ROTARY
HAMMER
DRILL
650W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
650W
No Load Speed:
1,000 /min
Impact Rate:
5,100 bpm
Impact Energy:
1.8 Joule
Accessory Fitment:
10mm SDS+
Drilling Capacities:
Concrete 22mm
Net Weight:
2.9 kg
ozito.com.au
WHAT'S IN THE BOX
Rotary Hammer Drill
Side Handle
Depth Gauge
Kit Box
RHD-2100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHD-2100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ozito RHD-2100

Summary of Contents for Ozito RHD-2100

  • Page 1 DRILL 650W Side Handle INSTRUCTION MANUAL SPECIFICATIONS Motor: 650W No Load Speed: 1,000 /min Depth Gauge Impact Rate: 5,100 bpm Impact Energy: 1.8 Joule Accessory Fitment: 10mm SDS+ Drilling Capacities: Concrete 22mm Net Weight: 2.9 kg ozito.com.au Kit Box RHD-2100...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION ROTARY HAMMER DRILL 1. SIDE HANDLE AND SAFETY CHECKS 1 SDS Accessory Holder 5 Forward/Reverse Lever 2 Accessory Locking Sleeve 6 Variable Speed Trigger Ensure the tool is disconnected from the power supply before performing any of the following operations.

  • Page 3: Operation

    OPERATION 2. SDS ACCESSORIES 3. CONTROLS To reduce the risk of electric shock, a residual current device Accessory (rated 30mA or less) must be used. Variable Speed Trigger 1. Prior to insertion into 2. Prior to insertion into chuck, ensure the SDS chuck add lubricant to 1.
  • Page 4 PRIOR TO CHANGING MODES, THE VARIABLE SPEED TRIGGER SHOULD BE RELEASED AND THE DRILL SHOULD HAVE Note: Do not force the drill or apply side pressure to elongate the COME TO A COMPLETE STOP. hole. Let the drill do the work. RHD-2100...

  • Page 5: Maintenance

    Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the drill by SPARE PARTS an unauthorised person or by mishandling of the drill.
  • Page 6 BT-RH 600 Artikel-Nr.: 4258240 SPARE PARTS Bohrhammer Ident-Nr.: 01038 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse.

  • Page 7: Electrical Safety

    Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. To reduce the risk of electric shock, a residual current device (rated 30mA or less) must be used.

  • Page 8: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0414...
