Page 1: Table Of Contents
Quick Start Guide Confirming the Package Contents First Steps Shooting and Playback Using ViewNX 2 Other Functions For Your Safety... - Page 2 Search Nikon’s continuously updated Knowledge Database for the latest technical support information. • Use “Ask Nikon a Question” to receive a prompt reply from a Nikon professional advisor to your e-mail. • Download the latest versions of Nikon software or firmware updates for your product, or register to receive e-mail notification for software or firmware updates.
-
Page 3: Confirming The Package Contents
Confirming the Package Contents In the event that any items are missing, please contact the store where you purchased the camera. COOLPIX S9600 Camera Strap Rechargeable Li-ion Battery Digital Camera EN-EL12 Charging AC Adapter USB Cable UC-E21 EH-71P* • Quick Start Guide (this guide) •... -
Page 4: Parts Of The Camera
Parts of the Camera 1 2 3 Mode dial Monitor d (menu) button Shutter-release button Power switch/power-on lamp Rotary multi selector (multi selector) Flash k (apply selection) button Zoom control f: wide-angle c (playback) button g: telephoto Charge lamp h: thumbnail playback Flash lamp i: playback zoom l (delete) button... -
Page 5: First Steps
First Steps 1 Attach the Camera Strap Step 2 Insert the Battery and Memory Card Step If a memory card is inserted, images will be saved on the memory card when you take images. If a memory card is not inserted, images will be saved in the camera’s internal memory. - Page 6 .2 Insert the battery. Battery latch • Push the orange battery latch in the direction indicated by the arrow (1), and fully insert the battery (2). • The battery locks into place when inserted correctly. Be Careful to Insert the Battery in Correct Direction Inserting the battery upside down or backwards could damage the camera.
-
Page 7: Removing The Battery And Memory Card
.4 Close the battery-chamber/memory card slot cover. Removing the Battery and Memory Card Turn the camera off and make sure that the power-on lamp and the monitor have turned off, and then open the battery-chamber/ memory card slot cover. • The camera, battery, and memory card may be hot immediately after using the camera. -
Page 8: Charge The Battery
Charge the Battery Step Use the included charging AC adapter and USB cable to charge the battery while it is in the camera. .1 Prepare the included charging AC adapter. If a plug adapter* is included with your camera, attach the plug adapter to the plug on the charging AC adapter. - Page 9 Notes Do not use a USB cable other than the UC-E21. Using a USB cable other than the UC-E21 could result in overheating, fire or electric shock. Electrical outlet Charge lamp USB cable (included) • The charge lamp slowly flashes green to indicate that the battery is charging.
-
Page 10: Turn On The Camera
Turn On the Camera Step Press the power switch. • The monitor turns on. The Auto Off Function If no operations are performed for a while, the monitor will turn off, the camera will enter standby mode, and the power-on lamp will flash. If no operations are performed for another 3 minutes, the camera will turn off automatically. - Page 11 Select a Language and Set the Camera Step Clock When the camera is turned on for the first time, the language- selection screen and the date and time setting screen for the camera clock are displayed. Use the multi selector to make the settings. •...
- Page 12 .3 Select your home time New York, Toronto, Lima zone and press the k button. Daylight Saving Time If daylight saving time is in effect, Back press H to enable the daylight saving time function. • When the daylight saving time function is enabled, W is displayed above the map.
- Page 13 .6 Select Yes and press the k button. 05/15/2014 15:30 • When settings are finished, the lens extends and the camera switches to shooting mode. Imprinting the Date and Time on Images While Taking Images After setting the date and time, enable the Print date option in the z (setup) menu (A26).
-
Page 14: Shooting And Playback
Shooting and Playback Rotate the Mode Dial and Align the A Step (Auto) Icon to the Mark Check the Battery Level and the Number Step of Exposures Remaining Battery level indicator 25m 0s 25m 0s Number of exposures remaining Battery level indicator Display Description The battery level is high. -
Page 15: Using The Zoom
Hold the Camera and Frame a Picture Step .1 Hold the camera steady in both hands. • Keep fingers and other objects away from the lens, flash, AF-assist illuminator, microphones, and speaker. .2 Frame the picture. 25m 0s 25m 0s Using the Zoom Move the zoom control. -
Page 16: Focus And Shoot
Focus and Shoot Step .1 Press the shutter-release button halfway, i.e., press the button lightly until you feel a slight resistance. • When the subject is in focus, the focus area that includes the subject or focus indicator glows green (multiple focus areas can glow green). -
Page 17: Flash Lamp
Flash lamp The flash lamp indicates flash status when the shutter-release button is pressed halfway. The flash fires when an image is taken. Flashing The flash is charging.* The flash does not fire when an image is taken. * If the battery level is low, the monitor turns off while the flash is charging. .2 Without lifting your finger, press the shutter-release button the rest of the way down to take the picture. -
Page 18: Delete Images
6 Delete Images Step .1 Press the l button to delete 4 / 4 4 / 4 the image currently displayed in the monitor. 0004. JPG 0004. JPG 05/15/2014 15:30 05/15/2014 15:30 .2 Use the multi selector HI to select the desired deletion method and Delete press the k button. - Page 19 Your Imaging Toolbox Installing ViewNX 2 Step An Internet connection is required. For system requirements and other information, see the Nikon website for your region. .1 Download the ViewNX 2 installer. Start the computer and download the installer from: http://nikonimglib.com/nvnx/ .2 Double-click the downloaded file.
