Summary of Contents for Interton CIC
- Page 1 User Guide Custom made Models: CIC, ITC, ITE Microphone-In-Helix (MIH) Interton Cosmo Interton Crisp Interton Share Interton Step...
- Page 2 Description of when to use Left serial number: Right serial number: Completely In the Canal (CIC) Note: Your hearing system might not support all 4 environmental programmes. Ask your hearing care professional for details. In The Canal (ITC) Instrument version:...
-
Page 3: Thank You
Becoming Accustomed to Amplification Thank you for selecting an Interton hearing system. We are proud of our hearing products and are confi- While purchasing a hearing system is a major step, it is only one step in a process toward more comfortable dent you have chosen one of the best products available. - Page 4 Hearing instrument type designations for models included in this user guide are: Hearing instrument uses and can radiate radio frequency energy and, if not installed and used in accordance with the in- type designations for models included in this user guide are: Model BO312, FCC ID: X26BO312, IC: structions, may cause harmful interference to radio communications.
-
Page 5: Intended Use
Intended use • The declaration of conformity may be consulted at www.resound.com • In US: FCC CFR 47 Part 15, subpart C. Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compen- • Other identified applicable international regulatory requirements in countries outside EU and US. Please sate for impaired hearing. -
Page 6: Table Of Contents
Contents Hearing Instrument(s) model and Inserting/removing hearing instruments . . . . . . . 20 Cleaning Custom made device . . . . . . . . . . . . 40 Warning to Hearing Aid Dispensers (US only) . - Page 7 Hearing instruments of type Hearing instruments of type ST230-DPW Hearing instruments of type Hearing instruments of type ST250-DPW BO13 are available in the fol- PH312 are available in the fol- ST230-DW BO312 are available in the fol- PH13 are available in the fol- ST250-DW lowing variants: lowing variants:...
- Page 8 Non wireless hearing instru- ST250-DP SR1330-P Push button (optional) ments are available in the fol- ST250-D SR1330-DP Battery compartment and On/Off lowing variants: ST250-P SR1230-P switch ST430-DP ST250 SR1230-DP Removal cord (optional) ST430-D SR1310 SR1130-P Sound outlet ST430-P SR1210 SR1350 Wax filter ST430 SR1110...
-
Page 9: Delayed Activation (Optional)
Getting started Delayed on-activation. This function will delay the time in which the hearing instruments turn on by several seconds after the battery compartment is closed. With Delayed on-activation, a beep will be heard for each On&Off function second of the delay period. When the battery door is closed, the hearing instrument turns on, and the default program will be activ ated. -
Page 10: Low Battery Indicator
Keep batteries away from pets, children and individuals who are mentally challenged. battery in the hearing instrument has depleted to a level at which use of the Interton TV Streamer TV and Do not attempt to dispose of batteries by burning them. Used batteries are harmful to the environ- Phone Clip cannot be supported, the hearing instrument will play two sets of descending tones. -
Page 11: Inserting/Removing Hearing Instruments
CAUTION Gently push the microphone into the creased area of the ear that is located Use only original Interton/GN Hearing consumables e.g. wax filters. above the microphone entrance, and make sure the tubing is in place. It may be helpful to pull your ear up and outward with your opposite hand during... - Page 12 1. Hold the edges of the hearing instrument with your thumb and forefinger. CAUTION 2. Pull outward while slightly rotating your hand forward. Use only original Interton/GN Hearing consumables e.g. wax filters. 3. Consult your hearing care professional if you have difficulties removing the hearing instrument.
-
Page 13: Volume Control (Optional)
If additional Applies only to Interton Share devices: Please note that when you turn the volume all the way down (until programmes have been activated, the following list ex- the volume control wheel stops rotating), the device will be turned off. -
Page 14: Flight Mode (Wireless Devices Only)
Flight mode. Only applicable to wireless devices* 2. You will then hear one or more beeps. The number of beeps indicates which programme you have selected (one beep = programme one, two beeps = programme two, etc.). 3. When the hearing instruments are turned off and then back on, the hearing instrument always returns WARNING to the default setting (programme one). -
Page 15: Telephone Use
Telephone use It is important to wait an additional 15 seconds after wireless function resumes before open ing and closing the battery compartment again for any reason. If the battery compartment is opened and closed Finding the optimal position for holding a telephone may require practice for some during this 15 second window, flight mode will resume. -
Page 16: Listen To Radio Or Tv
Listen to radio or TV AutoPhone (optional) When listening to the TV or the radio, start out by listening to news commentators since they usually speak The AutoPhone function, allows your hearing instrument to automatically switch to your tele phone pro- clearly, then try other programmes. -
Page 17: Autophone (Optional)
Placement of AutoPhone magnets AutoPhone usage Place AutoPhone magnet on your telephone receiver to allow operation of the Telephones can be used in a normal manner. A short melody will indicate that the AutoPhone feature has AutoPhone function. In order to place AutoPhone magnet properly: automatically switched the hearing instrument to your telephone programme. - Page 18 2. The AutoPhone may affect some medical devices or electronic systems. The manufacturer of any magnetically sensitive devices (e.g. pacemakers) should advise you regarding appropriate safety 2. Only use magnets supplied by Interton/GN Hearing. precautions when using your hearing instrument and magnet in close proximity to the medical device or electronic system in question.
