- Page 1 OWNER’S MANUAL PORTABLE AIR CONDITIONER Model: CH-PDH12AC1 CH-PDH14AC1 F or proper operation, please read and keep this manual carefully. Designed by Cooper&Hunter International Corporation, Oregon, USA www.cooperandhunter.com...
- Page 2 Read This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner. You'll find many answers to common problems in the chart of troubleshooting tips.
-
Page 3: Table Of Contents
CONTENTS SOCIABLE REMARK Sociable remark..........................2 SAFETY PRECAUTIONS Safety rules ............................3 Operating condition ...........................3 Electrical information .........................4 IDENTIFICATION OF PARTS Accessories ............................4 Names of parts...........................5 AIR CONDITIONER FEATURES Electronic control operating instructions ...................6 OPERATING INSTRUCTIONS Operating instructions ........................7 INSTALLATION INSTRUCTIONS Location ............................9 Window kit installation ........................9 Exhaust hose installation ........................12 Water drainage ..........................13... -
Page 4: Sociable Remark
SOCIABLE REMARK When using this air conditioner in the European countries, the following informa- tion must be followed: DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user. -
Page 5: Safety Precautions Safety Rules
SAFETY PRECAUTIONS Safety rules To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. Always do this Never do this Do not operate your air conditioner in a wet room such as a bathroom or laundry room. -
Page 6: Electrical Information
IDENTIFICATION OF PARTS WARNING For your safety Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any prong from the power cord. -
Page 7: Names Of Parts
IDENTIFICATION OF PARTS NAMES OF PARTS Front Operation panel Horizontal louver blade (swing automatically) Caster Carrying handle (both sides) Fig.1 Rear Upper air filter (Behind the grille) Upper air intake Air outlet Power plug socket (Use only when storing the unit) Drain outlet (only for Pump heating model) Power cord buckle (Used... -
Page 8: Air Conditioner Features
AIR CONDITIONER FEATURES ELECTRONIC CONTROL OPERATING INSTRUCTIONS Before you begin, thoroughly familiarize yourself with the control panel and remote controller and all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control panel alone or with the remote controller . NOTE: This manual does not include Remote Controller Operations, see the <<Remote Controller Instruction>>... -
Page 9: Operating Instructions Operating Instructions
OPERATING INSTRUCTIONS Error codes and protection code: HEAT operation (cooling only models without) E1- Room temperature sensor error- Press the "MODE" button until the "HEAT" Unplug the unit and plug it back in. indicator light comes on. If error repeats, call for service. Press the ADJUST buttons "+"... - Page 10 OPERATING INSTRUCTIONS SLEEP/ECO operation The system will automatically revert back to display the previous temper- Press this button, the selected temperature will ature setting if there is no operation increase(cooling) or decrease(heating) by in a five seconds period. C/2 F(or 1 F) 30 minutes.The temperature will - Turning the unit ON or OFF at any then increase (cooling) or decrease (heating) by time or adjusting the timer setting...
-
Page 11: Installation Instructions Location
INSTALLATION INSTRUCTIONS(optional) INSTALLATION INSTRUCTIONS Location The air conditioner should be placed on a firm foundation to minimize noise and virbration. For safe and secure positioning, place the unit on a smooth, level floor strong enough to support the unit. The unit has casters to aid placement, but it should only be rolled on smooth, flat surfaces. - Page 12 INSTALLATION INSTRUCTIONS(optional) Installation in a double-hung sash window Foam seal A (adhesive type) 1. Cut the foam seal(adhesive type) to the proper length and attach it to the window stool. Fig.8 2. Attach the window slider kit to the window stool. Adjust the Fig.8 length of the window slider kit according to the width of window, shorten the adjustable window kit if the width of...
- Page 13 INSTALLATION INSTRUCTIONS(optional) Installation in a sliding sash window 1. Cut the foam seal(adhesive type) to the proper length and Foam seal A (adhesive type) attach it to the window frame. See Fig.12. 2. Attach the window slider kit to the window stool. Adjust the length of the window slider kit according to the width of window, shorten the adjustable window kit if the width of Fig.12...
-
Page 14: Exhaust Hose Installation
INSTALLATION INSTRUCTIONS Exhaust hose installation: The exhaust hose and adaptor must be installed or removed in accordance with the usage mode. Fig.16a Fig.16b COOL,HEAT(heat pump type) or AUTO Install mode Hole seat Hole seat Hook FAN,DEHUMIDIIFY or HEAT(electrical heat type) Remove mode Hook... -
Page 15: Water Drainage
INSTALLATION INSTRUCTIONS Water drainage: Remove the upper drain plug During dehumidifying modes, remove the upper drain plug from the back of the unit, install the drain connector(5/8 universal female mender) with 3 4 hose(locally purchased). For the models without drain connector, just attach the drain Continuous √... -
Page 16: Care And Maintenance
CARE AND MAINTENANCE CARE AND MAINTENANCE Air filter (take out) IMPORTANT: 1) Be sure to unplug the unit before cleaning or servicing. 2) Do not use gasoline, thinner or other chemicals to clean Air filter the unit. (take out) 3) Do not wash the unit directly under a tap or using a hose. It may cause electrical danger. -
Page 17: Troubleshooting Tips
TROUBLESHOOTING TIPS TROUBLE SHOOTING TROUBLES POSSIBLE CAUSES SUGGEST REMEDIES 1. Unit does not - P1 appears in the display window Drain the water in the bottom tray. Start when Pressing on/off - Room temperature is lower than Reset the temperature. Button the set temperature.(Cooling mode) - The windows or doors in the room... - Page 18 www.cooperandhunter.us LIMITED WARRANTY STATEMENT PORTABLE AIR CONDITIONER This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________...
- Page 19 LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
