  • Page 1 SafetyCam-10 HD User Guide in English www.rollei.com...

  • Page 3: Contents Of Box

    7. Instruction manual 8. Warranty documents Note: • Caution! Keep plastic foil and bags away from babies and small children as danger of suffocation. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 4: Table Of Contents

    5.7. Setting up the domain name 5.8. Setting up an app 5.9. Installation on Mac OS X. 5.10. Installation tips THE PROGRAM ROLLEI SAFETYCAM CONFIG Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 5 8.13. Resetting 8.14. Restarting the camera POTENTIAL LEGAL INFRINGEMENTS 10. LICENSE DECLARATION 11. CONFORMITY 12. DISPOSAL 13. WARRANTY AND SERVICE 14. TECHNICAL SPECIFICATION 15. INDEX Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 6: Hazard, Safety And Warning Notices

    „ When the camera has been dropped or the housing is damaged , switch off camera. Otherwise danger of fire or electrocution „ The camera and its components may not be taken apart, modified or repaired. Danger of fire and electrocution. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 7 „ Damage to the electronics, lens or accessory caused by external influences such as impacts, falls or others are not covered by the warranty and are chargeable. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 8: Preparation

    7. Software CD (not shown) 3. LAN cable 8. Operating Instructions (not shown) 4. Mains adapter 9. Warranty documents (not shown) 5. Alarm terminals Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 9: Views Of Surveillance Camera

    10. Reset button 5. WLAN aerial 11. Microphone 6. Audio connection (no function) Note: • The focus ring (4) allows setting of the camera focus. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 10: Assembly Of Surveillance Camera

    Align the surveillance camera as desired. 4.3.3. Complete camera assembly Connect the supplied mains unit first into the surveillance camera and then into the socket Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 11: Installation Of Surveillance Camera

    • For this purpose deactivate all networks existing on your computer and plug the network cable of the surveillance camera directly into the computer. You can also access the surveillance camera via the program Rollei SafetyCam Config (see section 5.4).

  • Page 12: System Requirements

    Place supplied software CD into CD/DVD drive of your computer. The below selection menu should then appear automatically. If the menu does not start automatically, select drives from your computer and open the CD/DVD drive named “Rollei IP Camera” by clicking on it with the mouse. Start program by double clicking on CDMenu/CDMenu.exe.

  • Page 13: Cloud Installation "Rollei Cloud

    Your Rollei SafetyCam10 HD has been set up for simple camera installation. For this purpose we have provided a Cloud soluti- on that can be quickly and easily set up. After installation you can at any time access the camera directly via the “Rollei Cloud”.
  • Page 14 2. Select “Rollei SafetyCam 10 HD“ as camera model and click on “OK”. This calls up the existing settings of the camera. 3. In order to set up the camera for use via Rollei Cloud, select the third option “Camera with Rollei Cloud during the next step (recommended)“.
  • Page 15 6. Now enter the registration data for logging on to Rollei Cloud. Select any user name and a password consisting of at least 8 characters. Also enter a valid email address. Note down this log-on information. 7. The last step repeats again the implemented settings.
  • Page 16 5.4.2 Select “Rollei Cloud” Next open the start page of Rollei Cloud. in the Internet Browser using link http://rollei-cloud.de or http://rollei-cloud.com Enter user name specified in the Set-up assistant. The overview now lists all products of your IP camera. Select these to call up your camera.
  • Page 17 Rollei SafetyCam10 HD. 5.4.4. Use of the App The app “Rollei SafetyCam“ is available for your camera from the App Store and from Google Play. Load the App onto a Smartphone or a TabletPC and start App.

