JBL SCS150SI Owner's Manual

Surround cinema speakers
Hide thumbs Also See for SCS150SI:

Advertisement

Table of Contents

See also: Service Manual
S P E C I F I C A T I O N S
SCS150 System
Frequency Response
30Hz – 20kHz (–6dB)
Satellites
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
88dB @ 1 watt/1 meter
Tweeter
One 1/2" titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
8-1/8" x 3-1/2" x 3-7/8"
206mm x 89mm x 99mm
Weight
2.65 lb/1.2kg
All features and specifications are subject to change without notice.
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
O W N E R ' S G U I D E
P R O D U C T L I N E :
Surround Cinema Speakers
M O D E L
SCS150
N U M B E R :
D E S I G N G O A L : Bring the thrill of live performance and movie sound to
the home environment by calling on JBL's professional engineering leadership.
S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure
S U B W O O F E R T Y P E : Bass-reflex enclosure
P O R T D E S I G N : FreeFlow™ flared
P R O F E S S I O N A L R E F E R E N C E : Cinema Loudspeaker Series
Center
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
88dB @ 1 watt/1 meter
Tweeter
One 1/2" titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
3-1/2" x 8-1/8" x 3-7/8"
89mm x 206mm x 99mm
Weight
2.65 lb/1.2kg
Subwoofer
Amplifier
150 watts RMS
Woofer
10"
Enclosure
Bass reflex
Dimensions (H x W x D)
17-3/4" x 15-3/4" x 16-3/4"
451mm x 400mm x 426mm
Weight
35 lb/15.9kg
P R O S O U N D
C O M E S H O M E
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No. ai5139
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCS150SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JBL SCS150SI

Summary of Contents for JBL SCS150SI

  • Page 1 D E S I G N G O A L : Bring the thrill of live performance and movie sound to the home environment by calling on JBL’s professional engineering leadership. S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure S U B W O O F E R T Y P E : Bass-reflex enclosure P O R T D E S I G N : FreeFlow™...
  • Page 2 D E S I G N G O A L : Bring the thrill of live performance and movie sound to the home environment by calling on JBL’s professional engineering leadership. S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure S U B W O O F E R T Y P E : Bass-reflex enclosure P O R T D E S I G N : FreeFlow™...

  • Page 3: R E A D T H I S

    R E A D T H I S ! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not remove the grounding plug on the power cord, or use any plug or extension cord that does not have a grounding plug provided.
  • Page 4 T H A N K Y O U F O R C H O O S I N G J B L For more than 50 years, JBL has been involved in every aspect of music and film recording and reproduction,...

  • Page 5: Speaker Placement

    S P E A K E R P L A C E M E N T Front Speakers Surround Speakers The front speakers should be placed the same distance from each other as they are from the listening position. They should be placed at about the same height from the floor as the listeners’...

  • Page 6: Mounting Options

    M O U N T I N G O P T I O N S Satellites and Surrounds On shelves. Wall-Mounting Attach plate to wall. The brackets should be placed, if possible, so that the screws will fasten into a wooden wall stud.

  • Page 7: Speaker Connections

    Speakers and electronics terminals have corresponding (+) and (–) terminals. Most manu- facturers of speakers and electronics, including JBL, use red to denote the (+) terminal and black for the (–) terminal. The (+) lead of the speaker wire is noted with a stripe.

  • Page 8: Dolby Pro Logic

    Dolby Pro Logic (Non-Digital) – Speaker Level Use this installation method for Dolby Pro Logic appli- cations (not Dolby Digital, ® or other digital processing), where the receiver/processor does not have a subwoofer output, or a volume-controlled preamp (line-) level output: Connect your receiver or amplifier’s front left and right speaker terminals to the left...

  • Page 9: Dolby Pro Logic (Non-Digital) - Line Level

    Dolby Pro Logic (Non-Digital) – Line Level Use this installation method for Dolby Pro Logic appli- cations (not Dolby Digital, DTS or other digital processing), where the receiver/processor is equipped with a subwoofer output, or a volume-controlled preamp (line-) level output: –...

  • Page 10: Operation

    HIGH LEVEL LINE LEVEL IN – – IMPORTANT: CONNECT STRIPED WIRE TO RED ( ) SPEAKER TERMINAL. SUB 150 JBL, Incorporated A Harman International Company This area is designed to become quite warm during normal operation CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS : RISQUE DE CHOC ÉLECTRIQUE-NE PAS OUVRIR...

  • Page 11: Troubleshooting

    Web site at www.jbl.com for further information. If there is no sound from the center speaker: • Check all wires and...
  • Page 12 • In Dolby Digital or DTS modes, make sure your receiver/processor is configured so that the sub- woofer and LFE output are enabled. If there is no sound from the surround speakers: • Check all wires and con- nections between receiver/ amplifier and speakers.
