- Page 1 Instructions for use Refrigerator...
-
Page 2: Table Of Contents
Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. Refrigerator is used in households for storage of fresh food at temperatures exceeding 0°C. Before fi... -
Page 3: Before Fi Rst Operation
Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. -
Page 4: A Few Tips On How To Save Power With Your Refrigerator-Freezer Combo
• Self closing door hinge pulls the door to the cabinet just before closing, thereby preventing the door to remain ajar. Equally it limits the door opening angle and prevents damage to adjacent elements. • Rating plate with basic information is located in the interior of the appliance. If the sticker plate is not suitable for your language, replace it with the attached one. -
Page 5: Description Of The Appliance
Description of the appliance Interior light Shelf (adjustable height) Foldable egg rack (closed - six eggs, open - 12 eggs) Vegetable crisp pan ZeroZone drawer with pull-out guides* (max. 18 kg) Bottle rack* Door shelf (options: deep, shallow; covered or no cover) Twin bottle carrier with holder Tube holder*... -
Page 6: Installation And Connection
Installation and connection Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. Relevant class of the appliance is indicated on the rating plate. Class Ambient temperature SN (subnormal) from +10°C to +32°C... - Page 7 Connecting to power • Use the power cord to connect the appliance to the mains supply power. Wall outlet must be fi tted with ground terminal (safety socket). Nominal voltage and frequency are indicated on the relevant label or rating plate of the appliance. •...
-
Page 8: Appliance Control
Appliance control Control panel I Control unit is located at the exterior side of the door. Setting ON Setting OFF A Temperature selector and ON/OFF button B Clock ON/OFF button C Alarm button D Fast cooling button E Economy F Vacation G Setting hours H Setting minutes... -
Page 9: Setting The Temperature
The ON/OFF button First plug the power cord into the wall outlet. The LCD display is on and indicates dashes. • Switch the appliance on by pressing button (A) for 3 seconds. • Display indicates temperature +9°C, and it remains on the display until the actual temperature within the unit falls below this value. - Page 10 Other settings Alarm Continuous sound - opened door. If the door is open for more than one minute, the sound signal (continuous tone) starts and symbol appears. Alarm goes off by closing the door, or by pressing the alarm off button (C).
- Page 11 Child lock Built-in child lock prevents the appliance from unwanted temperature alterations and/or even switching off. Turn it on/ off by pressing the alarm button (C) for 3 seconds. During the activated protection, when you press any button the wording LOC appears on the display.
- Page 12 Control panel II The control unit is located on the outer side of the door. A Refrigerator on/off key B Signal light: on when refrigerator is in operation C Acoustic alarm off key D Signal light: on when high temperature alarm is activated E Super Cool (refrigerator boost) key F Signal light: on when the Super Cool (refrigerator boost) is activated G Refrigerator temperature setting key...
- Page 13 Switching the appliance When switching on the appliance for the fi rst time, fi rst connect on/off the power cord plug to a mains socket. Digital display unit will light up, »dashes« appear. • To switch the appliance on/off, press the (A) key and hold it for 3 seconds.
- Page 14 Refrigerator boost (intensive cooling) Press the (E) key to activate the refrigerator boost (intensive cooling). When the refrigerator boost (intensive cooling) is activated, the signal light (F) will be on. After six hours, the function is deactivated and the settings will return to the most recent values.
-
Page 15: Recommended Distribution Of Food
Recommended distribution of food Recommended Refrigerator compartments: distribution of food - top section: canned food, bread, wine, cake, … - middle section: dairy products, cheese, readymade food, desserts, juices, beer, TV-dinners, … - bottom section: meat, meat products, delicatessen, … - crisp pan: fresh fruit, vegetables, salads, appliances without ZeroZone drawer also: root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips, …... -
Page 16: Storing Fresh Food
Storing fresh food Important precautions Proper use of the appliance, adequately packed for storing fresh food food, correct temperature and hygienic precautions produce substantial impact on the quality of stored food. Always respect the best before date, printed on the packaging. - Page 17 • Fan (optional design depending on the model - under the ceiling or hid beneath the rear panel) improves even distribution of temperature and decreases dew upon storage racks. • Cool water dispenser (available only in certain models on the exterior side of the door) is used for pouring cool water without opening the refrigerator door.
-
Page 18: Storing Of Food In The Zerozone Drawer
Storing of food in the ZeroZone drawer The ZeroZone drawer provides storage of wide selection of fresh food approximately three times longer than in the traditional refrigerator. Food remains fresh for long time and it preserves its taste and nutritive ingredients. It reduces decay and loss of mass, so fruit and vegetables are more fresh and natural. - Page 19 Recommended storage Food: Storage period periods in the ZeroZone Meat: drawer* sausages, cold cuts, beef, pork, venison, up to 7 days raw meat poultry up to 5 days fi sh up to 4 days seafood up to 3 days Vegetables: cabbage, garlic, carrots up to 180 days celery, herbs...
-
Page 20: Defrosting The Appliance
Defrosting the appliance Automatic defrosting The appliance needs no special defrosting procedure, because ice deposited at the inner back wall is defrosted automatically. Ice deposited on the inner back wall during the compressor operation is defrosted when the compressor stops operating, and condensed water drops are drained through the outlet in the inner back wall into the drain pan situated above the compressor where it evaporates. -
Page 21: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not operate • Check if there is power in the socket and if the appliance is after connection to the mains: switched on. Cooling system operates • Ambient temperature too high. continuously without intermittent •... - Page 22 Fault: Cause/Remedy Bulb replacement: • Before replacing the light bulb, disconnect the appliance form the power supply. Remove the plastic cover, replace the bulb with a new one (E14, same voltage as the factory one) and fi t back the cover. •...
-
Page 23: Noise Level
Noise level The refrigerator - freezer appliances are cooled by the refrigeration system with a compressor, whose operation may produce certain noise. The level of such noise depends upon the location, correct use and age of the appliance. • After starting the appliance, the operation of the compressor (the refrigerant fl... - Page 24 HS3966EF HKS3666EF en (09-12) HKS3661EF...
