 1. Press the MENU button to open the menus for the current mode. 2. Press the LEFT or RIGHT button to scroll and select the ‘Scene’ menu. 3.
  • Page 22 ViviLink for Videos Menu The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying Vivitar Experience™ Image Manager application. 1. Press the MENU button to open the menus for the current mode.
  • Page 23 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection is displayed on the LCD screen. Note: The ‘None’ selected option does not appear with an icon. 7.
  • Page 24 2. Press the LEFT or RIGHT button to scroll and select the ‘White Balance’ menu. 3. Press the UP or DOWN button to highlight a specific option. 4. Press the SET button to confirm and select the highlighted menu option. selected option icon appears on the selected item.
  • Page 25 4. Press the SET button to confirm and select the highlighted menu option. selected option icon appears on the selected item. 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6.
  • Page 26 ISO Menu The ‘ISO’ menu allows you to set the level of sensitivity that your camcorder has to light in the surrounding environment. When the ISO level is increased, the image sensor in your camcorder will be more sensitive to light and allow you to capture images in lower-light situations.
  • Page 27 Spot – Meters the area within the spot point frame at the center of the LCD to set the exposure on the subject in the center of the monitor. 1. Press the MENU button to open the menus for the current mode. 2.
  • Page 28 Date/Time Menu When you capture an image with your camcorder, the image will include a time stamp with the date and time that the image was taken. The ‘Date/Time’ menu allows you to set your camcorder’s date and time as desired. You can also disable the timestamp for future images that will be taken with your camcorder.
  • Page 29 5. If you would like to exit the Date/Time menu without changing the settings, press the MODE button at any time to exit the menu and return to your previous screen. Auto Power Off Menu You can use the ‘Auto Power Off’ feature in order to conserve you camcorder’s battery life. The designated time represents when your digital video camcorder will automatically power off.
  • Page 30 selected option icon appears on the selected item. 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. TV Mode Menu The ‘TV Mode’...
  • Page 31  If you would like to delete individual images, use the Delete menu in the digital video camcorder’s Playback mode. 1. Press the MENU button to open the menus for the current mode. 2. Press the LEFT or RIGHT button to scroll and select the ‘Format Memory’ menu. 3.

  • Page 32: Video Playback Mode

    You will then automatically exit the menu and return to the previous mode with the camcorder settings set to the Factory Default Settings. Note: After RESETTING to the default settings, it is recommended to select your system Language, Date/Time and ViviLink for Photos and Videos. If you do not, the next time your camcorder is powered on, you will be prompted to define those settings.
  • Page 33 2. Playing Your Selected Video:  Press the Shutter button to START playing the video.  Press the Shutter button again to PAUSE the video and to continue playing and pausing as needed.  To fully STOP the video and restore the icons to the LCD, press the SET button. Note: While the video is playing all the icons on the top section of the LCD disappear.
  • Page 34 VIDEO PLAYBACK MODE QUICK FUNCTION BUTTONS Your digital camcorder has a four-directional pad that functions as Quick Function buttons. Button Function Displays the NEXT image Right Navigates in Thumbnail View Displays the PREVIOUS image Left Navigates in Thumbnail View Navigates in Thumbnail View Down Navigates in Thumbnail View STOPS Video Playback...
  • Page 35 VIDEO PLAYBACK MODE MENUS The following menu appears in your digital video camcorder’s Video Playback Mode: Delete Menu While in the Playback Mode, you can delete captured videos and photos from your camcorder through the ‘Delete’ menu. 1. Select the video you would like to delete. 2.
  • Page 36 ViviLink for Videos Menu The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying Vivitar Experience™ Image Manager application. 1. Select the video you to which you would like to add a ViviLink.
  • Page 37  Remember that the ViviLink feature is deactivated by default. A ViviLink destination will only be assigned to a photo or video if you manually set it from this menu or from the ViviLink menu in Capture mode (accessible from the ViviLink menu option in Capture mode). ...
  • Page 38 Press the MODE button at any time to exit the menu and return to your previous mode. Note:  Any image that is locked displays a lock symbol on the LCD screen when viewing that image in the Playback Mode. Videos that are not locked do not display the lock symbol. ...

