Page 1: Air Conditioning
VICTORIA HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM INSTALLATION MANUAL Models: GWH30LB-D3DNA5E(230V) GWH36LB-D3DNA5E(230V) - Page 2 GWH30LB-D3DNA5E(230V) System Includes: GWH30LB-D3DNA5E/I, GWH30LB-D3DNA3E/O GWH36LB-D3DNA5E(230V) System Includes: GWH36LB-D3DNA5E/I, GWH36LB-D3DNA3E/O...
- Page 3 Indicates a hazardous situation that, if not avoided, will result in death or serious injury. Indicates a hazardous situation that, if not avoided, could result in death or serious injury. Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. Indicates important but not hazard-related information, used to indicate risk of property damage.
-
Page 4: Table Of Contents
CONTENTS Installation service ■ Notices for installation................1 ■ Installation dimension diagram............3 ■ Install indoor unit................4 ■ Install outdoor unit................6 ■ Check after installation and test operation..........8 ■... -
Page 5: Installation Service Notices For Installation
Installation service- Notices for installation Important Notices 1. The unit installation work must be done by qualified personnel according to the local rules and this manual. 2. If the air conditioner has not plug, directly connect it into the fixed circuit, a breaker should be installed in the fixed circuit. - Page 6 Notices for installation Safety Requirements For Electric Appliances 1. The power supply should be used the rated voltage and AC exclusive circuit, the power cable diameter should be satisfied. Don't drag the power cable emphatically. It should be reliably earthed, and it should be connected to the special earth device, the installation work should be operated by the professional.
-
Page 7: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram Installation dimension diagram Space to the ceiling (15cm) Above 6in(15cm) Above 6in(15cm) Above Space to the wall Space to the wall 9.8ft 8.2ft (3m) (2.5m) Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ●... -
Page 8: Install Indoor Unit
Install indoor unit Install the rear panel 1.Always mount the rear panel horizontally. As the water drainage pipe at the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly high. 2. -
Page 9: Install The Indoor Unit
Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. The electric wiring must be correctly connected, wrong connection may cause spare parts ●... -
Page 10: Install Outdoor Unit
Install outdoor unit Electric Wiring 1. Disassemble handle of right side plate or front side plate of outdoor unit. 2. Take o wire clamp, connect and x power connect cord and power cord to terminal of line bank.Wiring should t that of indoor unit. 3. - Page 11 Install outdoor unit Indoor unit check point ● Leak hunting Use soap water or leak hunting meter to check whether the joints is leak. Outdoor unit check point Fig.6 Outdoor condensation drainage (Heat pump type only) When the unit is heating, the condensing water and defrosting water can be drained out reliably through the drain hose.
-
Page 12: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction The unit may drop, shake or emit noise. Has it been fixed firmly? It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? capacity. -
Page 13: Installation And Maintenance Of Healthy Filter
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. - Page 14 www.cooperandhunter.us PRODUCT & INSTALLATION RECORD For your convenience, please record the model and serial numbers of your new equipment in the spaces provided. This information, along with the installation data and dealer contact information, will be helpful should your system require maintenance or service. UNIT INFORMATION Model No.