  • Page 18: Manual Set Up Of Surveillance Camera

    The IP surveillance camera is directly connected to the router, either via a network cable or wireless via WLAN. This allows access to the surveillance camera from the home network and the Internet. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 19 8. The standard set-up of the surveillance camera is described from section 5.4. onwards. Further information relating to the use and settings are provided from chapter 7 onwards. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 20 Internet browser. Select the desired language and then enter the following in the text window: User name: admin Password: Leave empty Click on “Log on”. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 21 At the bottom of the window change to “Settings“ and then to ” Wireless settings“ Select the region in which the surveillance camera will be used from the “Region” option. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 22: Setting Up The Router

    You can now remove the network cable between the surveillance camera and the router. Do, however, note that the surveil- lance camera has a different local address through the wireless connection than when connected via the network cable. Once restarted, the surveillance camera must be searched for using the program Rollei SafetyCam Config and opened through “Browser“ .
  • Page 23 First start the configuration program of your router. For this you require the local network address of your router. You can check the local network connection by searching for the surveillance camera in the program Rollei SafetyCam Config and then displaying the network settings using option “Address“.
  • Page 24 In order to avoid problems the same internal and external port of the surveillance camera should be chosen. Activate the surveillance camera again using the program “Rollei SafetyCam Config”. Under “Settings” change to “Network settings” and change the value under “Port” also to 81. Save the changes.

  • Page 25: Setting Up The Domain Name

    Click on “Apply“, to accept the changed settings. Next, restart the surveillance camera to accept the changes. This operation takes around another 2 minutes. The surveillance camera is now reachable under the registered address. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 26: Setting Up An App

    5.8. Setting up an app The app “Rollei SafetyCam“ sis a program for accessing the IP surveillance camera from your iPhone or Android Smartphone. The App can be downloaded free of charge from the ”App Store“ and also from “Google Play“.

  • Page 27: Installation On Mac Os

    Now click on “System settings” and then on “Network”. Select the current network connection from the window. This is indica- ted by the preceding green point, in this case “WLAN”), click on “Further Options”: Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 28 Change to page “TCP/IP“ where you find the IP address of your router under “Router”. The address in the below example is 192.168.16.1. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 29 Browser (Safari) in order to open the configuration page of the surveillance camera. Now continue the installation as specified in section 5.5., Manual set-up of surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 30: Installation Tips

    Check the wireless settings and in particular the entered code. All WLAN channels may not be enabled. Adjust the “Region” setting when entering the Wireless settings. You router may allocate changing local IP addresses each time it connects. Search for the camera again using Rollei Safety- Cam Config.
  • Page 31 Generally it is not possible to call up the surveillance camera via the Internet from the same network the camera is connected to. This can only be done using the local network address. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 32: The Program Rollei Safetycam Config

    6. The program Rollei SafetyCam Config Below we have provided a detailed description of the program Rollei SafetyCam Config, as installed in section 5.3., Software Installation. Ensure that the surveillance camera is connected to the router via the network cable and is connected to the mains (see section 5.1., Hardware Installation).
  • Page 33 The default user account is ”admin“ without password. To call up a surveillance camera from the camera list Rollei SafetyCam Config in the Browser window, click on “Browser“ in the menu. This opens the standard browser with the log-in page of the camera. You can then either call up the camera image or enter further settings for the camera.

  • Page 34: Use Of Surveillance Camera

    Enter a User name and respective password to log on. Next click on “Log on“. When using the surveillance camera for the first time enter “admin“ as User name and leave password field empty.. This starts the operating and settings program of the surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 35: Controlling The Surveillance Camera

    As soon as the IP Security Camera is connected to power, a calibration is automatically carried out. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 36 Click on button of option 1, 2 or 3 to move the camera head in the position stored under the respective number. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 37 Adobe Flashplayer has to be installed on the operating net browser. It can be downloaded via http://get.adobe.com/go/ getflashplayer/. Horizontal and vertical mirroring of the camera image can, for instance be used when the surveillance camera is ceiling mounted. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 38: Settings

    The device status provides information about current data and settings values of the surveillance camera. Select 1 from the below menu. Symbol “Device status”. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 39: Camera Name

    “Save”. The camera name can consist of any characters and can contain up to 20 characters. The camera name is saved without having to restart the surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 40: Date And Time

    NTP servers by name or IP address that are not listed.. Click on “Apply“, to accept the changed settings. The changes are saved without having to restart the surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 41: User Account