  • Page 39: Photo Capture Mode

    Photo Capture Mode The Photo Capture mode allows you to capture pictures with your digital video camcorder. When the camera is first powered ON, the camera will be in Video Capture Mode. Press the MODE button once to access the Photo Capture Mode. TAKING A PICTURE 1.
  • Page 40 PHOTO CAPTURE MODE QUICK FUNCTION BUTTONS Your digital camcorder has a four-directional pad that functions as Quick Function buttons. Button Function Delete Right Opens the Delete menu to the ‘Delete This Photo?’ option Self-Timer Toggles between the Self-Timer Options: Left 2 seconds, 5 seconds, 10 seconds, Off Light Exposure (-3.0EV ~ +3.0EV) EV + Up...
  • Page 41 PHOTO CAPTURE MODE MENUS The following are the menus that appear in your digital video camcorder’s Photo Capture Mode:...
  • Page 42 Note:  The selection icons appearing above indicate the default setting.  Once you change a setting, the setting is saved by your camcorder until you manually change the setting or restore the default factory settings. Scene Menu The ‘Scene’ menu allows you to choose scene settings that allow your camcorder to adapt properly to your current environment.
  • Page 43 ViviLink for Photos Menu The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying Vivitar Experience™ Image Manager application. 1. Press the MENU button to open the menus for the current mode.
  • Page 44 4. Press the SET button to confirm and select the highlighted menu option. selected option icon appears on the selected item. 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6.
  • Page 45 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection is displayed on the LCD screen.
  • Page 46  Anti-Shake - Ensure that the Anti-Shake option is set to ‘On’. The Anti-Shake option is ‘On’ by default when you start using your camcorder and assists you in properly focusing the image.  Distance from the camcorder – The subject’s face must be no further than 8 to 9 feet (3.5 meters) from the camcorder and the face must cover at least 20% (1/5th) of the picture as seen on the LCD screen.
  • Page 47 4. Press the SET button to confirm and select the highlighted menu option. selected option icon appears on the selected item. 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6.
  • Page 48 4. Press the SET button to confirm and select the highlighted menu option. selected option icon appears on the selected item. 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6.
  • Page 49 If the environment has less light (darker) than is needed, increase the exposure setting (by using the positive + count) to increase the amount of light allowed into the lens by your camcorder. Note: The Light Exposure setting can also be quickly activated by simply pressing the UP (EV +) or DOWN (EV-) button while in Capture Mode.
  • Page 50 5. To continue within the menus and select a different menu option: Press the LEFT or RIGHT button to select the next menu item. 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection is displayed on the LCD screen.
  • Page 51 Language Menu You can select your digital video camcorder’s language setting by selecting the desired language from the ‘Language’ menu. 1. Press the MENU button to open the menus for the current mode. 2. Press the LEFT or RIGHT button to scroll and select the ‘Language’ menu. 3.
  • Page 52 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. An icon reflecting your selection is displayed on the LCD screen. To Set the Date and Time: 1. Highlight the ‘Date Setup’ menu option. 2.
  • Page 53 Auto Power Off Menu You can use the ‘Auto Power Off’ feature in order to conserve you camcorder’s battery life. The designated time represents when your digital camcorder will automatically power off. When the camcorder sits idle for the designated period of time, the camcorder will shut off completely and will need to be turned on again with the POWER button before the next use.
  • Page 54 6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. TV Mode Menu The ‘TV Mode’ menu allows you to select the TV option appropriate for you to view your captured images on your television.
  • Page 55 3. You are asked: “Are you sure you want to delete all media on the card?” 4. Press the UP or DOWN button to highlight the desired menu option: ‘Yes’ or ‘Cancel’. Press the UP or DOWN button to highlight a specific option: - CANCEL: To exit without formatting the SD Memory Card, select ‘Cancel’...

