You have chosen a modern surveillance camera with excellent technical equipment and
Please study all notices carefully and diligently. Please study this information in detail observing, in particular, the safety
instructions. The device comes with a 3-year warranty. In case of a defect in the surveillance camera
you require the enclosed warranty card and proof of purchase. Keep these in a safe place together with the Instruction
Manual. Please include the Instruction Manual when passing the camera on to a third party.

1. Contents of box

Carefully unpack the surveillance camera and check that all parts listed below are present:
1. IP Surveillance camera ROLLEI SafetyCam 20 HD
2. PoE adapter
3. Wall fixing
4. 2x LAN cables
5. Aerial
6. Software CD
7. Instruction manual
8. Warranty documents
Note:
•
Caution! Keep plastic foil and bags away from babies and small children as danger of suffocation.
RCP Technik GmbH & Co. KG, Tarpen 40/Gebäude 7b, D-22419 Hamburg
Dear customer,
Congratulations on purchasing a high-quality ROLLEI product.
respective accessory, which is particularly easy to operate.
Hotline: +49 (0)6 31/3 42 84 49
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the safetycam 20 hd and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rollei safetycam 20 hd

Summary of Contents for Rollei safetycam 20 hd

  • Page 1: Contents Of Box

    Manual. Please include the Instruction Manual when passing the camera on to a third party. 1. Contents of box Carefully unpack the surveillance camera and check that all parts listed below are present: 1. IP Surveillance camera ROLLEI SafetyCam 20 HD 2. PoE adapter 3. Wall fixing 4.

  • Page 2: Table Of Contents

    INSTALLATION OF SURVEILLANCE CAMERA 5.1. Hardware installation 5.2. System requirements 5.3. Software installation 5.4. Cloud installation “Rollei Cloud” 5.5. Manual set up of surveillance camera 5.6. Setting up the router 5.7. Setting up the domain name 5.8. Setting up an app 5.9.
  • Page 3 USE OF SURVEILLANCE CAMERA 7.1. Activating the surveillance camera 7.2. Controlling the surveillance camera SETTINGS 8.1. Device status 8.2. Camera name 8.3. Date and time 8.4. User account 8.5. Network settings 8.6. Wireless settings 8.7. UPNP settings 8.8. DDNS settings 8.9.

  • Page 4: Hazard, Safety And Warning Notices

    3. Hazard, safety and warning notices Incorrect use of the surveillance camera and accessories can be dangerous for you and others and can damage or destroy the surveillance camera. We therefore ask you to read and strictly observe the following Hazard, safety and warning notices. Intended use „...
  • Page 5 sary. Disconnect from mains only by pulling out plug from mains socket. „ Ensure adequate ventilation and do not cover power supply to prevent overheating. „ The power supply may not be used during athunderstorm. Otherwise danger of electrocution. Damage from heat – fire hazard „...

  • Page 6: Preparation

    4. Preparation 4.1. Part names 1. IP Surveillance camera ROLLEI SafetyCam 20 HD 6. Assembly material (not shown) 2. Wall fixing 7. Software CD (not shown) 3. 2x LAN cables 8. Operating Instructions (not shown) 4. PoE adapter 9. Warranty documents (not shown) 5.

  • Page 7: Views Of Surveillance Camera

    4.2. Views of surveillance camera 1. Lens 5. Network connection (LAN) and PoE 2. Infrared LEDs 6. Wall fixing 3. Sensor 7. Reset button 4. WLAN aerial 8. Aerial connection RCP Technik GmbH & Co. KG, Tarpen 40/Gebäude 7b, D-22419 Hamburg Hotline: +49 (0)6 31/3 42 84 49...

  • Page 8: Assembly Of Surveillance Camera

    4.3. Assembly of surveillance camera Using the supplied wall fixing, the surveillance camera can be installed at a fixed location. Note: • Do not place surveillance camera directly next to electronic devices as this could produce interference. In case of picture interference, test camera at another location.

  • Page 9: Installation Of Surveillance Camera

    • For this purpose deactivate all networks existing on your computer and plug the network cable of the surveillance camera directly into the computer. You can also access the surveillance camera via the program Rollei SafetyCam Config (see section 5.4).

  • Page 10: System Requirements

    Place supplied software CD into CD/DVD drive of your computer. The below selection menu should then appear automatically. If the menu does not start automatically, select drives from your computer and open the CD/DVD drive named “Rollei IP Camera” by clicking on it with the mouse. Start program by double clicking on CDMenu/CDMenu.exe.

