Properties
• expands the home network over the electrical
wiring—immediately ready for operation
• with internal socket - no power outlets blocked
for use
• Internet connection "out of the box": FRITZ!Box
and FRITZ!Powerline are a perfect match
• robust data transmission through the latest
500-Mbit/s powerline technology
• low consumption and power saving standby
operation
• compatible with IEEE P1901
• clear, self-explanatory user interface for simple
operation
avm.de/en
© AVM GmbH · Alt-Moabit 95 · 10559 Berlin · Germany
Customer Service
• Manual
avm.de/en/service/manuals
• User Interface
avm.de/en/powerline
• Support
avm.de/en/service/support
Disposal Information
In accordance with the Electrical and Electronic
Equipment Act, the FRITZ!Powerline 530E and
cable may not be disposed with household waste.
Please bring these to your local collection points for
disposal.
Installation and
Installation and
Operation
Operation
FRITZ!Powerline
530E