  • Page 56: Photo Playback Mode

    Photo Playback Mode The Playback Mode allows you to review and edit photos and videos that you’ve already taken with your camera.  When you first turn on the camera, the camera will be in Video Capture Mode by default. ...
  • Page 57 THUMBNAIL VIEW Press the Zoom lever down towards the W/Zoom Out to display your captured images in Thumbnail View. The images (videos and photos) on your camcorder will be displayed in a 3 X 3 matrix where you can scroll and select images from the thumbnails. 1.
  • Page 58 Other: T / Zoom In Zooms in to the selected photo. Zooms out of the selected photo. W / Zoom Out Opens the Thumbnail View Opens the Menu options for Playback Mode. MENU To navigate through the Menus, use the UP/DOWN/LEFT/RIGHT direction control buttons.
  • Page 59 Delete Menu While in the Playback Mode, you can delete captured videos and photos from your camcorder through the ‘Delete’ menu. 1. Select the photo you would like to delete. 2. Press the MENU button to open the menus for the current mode. 3.
  • Page 60 ViviLink for Photos Menu The ViviLink technology allows you to quickly and easily upload your camcorder’s photos and videos to the social networks of your choice with the accompanying Vivitar Experience™ Image Manager application. 1. Select the photo you to which you would like to add a ViviLink.
  • Page 61 5. Press the SET button to confirm and select the highlighted menu option. 6. The selected picture will now appear rotated as you have specified in the Playback mode as a new photo. Note: A locked/protected photo cannot be rotated. First unlock the photo, and then select the ‘Rotate’...
  • Page 62 Protect/Lock Menu Pictures and videos taken with your camcorder can be protected or “locked” to prevent any deletion or alteration being made to the files. 1. View the photo you would like to protect/lock. 2. Press the MENU button to open the menus for the current mode. 3.
  • Page 63 Print This Photo Menu You can use the ‘Print This Photo’ menu to print the photos that are on your digital camcorder directly to a Pictbridge compatible printer. 1. Scroll through your pictures and find the one you would like to print. 2.

  • Page 64: Connecting The Digital Camcorder To A Tv Or Hdtv

    6. To exit the menu view: Press the MODE button to exit the menu and return to your previous mode. 7. To activate the Slide Show: Press the SET button while viewing a photo in Playback Mode. Press the SET button again to stop the Slide Show. Connecting the Digital Camcorder to a TV or HDTV The digital camcorder has an AV/HDMI port to use your larger TV screen in place of the camcorder’s LCD screen.
  • Page 65 In the Video and Photo Capture Menus, use the TV Mode Menu to select the appropriate TV format. 4. When the digital video camcorder is set to Video or Photo Capture mode, you can preview what you would like to record on the TV screen and view the recording on the TV. 5.

  • Page 66: Installing The Software

    Installing the Software You must be connected to the Internet to install and run the Vivitar Experience™ Image Manager software. 1. Insert the installation CD into your CD-ROM drive. The installation screen should automatically open. 2. WINDOWS: The Vivitar Experience™ Image Manager Installer window appears. If the window does not appear, open the application’s CD/DVD drive and click on “Setup.exe”...
  • Page 67 12. MACINTOSH: Click the “Quit” button when the installation is complete. Click the “Launch Vivitar Experience™ Image Manager” to open the application. 13. If you close the application you can run the Vivitar Experience™ Image Manager from the Programs (WINDOWS) or Applications (MACINTOSH) menu on your computer.

  • Page 68: Connecting The Camcorder To The Computer

    Connecting the Camcorder to the Computer 1. Use the USB cable that came with your camcorder to connect your camcorder to your computer. 2. Power the camcorder ON. 3. The first time you connect the device to the computer you will have to wait a few seconds until the computer recognizes the device.

  • Page 69: Get Started

     Edit images using automatic and manual tools  Use automatic “Geotagging” with built in Google Maps For more details on how to use the Vivitar Experience Image Manager open the Help file or click the “Take a Tour” button on the application’s Home screen.

  • Page 70: Transferring Images From The Camera To The Computer Manually

    Transferring Images from the Camera to the Computer Manually TRANSFERRING PHOTOS AND VIDEOS: WINDOWS OS 1. Use the supplied USB cable to connect your camcorder to your computer. 2. ‘MSDC’ appears on the LCD. 3. A window appears with a list of options, select “Open folder to view files” and click OK. 4.

  • Page 71: Camcorder Maintenance

    TRANSFERRING PHOTOS AND VIDEOS: APPLE IPAD IMPORTANT: Please check your device packaging for compatibility with the iPad. Apple iPad Camcorder Connection: For models that are compatible with the iPad, photos and videos can be imported from your digital camcorder to your iPad by following either one of the options below: 1.

  • Page 72: Sakar Warranty Card

    Sakar Warranty Card This warranty covers for the original consumer purchaser only and is not transferable. Products that fail to function properly UNDER NORMAL USAGE, due to defects in material or workmanship will be repaired at no charge for parts or labor for a period of one year from the time of purchase.

  • Page 73: Technical Support

    Q: I deleted images using the Vivitar Experience Image Manager. The images were also deleted from my computer. How do I recover images that I accidently deleted? All images deleted using the Vivitar Experience Image Manager are sent to your computer’s...
