Page 2: Specifications
SPECIFICATIONS - MODEL NO. RHR-850 Motor: 850W Input: 230V ~ 50Hz No load speed: 800 /min Impact rate: 3,000 bpm Impact energy: 3.8 Joule Accessory fitment: SDS+ Drilling capacities: Timber 40mm Steel 13mm Masonry 28mm Weight (tool only): 4.35 kgs KNOW YOUR TOOL 1. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS……………………………………… Page 1 INTRODUCTION……………………………………….. Page 3 ELECTRICAL SAFETY.…………………………………. Page 3 GENERAL SAFETY INSTRUCTIONS………………… Page 4 ADDITIONAL SAFETY INSTRUCTIONS FOR ROTARY HAMMER DRILLS…………………………… Page 6 OPERATION……………………………………………. Page 7 DEPTH ROD……………………………………………. Page 7 FITTING A SDS+ ACCESSORY……………………….. Page 7 FITTING &... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Warning! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term "power tool" in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 6 GENERAL SAFETY INSTRUCTIONS (cont.) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
-
Page 7: Additional Safety Instructions For Rotary Hammer Drills
ADDITIONAL SAFETY INSTRUCTIONS FOR ROTARY HAMMER DRILLS This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 8: Operation
OPERATION BEFORE ATTACHING OR REMOVING ANY ACCESSORIES FROM THE DRILL, BE SURE TO DISCONNECT THE DRILL FROM THE POWER SUPPLY. Depth Rod The metal depth rod (11) allows you to drill to a predetermined depth. Loosen the 360° side handle (9) by turning anti-clockwise. Feed the metal depth rod (11) so the drill bit extends beyond the end of the metal depth rod (11) to the required drilling depth. -
Page 9: Fitting & Using The Dust Cover
OPERATION (cont.) Fitting and Using the Dust Cover The dust cover (17) catches dust and debris generated while using the drill over head. It’s advised to use the dust cover (17) when drilling over head to minimize dust and debris entering the drill’s air vents and extending the drill’s life. - Page 10 OPERATION (cont.) Hammer Drilling Mode Rotate the side mode selector (4) to the hammer and drill icon, and rotate the rear mode selector (8) to the drill and hammer icon. This setting is recommended for use when drilling holes in concrete and other masonry products. The hammer action will be in operation while simultaneously the drill bit rotates.
-
Page 11: Maintenance
Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the drill by an unauthorised person or by mishandling of the drill. -
Page 12: Trouble Shooting
Limited spare parts are available subject to availability. Please contact your local Bunnings Special Orders Desk to order the required spare parts. Most common spare parts listed below: Spare part Ozito part no. Carbon Brush Holder (pair) SPRHR850-64 Carbon Brush (pair) -
Page 13: Description Of Symbols
DESCRIPTION OF SYMBOLS Volts Hertz Alternating current Watts /min Revolutions or No load speed reciprocation per minute ø /bpm Impact rate Diameter Double insulated Regulator compliance mark Warning CARING FOR THE ENVIRONMENT Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way. -
Page 14: Contents
CONTENTS 1 x Rotary Hammer Drill RHR-850 3 x SDS+ drill bits 1 x Side Handle 1 x SDS+ pointed chisel 1 x Tub of Grease 1 x SDS+ flat chisel 1 x Depth Rod 1 x Accessory box 1 x Chuck Key... -
Page 15: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 1 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 12 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