    Click on “Apply“, to accept the changed settings.The surveillance camera is restarted to save the changes to the user account. The restart takes about 2 minutes. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 42: Network Settings

    The port of Web user interface should always be set to the same port as the external port of the surveillance camera in the router. (see section 5.6.Setting up the router). Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 43 Click on “Apply“, to accept the changed settings. You have to restart the surveillance camera before the changes are saved in the network settings. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 44: Wireless Settings

    System Administrator. „ Network name (SSID): Enter the name of your wireless network (also referred to as SSID). Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 45 Click on “Apply“, to accept the changed settings. Next, restart the surveillance camera to accept the wireless settings changes. The restart takes about 2 minutes. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 46: Upnp Settings

    Note: • These settings are only of importance where manual installation was selected. When using Rollei Cloud, no further settings have to be entered. Universal Plug and Play (UPnP) is used for controlling devices via an IP-based network. Where the router supports UPnP and where this function is activated, the required Firewall settings are automatically selected.

  • Page 47: Ddns Settings

    Note: • These settings are only of importance where manual installation was selected. When using Rollei Cloud, no further settings have to be entered. On the Internet, the surveillance camera can be accessed through the IP address of the router or server. As in many cases the public IP address of the Internet access changes constantly, it is advantageous if the surveillance camera can be accessed via a fixed address.
  • Page 48 Click on “Apply“, to accept the changed settings. Next, restart the surveillance camera to accept the DDNS settings changes. The restart takes about 2 minutes. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 49: Mail Settings

    The so-called SMTP Server (Simple Mail Transfer Protocol) is a post output server of an email provider. Emails are sent to this server for forwarding. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 50 Click on”Test“, to test the email settings. A test email is then sent to the listed email addresses. Click on “Apply“, to accept the changed settings. The changes are saved without having to restart the surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 51: Ftp Settings

    „ Upload in interval: Select this option if you wish images of the surveillance camera to be uploaded to the FTP server at regular intervals. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 52: Alarm Settings

    Select option “Alarm settings” from the bottom of the menu. Depending on the set options, the following will be displayed: „ Motion detection: Select this option to activate motion detection. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 53 „ URL: State the HTTP address to be called up in the event of an alarm. Click on “Apply“, to accept the changed settings. The changes to the alarm settings are saved without having to restart the surveillance camera. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 54 If an alarm signal has been applied, a signal is emitted according to the above settings. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 55: Camera Head Settings

    Click on “Save” to accept changes to the settings. Changes to the camera head settings are accepted without the IP Security Camera having to be restarted. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 56: Resetting

    If the network settings have been changed, the surveillance camera may no longer be attainable under the current address. The surveillance camera can be found again using the configuration program. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 57: Potential Legal Infringements

    Road users could also be determined from lettering on vehicles. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 58: License Declaration

    We guaranty that the source text of the implemented software will be forwarded for a period of at least three years from the date of purchase, provided that the commercial source has obtained the product directly from us or with the involvement of only commercial agents. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 59: Conformity

    Rollei GmbH & Co. KG Denisstr. 28A Rollei GmbH & Co. KG 67663 Kaiserslautern In de Tarpen 42 Germany Germany Hotline: +49 40 270750270 Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 60: Technical Specification

    Weight approx. 238 g Note: • We reserve the right to make technical and optical changes to the product as part of product improvements. Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...

  • Page 61: Index

    LAN cable 6 Legal regulations 55 Date 38 License declaration 56 DDNS server 23 Light frequency 35 DDNS settings 23 Log-on 32 Device status 36 Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
  • Page 62 Rollei Cloud 11, 14, 15 Rollei SafetyCam Config 30 Wall fixing 6 router 16, 20, 25 Warranty 57 Wireless settings 19, 42 WLAN aerial 7 WLAN Settings 42 Rollei GmbH & Co. KG, In de Tarpen 42, D-22848 Norderstedt Service Hotline +49 40 270750270...