-
Page 20: Using Viewnx
Transferring Images to the Computer Step .1 Choose how images will be copied to the computer. Choose one of the following methods: • Direct USB connection: Turn the camera off and ensure that the memory card is inserted in the camera. Connect the camera to the computer using the USB cable. - Page 21 2 Double-click Import File. If the memory card contains a large number of images, it may take a while for Nikon Transfer 2 to start. Wait until Nikon Transfer 2 starts. Connecting the USB Cable The connection may not be recognized if the camera is connected to the computer via a USB hub.
-
Page 22: Viewing Images
.3 Terminate the connection. • If the camera is connected to the computer, turn the camera off and disconnect the USB cable. • If you are using a card reader or card slot, choose the appropriate option in the computer operating system to eject the removable disk corresponding to the memory card and then remove the card from the card reader or card slot. -
Page 23: Other Functions
Other Functions Flash Mode, Self-Timer, Macro Mode, Creative Slider, and Exposure Compensation Use the multi selector in shooting mode to apply the following settings. Function Description The flash modes available are U (auto), V 1 m Flash mode (auto with red-eye reduction), W (off ), X (fill flash), and Y (slow sync) modes. -
Page 24: Selecting A Shooting Mode
Selecting a Shooting Mode When the mode dial is rotated next to the mark, the camera switches to the corresponding shooting mode shown below. Auto mode Used for general shooting. Settings can be adjusted to suit the shooting conditions and the type of shot you want to capture. x, y, X, S, W Scene mode Camera settings are optimized according to the scene that you... -
Page 25: Recording Movies
Recording Movies You can record movies by simply pressing the b (e movie- record) button. Press the b (e movie-record) button to start movie recording. Press the b (e movie-record) button again to stop movie recording. Other Functions... -
Page 26: Using Camera Menus
Using Camera Menus A variety of shooting and playback settings can be adjusted from the camera menus. Press the d button to display 25m 0s 25m 0s the menu for the current mode and use the multi selector to select an item (A11). Select a menu icon on the left to switch to Image mode the menu of the selected icon. -
Page 27: Playback Mode
Playback Mode The following options are available in full-frame playback mode. Control Name Main Functions • When the camera is turned off, press c (playback) and hold this button to turn the button camera on in playback mode. • Return to shooting mode. •... - Page 28 Control Name Main Functions d (menu) Display and hide the menu. button l (delete) Delete images. button Other Functions...
-
Page 29: For Your Safety
Repairs should be performed only by qualified technicians. Should the camera or charging AC adapter break open as the result of a fall or other accident, take the product to a Nikon- authorized service representative for inspection, after unplugging the product and/or removing the battery. - Page 30 Failure to observe this precaution could cause damage or fire. Use the appropriate power supply (battery, charging AC adapter, AC adapter, USB cable) Using a power supply other than those provided or sold by Nikon could result in damage or malfunction. Observe caution when handling the battery The battery may leak, overheat, or explode if improperly handled.
- Page 31 Should the insulation be damaged and the wires become exposed, take it to a Nikon-authorized service representative for inspection. Failure to observe these precautions could result in fire or electric shock.
- Page 32 Use appropriate cables When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations. Handle moving parts with care Be careful that your fingers or other objects are not pinched by the lens cover or other moving parts.
- Page 33 Notices Notices for Customers in the U.S.A. IMPORTANT SAFETY INSTRUCTIONS -SAVE THESE INSTRUCTIONS. DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the power outlet if needed.
- Page 34 Nikon Corporation may void the user’s authority to operate the equipment. Interface Cables Use the interface cables sold or provided by Nikon for your equipment. Using other interface cables may exceed the limits of Class B Part 15 of the FCC Rules.
-
Page 35: Caring For The Camera
Caring for the Camera To ensure continued enjoyment of this Nikon product, observe the precautions described below in addition to the warnings in “For Your Safety” (A29) when using or storing the device. Do Not Drop The product may malfunction if subjected to strong shock or vibration. - Page 36 • The monitor is lit by an LED backlight. Should the monitor begin to dim or flicker, contact your Nikon-authorized service representative. About the Manuals Nikon will not be held liable for any damages resulting from the use of this product. Notices...
- Page 37 Before taking pictures on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.
- Page 38 (products purchased in the EU or EFTA can be used anywhere within the EU and EFTA). Nikon does not accept liability for use in other countries. Users who are unsure as to the original country of sale should consult with their local Nikon service center or Nikon-authorized service representative.
- Page 39 COOLPIX S9600, which is equipped with a DW092 (FCC ID: EW4DW092/ IC ID: 4634A-3149EC) Wireless LAN Module, has been tested and found to comply with FCC/IC radiation exposure limits set forth for an...
- Page 40 Precautions when Using Radio Transmissions Always keep in mind that radio transmission or reception of data is subject to interception by third parties. Note that Nikon is not responsible for data or information leaks that may occur during data transfer.
- Page 41 AVC Patent Portfolio License This product is licensed under the AVC Patent Portfolio License for the personal and non-commercial use of a consumer to (i) encode video in compliance with the AVC standard (“AVC video”) and/or (ii) decode AVC video that was encoded by a consumer engaged in a personal and non- commercial activity and/or was obtained from a video provider licensed to provide AVC video.
-
Page 42: Trademark Information
• Android and Google Play are trademarks or registered trademarks of Google, Inc. • All other trade names mentioned in this manual or the other documentation provided with your Nikon product are trademarks or registered trademarks of their respective holders. Notices... - Page 44 FX3K01(11) 2014 6MN36711-01...