  • Page 11: Cloud Installation "Rollei Cloud

    Your Rollei SafetyCam20 HD has been set up for simple camera installation. For this purpose we have provided a Cloud soluti- on that can be quickly and easily set up. After installation you can at any time access the camera directly via the “Rollei Cloud”.
  • Page 12 2. Select “Rollei SafetyCam 20 HD“ as camera model and click on “OK”. This calls up the existing settings of the camera. 3. In order to set up the camera for use via Rollei Cloud, select the third option “Camera with Rollei Cloud during the next step (recommended)“.
  • Page 13 6. Now enter the registration data for logging on to Rollei Cloud. Select any user name and a password consisting of at least 8 characters. Also enter a valid email address. Note down this log-on information. 7. The last step repeats again the implemented settings.
  • Page 14 5.4.2 Select “Rollei Cloud” Next open the start page of Rollei Cloud. in the Internet Browser using link http://rollei-cloud.de or http://rollei-cloud.com Enter user name specified in the Set-up assistant. The overview now lists all products of your IP camera. Select these to call up your camera.
  • Page 15 Rollei SafetyCam20 HD. 5.4.4. Use of the App The app “Rollei SafetyCam“ is available for your camera from the App Store and from Google Play. Load the App onto a Smartphone or a TabletPC and start App.

  • Page 16: Manual Set Up Of Surveillance Camera

    5.5. Manual set up of surveillance camera In the subsequent graphics it is schematically shown how the surveillance camera is integrated in your existing home network and how it is accessed from the Internet. Therouter is central to this operation. The router is the connection between your home network and the Internet. The router is thus connected to two networks at the same time, the Internet and your home network.
  • Page 17 As the router is, however, protected from Internet access via so-called Firewall a separate access must be set up for the sur- veillance camera. This is referred to as Port forwarding. The following installation steps are required to set up the surveillance camera in the home network and via the Internet: 1.
  • Page 18 Ensure that the surveillance camera is connected to the router via the network cable and is connected to the mains (see section 5.1., Hardware Installation). A network connection between the computer and the router must also exist. Open the program Rollei SafetyCam Config. In the program select ”Start search“, to open a list of available surveillance cameras.
  • Page 19 The viewing window of the surveillance camera is displayed. At the bottom of the window change to “Settings“ and then to ”Wireless settings“ Select the region in which the surveillance camera will be used from the “Region” option. RCP Technik GmbH & Co. KG, Tarpen 40/Gebäude 7b, D-22419 Hamburg Hotline: +49 (0)6 31/3 42 84 49...

  • Page 20: Setting Up The Router

    You can now remove the network cable between the surveillance camera and the router. Do, however, note that the surveil- lance camera has a different local address through the wireless connection than when connected via the network cable. Once restarted, the surveillance camera must be searched for using the program Rollei SafetyCam Config and opened through “Browser“ .
  • Page 21 First start the configuration program of your router. For this you require the local network address of your router. You can check the local network connection by searching for the surveillance camera in the program Rollei SafetyCam Config and then displaying the network settings using option “Address“.
  • Page 22 In order to avoid problems the same internal and external port of the surveillance camera should be chosen. Activate the surveillance camera again using the program “Rollei SafetyCam Config”. Under “Settings” change to “Network settings” and change the value under “Port” also to 81. Save the changes.

  • Page 23: Setting Up The Domain Name

    5.7. Setting up the domain name On the Internet, the surveillance camera can be accessed through the public IP address of the router. As in many cases the public IP address of the Internet access changes constantly, it is advantageous if the surveillance camera can be accessed via a fixed address.

  • Page 24: Setting Up An App

    5.8. Setting up an app The app “Rollei SafetyCam“ sis a program for accessing the IP surveillance camera from your iPhone or Android Smartphone. The App can be downloaded free of charge from the ”App Store“ and also from “Google Play“.

  • Page 25: Installation On Mac Os

    Next, you require the IP address of the surveillance camera from the settings data of the router. The configuration page of the SafetyCam 20 HD can be opened with this address and settings of the surveillance camera can be entered.
  • Page 26 Change to page “TCP/IP“ where you find the IP address of your router under “Router”. The address in the below example is 192.168.16.1. RCP Technik GmbH & Co. KG, Tarpen 40/Gebäude 7b, D-22419 Hamburg Hotline: +49 (0)6 31/3 42 84 49...
  • Page 27 Determine the IP address of the surveillance camera Open Internet Browser “Safari“ and enter the previously determined IP address of the router. The configuration page of the router opens. Generally an option “DHCP table“ or “DHCP reservation“, can be found under Settings, which can be called up. You then receive a list of all devices in the network as shown in the below example.