-
Page 19: Tele-Loop Systems (Optional)
Telecoil (optional) Tele-loop systems (optional) If equipped, a telecoil can be activated by your hearing care professional and accessed through one of Many places, such as theatres, houses of worship, and schools are equipped with tele-loop systems. the additional programmes. A telecoil picks up a telephone’s magnetic signal and converts it to sound. An When using a telecoil programme with tele-loop systems, sound is picked up directly and may improve optional telephone programme may help to improve speech understanding on the telephone. -
Page 20: Care And Maintenance
Care and maintenance 6. If your instrument does get wet, or if it has been exposed to high humidity or perspiration, it should be left to dry out overnight with the battery out and the battery compartment open. It is also a good idea to put the instrument and battery in a sealed container together with a drying agent (desiccator) overnight. -
Page 21: Cleaning Custom Made Device
Cleaning custom made device Discard the used filter in the slot located in the wax filter kit by pressing it into the center, sliding it to one end of the slot, and pull until the filter is discarded. It is important to keep your hearing instrument clean and dry. -
Page 22: General Warnings
Only applicable to wireless devices For use of wireless functionality only use Interton/ GN Hearing accessories. For further guidance regarding e.g. pairing, please refer to the user guide of the relevant Interton/ GN Hearing accessory. CAUTION This device operates in the frequency range of 2.4 GHz - 2.48 GHz. - Page 23 CAUTION ments or to the hearing of the other individual. Only connect Interton hearing instruments to Interton/GN Hearing accessories intended and qualified to be Instrument usage by children or mentally challenged persons should be supervised at all times to used with Interton hearing instruments.
-
Page 24: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOM CAUSE POSSIBLE REMEDY PAGE IN THIS USER GUIDE No sound • Not turned on • Turn on by closing the battery door • Dead battery • Replace battery • Battery door will not close • Insert battery properly •... - Page 25 TROUBLESHOOTING GUIDE SYMPTOM CAUSE POSSIBLE REMEDY PAGE IN THIS USER GUIDE Not loud enough • Incorrect hearing instrument placement • Reinsert hearing instrument • Blocked sound outlet filter • Change filter or consult your hearing care professional • Change in hearing sensitivity •...
- Page 26 TROUBLESHOOTING GUIDE SYMPTOM CAUSE POSSIBLE REMEDY PAGE IN THIS USER GUIDE Excessive whistling / feedback • Incorrect hearing instrument placement • Re-insert hearing instrument carefully • Excessive ear wax • Consult your hearing care professional • Feedback control may need adjustment •...
- Page 27 TROUBLESHOOTING GUIDE SYMPTOM CAUSE POSSIBLE REMEDY PAGE IN THIS USER GUIDE Sound • Weak battery • Replace battery distorted / • Improper hearing instrument fit • Consult your hearing care professional not clear • Hearing instrument damaged • Consult your hearing care professional •...
-
Page 28: Technical Data
Technical Data Technical Data Maximum output Maximum output Hearing Instrument Model Battery size Hearing Instrument Model Battery size (2ccCoupler / IEC 60118-7) (2ccCoupler / IEC 60118-7) CI310, CI210, SR1310, SR1210, SR1110, C650-MW, C450-MW 112 dB SPL (typical) 112 dB SPL (typical) ST410, ST210 C630-MW, C430-MW 112 dB SPL (typical) - Page 29 Technical Data Technical Data Maximum output Maximum output Hearing Instrument Model Battery size Hearing Instrument Model Battery size (2ccCoupler / IEC 60118-7) (2ccCoupler / IEC 60118-7) ST430, ST430-D, ST230, ST230-D 114 dB SPL (typical) CI330, CI330-D, CI230, CI230-D, CI330-W, CI330-DW, CI230-W, CI230-DW, SR1330, 114 dB SPL (typical) ST430-P, ST430-DP, ST230-P, ST230-DP 118 dB SPL (typical)
- Page 30 Technical Data Technical Data Maximum output Maximum output Hearing Instrument Model Battery size Hearing Instrument Model Battery size (2ccCoupler / IEC 60118-7) (2ccCoupler / IEC 60118-7) ST450, ST450-D, ST250, ST250-D 118 dB SPL (typical) CI350, CI350-D, CI350-W, CI350-DW, CI250, CI250-D, CI250-W, CI250-DW, SR1350, 117 dB SPL (typical) ST450-P, ST450-DP, ST250-P, ST250-DP 130 dB SPL (typical)
-
Page 31: Warranty And Repairs
-25° C (-13F) and +70° C (+158F) according to internal and industry standards. As a signatory to the United Nations Global Compact initiative, Interton is committed to doing this in line with environment-friendly best practices. Hearing instruments therefore, at Interton’s discretion, may be During transport or storage, the temperature should not exceed the limit values of -20°... -
Page 32: Hearing Instrument Expectations
Hearing instrument expectations (iii) History of sudden or rapidly progressive hearing loss within the previous 90 days. (iv) Acute or chronic dizziness.(v) Unilateral hearing loss of sudden or recent onset within the previous A hearing aid will not restore normal hearing and will not prevent or improve a hearing impairment resulting 90 days.(vi) Audiometric air-bone gap equal to or greater than 15 decibels at 500 hertz (Hz), 1,000 from organic conditions Hz, and 2,000 Hz. -
Page 33: Children With Hearing Loss (Us Only)
physician will refer you to an audiologist or a hearing aid dispenser, as appropriate, for a hearing aid evalu- development and the educational and social growth of a child. An audiologist is qualified by training and ation. The audiologist or hearing aid dispenser will conduct a hearing aid evaluation to assess your ability experience to assist in the evaluation and rehabilitation of a child with hearing loss. - Page 34 Equipment includes RF transmitter. Faceplate/Electronics by: Interton A/S. Any issues relating to the EU Medical Device Directive 93/42/EEC, or Council Directive 1999/5/EC on 0297 Radio Equipment and Telecommunications terminal equipment should be directed to Interton A/S.
- Page 35 Worldwide headquarters Interton A/S | Lautrupbjerg 7 | DK-2750 Ballerup | Denmark Tel.: +45 45 75 1111 | Fax: +45 45 75 1119 | www.interton.com | CVR no. 55082715...
