Honeywell UDC3500 Quick Start Manual

51-52-25-130
September 2005
For detailed instructions see UDC3500 Controller Product Manual 51-52-25-120.
Step 1. Model Number Interpretation
Write your controller model number in the boxes. Then refer to Tables I, II, III, IV, and V . Circle the corresponding options to identify your controller's features. A dot indicates the feature is available.
Key Number
KEY NUMBER - UDC3500 Single & Dual Loop Controller
Description
Digital Controller for use with 90 to 264Vac Power + Current Output #1
Digital Controller for use with 24Vac/dc Power + Current Output #1
TABLE I - Specify optional Output and/or Alarms
None
Current Output (4 to 20mA, 0 to 20 mA) (Current Output #3)
Electro Mechanical Relay (5 Amp Form C)
Output #2
Solid State 1 Amp (Zero-Crossing Type)
Open Collector transistor output
Dual 2 Amp Relays (Form A) (Heat/Cool, Pos Prop, TPSC, Relays 1 & 2)
Relay Outputs #3, #4 None
and #5
Three (3) E-M Relay (5 Amp Form C)
TABLE II - Communications and Software Selections
None
Current Output #2 + (4) Digital Inputs
Communications
Current Output #2 + (4) Digital Inputs + Modbus RS-485
10 Base-T Ethernet (Modbus RTU) + (4) Digital Inputs
Standard Functions, Includes Accutune
Math Option
Set Point Programming (1 Program, 20 Segments)
Set Point Programming Plus Math
Software Selections
HealthWatch
SPP + HealthWatch
Math + HealthWatch
SPP + Math + HealthWatch
Single Loop
Loops of Control
2 Loops + Internal Cascade
None
Real-Time Clock
Real-Time Clock (RTC)
Step 2. Dimensions and mounting
Max. panel thickness
19,1
mm
0.75
inches
92,0 + 0,8
- 0,00
Panel
3.62 + 0.03
Cutout
- 0.00
92,0 + 0,8
- 0,00
17,9
3.62 + 0.03
0.70
- 0.00
Step 4. Configuration Procedure
Step Operation
1 Enter Set Up Mode
2 Select any Set Up
Group
3 Select a Function
Parameter
Loop 1/2
4 Change the Value
or Selection
5 Enter the Value or
Selection
Loop 1/2
6 Exit Configuration
Quick Start Guide for UDC3500 Universal Digital Controller
- -
Table I Table II
Selection
DC3500
DC3501
0 _ _ _
1 _ _ _
2 _ _ _
3 _ _ _
_ 0 _ _
_ A _ _
_ B _ _
_ C _ _
_ D _ _
_ E _ _
_ F _ _
_ G _ _
_ _ 0 _
_ _2 _
_ _ _ 0
_ _ _ C
Step 3. Wiring
9,0
0.35
90,6
108,6
3.57
4.28
Output #2 Output #2
148,0
5.81
Press
Upper Display = SETUP
Setup Setup
Lower Display = TUNING (This is the first Set Up Group title)
Sequentially displays the other Set Up group titles shown in the prompt hierarchy. See User Manual.
Setup Setup
You can also use the
group of parameters you want to configure. Then proceed to the next step.
Upper Display = the current value or selection for the first function prompt of the selected Set Up group.
Func
Lower Display = the first Function prompt within that Set Up group.
Sequentially displays the other function prompts of the Set Up group you have selected. Stop at the function prompt that you want to change,
then proceed to the next step.
Increments or decrements the value or selection that appears for the selected function prompt. If you change the value or selection of a
or parameter while in Set Up mode but then decide not to enter it, press the MAN/AUTO key once. This will recall the original configuration.
This "recall" procedure does not work for a Field Calibration process. Field Calibration is a one-way operation.
Enters value or selection made into memory after another key is pressed.
Func
Exits configuration mode and returns controller to the same state it was in immediately preceding entry into the Set Up mode. It stores any
Lower Lower Lower
changes you have made.
Display Display Display
If you do not press any keys for 30 seconds, the controller times out and reverts to the mode and associated display used prior to entry into
Set Up mode.
-
Table III
TABLE III - Input types can be changed in the field
Availability
TC, RTD, mV, 0-5V, 1-5V
TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA
Input 1
TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA, -1-1V, 0-10V
Relative Humidity (Requires Input 2)
0 _
Carbon, Oxygen or Dewpoint (Requires Input 2)
C _
None
E _
TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA
Input 2
A _
TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA, -1-1V, 0-10V
T _
Two HLAI instead of 1 LLAI
R _
None
_ 0
TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA
_ E
Input 3 TC, RTD, mV, 0-5V, 1-5V, 0-20mA, 4-20mA, -1-1V, 0-10V
Two HLAI instead of 1 LLAI
Slidewire Input for Position Prop. (Requires Dual Relay Output)
TABLE IV - Options
CE (Standard)
Approvals
CE, UL and CSA
None
Tags
Stainless Steel Customer ID Tag - 3 lines w/22 characters/line
None
Future Options
None
None
TABLE V - Product Manuals
Product Information on CD - (English)
English Manual (Hard Copy)
French Manual (Hard Copy)
Manuals
German Manual (Hard Copy)
Italian Manual (Hard Copy)
Spanish Manual (Hard Copy)
None
Certificate
Certificate of Conformance (F3391)
Relays #3, #4 and #5 Relays #3, #4 and #5
Earth Ground Earth Ground
AC/DC AC/DC AC/DC
L1 L1
Line Line Line
Hot Hot
Voltage Voltage Voltage
L2/N L2/N
Neutral Neutral
4 4
+ +
5 5
Current Output #1 Current Output #1
6 6
- -
7 7
+ +
2 2
8 8
+ +
1 1
- - - - 9 9
Result
or keys to scan the Set Up groups in both directions. Stop at the Set Up group title that describes the