  • Page 28: Installation Tips

    Check the wireless settings and in particular the entered code. All WLAN channels may not be enabled. Adjust the “Region” setting when entering the Wireless settings. You router may allocate changing local IP addresses each time it connects. Search for the camera again using Rollei Safety- Cam Config.
  • Page 29 Camera can be reached locally but not through the Internet. This generally always occurs when Port forwarding is not or is incorrectly set up in the router. read section 5.6., Setting up the Router, and information contained on Internet page: http://www.safetycam-info.com. Internet connection via 3G/4G mobile phone networks.

  • Page 30: The Program Rollei Safetycam Config

    6. The program Rollei SafetyCam Config Below we have provided a detailed description of the program Rollei SafetyCam Config, as installed in section 5.3., Software Installation. Ensure that the surveillance camera is connected to the router via the network cable and is connected to the mains (see section 5.1., Hardware Installation).
  • Page 31 The default user account is ”admin“ without password. To call up a surveillance camera from the camera list Rollei SafetyCam Config in the Browser window, click on “Browser“ in the menu. This opens the standard browser with the log-in page of the camera. You can then either call up the camera image or enter further settings for the camera.

  • Page 32: Use Of Surveillance Camera

    7. Use of surveillance camera 7.1. Activating the surveillance camera First open your Browser program (Internet Explorer, Firefox, Opera, Google Chrome, Safari or similar). Next to it is the local IP address of the surveillance camera. If you wish to access a surveillance camera from a computer in the same network, you can also enter the local network address at this point.

  • Page 33: Controlling The Surveillance Camera

    7.2. Controlling the surveillance camera Various elements and options are available for controlling the surveillance camera. Some basic camera settings are shown below the camera image. The operating elements available and settings that can be changed depend on the authority of the user account.

  • Page 34: Settings

    8. Settings The below sections provide an overview of all possible options of the surveillance camera. In case of problems during the installation or use or changing of the settings of the surveillance camera, these sections contain information outlining the available options.

  • Page 35: Camera Name

    8.2. Camera name You can assign a name to the surveillance camera in order to for instance make it easier to find in the network or to allow a clear assignment where several surveillance cameras are used. Select 2nd symbol “Camera name” from the below menu. Enter the desired name for the surveillance camera in the text field and click on “Save”.

  • Page 36: Date And Time

    8.3. Date and time Set the time zone of the surveillance camera and whether date and time should be automatically updated via a so-called NTP server (Time server). The correct time is, for instance, required for planning alarms or FTP transfers. 1.

  • Page 37: User Account

    8.4. User account You can set up anything up to 8 user accounts for the surveillance camera. The surveillance camera is then accessed via these user accounts. The surveillance camera is shipped with the user account “admin”, not requiring a password. This account can neither be removed nor can the authority “Administrator”...

  • Page 38: Network Settings

    8.5. Network settings In order to connect the surveillance camera to an existing network or a router, network settings must be entered. Use DHCP:If your network allows automatic addition of a new device (Client). select this option. All required data are obtained directly from the server or router.
  • Page 39 Where automatic acceptance of new devices is not sup- ported by your router, please deselect “Use DHCP“. Several ne input fields appear. Manually enter the access data of your network. The required data can generally be called up from the computer via the network properties or can be obtained from the System Administrator of the network.

  • Page 40: Wireless Settings

    8.6. Wireless settings If the surveillance camera is to be connected to a network using the wireless option W-LAN (Wireless LAN), the required settings can be entered under this option. Select option “Wireless settings” from the bottom of the menu. „...
  • Page 41 „ Region: Depending on the region, W-LAN does not support various channels. Select the region in which the surveillance camera will be used from the “Region” option. „ Encoding:Data in wireless networks are in most cases transmitted encoded to prevent third-party access. State what type of encoding is used in your W-LAN network.

  • Page 42: Upnp Settings

    Note: • These settings are only of importance where manual installation was selected. When using Rollei Cloud, no further settings have to be entered. Universal Plug and Play (UPnP) is used for controlling devices via an IP-based network. Where the router supports UPnP and where this function is activated, the required Firewall settings are automatically selected.

