MULTI DUCTLESS INVERTER HEAT PUMP PANEL CASSETTE TYPE INDOOR UNIT INSTALLATION MANUAL Models: GKH(12)BA-D3DNA2A/I GKH(18)BA-D3DNA2A/I... -
Page 2: User Notice
User Notice ◆ When operating, the entire capacity of the cooperating indoor unit should be not larger than 150% of outdoor unit. Otherwise, it will cause the shortage of cooling (heating) capacity. ◆ A Breaker(or fuse) need to be installed in every indoor unit, and the capacity should in according with indoor unit’s electrical parameter;... -
Page 3: Table Of Contents
Thank you for choosing a C&H Multi Ductless Heat Pump! You can feel confident in your selection because the same pride incraftsmanship and engineering knowledge that goes into millions of other C&H installed products worldwide has gone into your unit. Please read this owner’s manual carefully before operationand retain it for future reference. -
Page 4: Safety Information
Safety Information 1 Safety Information Please read this manual carefully before use this unit, and operate it correctly according to the guide in this manual. Please take specially note to the meaning of these two marks: Warning!: This mark means that it may cause casualty or badly heart if the operation is incorrect. -
Page 5: Install Of The Compact Panel Cassette Type Indoor Unit
Wall Wall surface surface ≥59(1500) ≥59(1500) Model GKH(12)BA-D3DNA2A/I unit: in (mm) 10 (260) GKH(18)BA-D3DNA2A/I Ground surface Fig.1 2.2 Select install location of the indoor unit (1). Obstruct should put away from the intake or outlet vent of the indoor unit so that the airflow can be blown though all the room. -
Page 6: Important Notice
25in (650mm) 22in (570mm) 16in (400mm) Fig.2 Install dimension of mode (inches (mm)) GKH(12)BA-D3DNA2A/I,GKH(18)BA-D3DNA2A/I ◆ The drilling of holes in the ceiling must be done by the professional personnel. Installation stands for main body of the unit Ceiling Above 0.78in ( 20 mm) Fig.3... -
Page 7: Connection Of The Refrigerant Pipe
Install of The Compact Panel Cassette Type Indoor Unit ◆ Install the install cardboard on the unit by bolt (3 piece), and fix the angle of the drainage pipe at the outlet vent by bolt. (3). Adjust the unit to the suitable install place. (Refer to the fig.3) (4). -
Page 8: Drainage Hose
Install of The Compact Panel Cassette Type Indoor Unit Smear freeze motoroil here Median sponge (attachment) (entwine the wiring interface with seal mat) Thread fasten(x4) Torque wrench Heat preservation sheath of liquid inlet tube (attachment) (for liquid tube) Spanner Heat preservation sheath of gas collection tube (attachment)(for Gas collection tube... - Page 9 Install of The Compact Panel Cassette Type Indoor Unit Sponge(attachment) Clamp(attachment) Clamp Drain hose Sponge (gray) Below 0.17in ( 4mm ) Fig.7 Drain stepup pipe note ◆ The install height of the drain raising pipe should less than 11in (280mm). ◆...
-
Page 10: Electrical Wiring
Fig.12 Power cord standard recommending table Power Supply Min. Sectional Area of Min. Sectional Area of Model (V, Ph, Hz) Earth Wire(AWG) Power Cord(AWG) GKH(12)BA-D3DNA2A/I 208~203V-1Ph-60Hz UL1015 AWG 18*1 UL1015 AWG 18*3 GKH(18)BA-D3DNA2A/I 208~203V-1Ph-60Hz UL1015 AWG 18*1 UL1015 AWG 18*3... -
Page 11: Install The Panel
Install of The Compact Panel Cassette Type Indoor Unit 2.9 Install the panel (1). Set the panel to the indoor unit body by matching the position of the swing flap motor of the panel to the piping position of the panel to the piping position of the indoor unit as shown by fig.13. (2). - Page 12 Install of The Compact Panel Cassette Type Indoor Unit Air leak Air leak from ceiling Water condensatation, water drop Fig.14 ② . I f gap still exist between ceiling and decoration panel after tightening the screws, readjust the height of the indoor unit. (As shown in fig.15) If the raising lever and drain hose are not affect, can adjust the height of indoor unit by the hole on the corner...
-
Page 13: Constitutes And Names Of Parts Of Compact Panel Cassette Type Indoor Unit
Constitutes and Names of Parts of Compact Panel Cassette Type Indoor Unit 3 Constitutes and Names of Parts of Compact Panel Cassette Type Indoor Unit GKH(12)BA-D3DNA2A/I GKH(18)BA-D3DNA2A/I... -
Page 14: Working Temperature Range
Working Temperature Range 4 Working Temperature Range Working Temperature Range Indoor side state Outdoor side stae Wet bulb Dry bulb Dry bulb Wet bulb °F (°C) °F (°C) temp. °F (°C) °F (°C) temp. temp. temp. Rated Cooling 81(27) 66(19) 95(35) 75(24) Max. - Page 15 www.cooperandhunter.us MANUFACTURER: GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070...