  • Page 43: Ddns Settings

    Note: • These settings are only of importance where manual installation was selected. When using Rollei Cloud, no further settings have to be entered. On the Internet, the surveillance camera can be accessed through the IP address of the router or server. As in many cases the public IP address of the Internet access changes constantly, it is advantageous if the surveillance camera can be accessed via a fixed address.
  • Page 44 First, enter a user name. This may only consist of small and capital letters, numbers or a hyphen. The user name is used for the Internet address of the surveillance camera. Enter, for instance, the user name “ipcamera“ and, after registration, the surveillance camera can be called up via address http:// ipcamera.rolleicam.net as soon as it is connected to the Internet.

  • Page 45: Mail Settings

    8.9. Mail settings In certain circumstances, the surveillance camera can send out a alarm message by email. For this purpose an email account must be specified from which emails will be sent out. A private email address can, for instance, be used or you can set up a separate email address for the surveillance camera.
  • Page 46 „ Server: Enter address of SMTP server of Email account. „ Port: Enter port of SMTP server. The standard value is 25. „ Encoding:State the encoding used by the SMTP server. „ Requires authentication: State whether the SMTP server requires authentication. If yes, mark this option and state the user name and password of the email account.

  • Page 47: Ftp Settings

    8.10. FTP settings The surveillance camera offers the option to upload images to an FTP server once or regularly. Specify the required additional data for an FTP server to be used. Select option “FTP settings” from the bottom of the menu and select “Use FT”. Activate “Use FTP “, if images of the surveillance camera are to be uploaded to an FTP server.

  • Page 48: Alarm Settings

    „ Interval (seconds): Specify at what intervals an image is to be taken and transferred. Values are in seconds. „ Enter file name: Select this option if you wish to specify a file name. If this option has not been selected, a predefined file name will be used when saving the images.

  • Page 49: Resetting

    „ Use time schedule: You can restrict the period of time during which alarms can be triggered. As soon as this option is selected, the adjacent time schedule appears, in which the active times can be selected. Select the times during which the alarm settings should be active.

  • Page 50: Restarting The Camera

    8.13. Restarting the camera Click on “Restart now” to restart the surveillance camera. This saves all entered settings. Resetting takes 2 minutes. Wait until the Browser window shows the logging on option again. Note: • If the network settings have been changed, the surveillance camera may no longer be attainable under the current address.

  • Page 51: Potential Legal Infringements

    10. Potential legal infringements Observe the following information for using the IP surveillance camera: Copyright Generally every person owns his/her own image. According to the copyright law, images may only be published without the consent of the respective person if the person appears only as a person embellishment to a landscape image, or a location as a public place.

  • Page 52: License Declaration

    Duty of notification Where a personal identification of persons cannot be excluded, a clearly visible notice concerning the surveillance camera must be erected at all accesses to the monitored area. Passers-by must also be informed that by entering the monitored area they give their permission to pictures/videos being taken so that if they do not wish to give their consent they can avoid the picture/video being taken by not accessing the area.

  • Page 53: Conformity

    The device comes with a 3-year manufacturer’s warranty. Please see the enclosed Warranty Card for details. Please contact our hotline prior to returning a defective device. Service address: Manufacturer's address: Rollei Service Germany RCP Technik GmbH & Co. KG Denisstr. 28A Tarpen 40/Gebäude 7b...

  • Page 54: Technical Specification

    15. Technical specification Model SafetyCam 20 HD Image sensor 1/5“ Megapixels CMOS sensor, 1280 x 720 pixels Lens F=2.4, f=3.6 mm, Infrared lens Infrared light 24 Infrared LEDs Night vision 20 m Minimum lighting 0.5 Lux (w/o LEDs) angle of view 60°...

  • Page 55: Index

    16. Index Accessories 1 Encoding 20, 41 Address 30 Administrator 33, 37 Firewall 17 Alarm message 45 Firmware 31 Alarm settings 48 FTP settings 47 Alarm terminals 6 angle of view 54 App 15 Hardware installation 9 App for Smartphones 24 Hazard information 4 Assembly 8 Image sensor 54...
  • Page 56 Network settings 38 Time zone 36 NTP Server 36 UPNP 42 Operator 33, 37 User 33 User account 37 User data 2 Port 22, 30, 38 Port forwarding 17, 21 Protocols 54 Visitor 37 Region 41 Wall fixing 6, 8 Resetting 49 Warning notices 4 Resolution 33...
