Shenzhen Hongdian Technologies H332x User Manual

Mdvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User manual


H322x MDVR



Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H332x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shenzhen Hongdian Technologies H332x

Summary of Contents for Shenzhen Hongdian Technologies H332x

  • Page 1: User Manual

    User manual   H322x MDVR    ...
  • Page 2 Shenzhen Hongdian Technologies Corporation. Trademarks and Permissions     and DTU are the trademarks and logos of Shenzhen Hongdian Technologies Corporation. Other trademarks and logos mentioned in this manual belong to other organizations related. Shenzhen Hongdian   Technologies Corporation does not own the rights of other trademarks and logos.
  • Page 3   General intro   Hongdian H332x MDVR is a 3G/4G mobile DVR for vehicle use with integration of 4 channels AV collection, storage and data transmission.   This manual will introduce product info, installation procedure, configuration, FAQ of this H332x .  ...
  • Page 4   6 glossary   To introduce the glossary in this file   A abbrev   To introduce the abbreviation in this file   Conventions   Symbol Conventions   The symbols that may be found in this document are defined as follows.   Symbol  ...
  • Page 5   [ x | y | ... ]   Optional items are grouped in brackets and separated by vertical bars. One item is selected or no item is selected.   { x | y | ... } *   Optional items are grouped in braces and separated by vertical ars. A minimum of one item or a maximum of all items can be selected.

  • Page 6: Table Of Contents

    1 General info ................................. 1-1    1.1 General info ..............................1-1       1.2 Product application ............................1-1   2 H332x MDVR installation ........................... 2-1    2.1 Installation procedure ........................... 2-1       2.2 Open box ..............................2-2  ...
  • Page 7   4.6 Network ..............................4 10 4.6.1 Ethernet ............................. 4 - 10 4.6.2 DDNS ..............................4 11 4.6.3 DNS Setup ............................4 11 4.6.4 Route Setup ............................4 11 4.6.5 ICMP ..............................4 12 4.7 Alarm ................................4 12 4.7.1 Video Alarm ............................4 12 4.7.2 I/O Setup ............................

  • Page 8: General Info

    1.1 General info   Hongdian H332x MDVR (mobile digital video recorder) is a 3G/4G mobile DVR for vehicle use with integration of 4 channels AV collection, storage and data transmission. It will collect and digitally code the AV data from sound pickup, camera, and then transmit the data to monitoring center for surveillance purpose.
  • Page 9      ...
  • Page 10   1 -2  ...

  • Page 11: H332X Mdvr Installation

    To introduce how to supply power to MDVR.   To introduce how to check after installation.   Installation check   2.1 Installation procedure   The procedure to install H332x MDV is as shown in figure 2-1.     H332x MDVR installation procedure   Figure 2-1   2 -1...

  • Page 12: Open Box

    Complete materials include the following equipment in table 2-1. Package carton shall be kept properly for a second transportation.   Item name   quantity Note       Standard equipment H332x MDVR     CD-ROM   User manual and other info   Inspection certificate Warranty card    ...

  • Page 13: Install Hard Disk & Sim Card

    2.3 Install Hard disk & SIM card   Usually H332x MDVR is equipped without HD. Customers can buy 2.5” SATA Hard Disk themselves. Customers are suggested to choose good quality or famous brand HD to guarantee save data storage.  ...
  • Page 14     Step3 Slide out the HD box.      Step4 Unscrew all screws on the side and back panel      2 -4...
  • Page 15     Step5 Insert the hard disk      Step6 Screw fix the hard disk.        2 -5...
  • Page 16   Step7 Install SIM card &SD card..      Step8 Slide back hard disk box.        Screw back screws and lock hard disk.    Step9   2 -6...

  • Page 17: Connect Cables

        ---end   2.4 Connect cables   Background Basically nearly all interfaces of H332x MDVR are on the rear panel, it is necessary to know info of the interfaces on the panel. Front Panel:       2 -7...
  • Page 18       Rear Panel(8 channels ):           Definition of interfaces   Panel   Interface Name Instruction   Front Panel   Audio/video output AV OUT AV output port to connect monitor.   10/100BaseT   Ethernet Used for update or export file Reserved  ...
  • Page 19 Cellular SMA-J female port GPS antenna GPS SMA-J female port Wi-Fi antenna WIFI WiFi SMA-J female port DC IN DC IN Power supply for H332x DC OUT DC OUT Power supply for camera. etc GPIO instruction       Label  ...
  • Page 20   10   12V_OUT   To power other device（ Power supply current (less   than 1A) 11   Speed_IN   Connect external speed censor, support sine wave or square wave input   12  GND  Ground  13  PC_TX1  Received Data （RS232）  14  PC_RX1  Transmitted Data（RS232） ...
  • Page 21       The black plug shall connect MDVR and then fasten it.   AV IN1-AV IN4, every cable has two interfaces and two power cables: AV_OUT interface Line sequence   Label   Color Instruction 1   ACC  Red  12V “+”  2  ...

  • Page 22: Serial Port

      Audio speaker input/output Audio speaker input/output port to connect audio speaker input/output cable.   audio speaker input/output port     audio speaker input/output cable     Number   Color P2, P3 Note   1   P3 (Orange)   Yellow LINE-IN  ...
  • Page 23         Power supply port Power supply port is shown in figure 2-19. Power supply cable is shown in figure 2-20, cable definition see table 2-5.   Power supply port     Power supply cable     Label   Color Note  ...
  • Page 24 If device cannot power on, check safety fuse first.   ACC inigition signal must > 7.5V, to start the device.   DC IN 2+ and DC IN 2- used as backup power to connect UPS, if main power off, H332x will switch to backup power immediately.  ...

  • Page 25: Ethernet Port

        Line sequence label identification Description 1  GND  Ground  2  DC IN +  Power “+“    3  ACC  ignition wire       Ethernet port   RJ45 interface, 10/100 baseT standard, self-adaption.   2.5 Power supply     Pls confirm there is no short cut of the power supply. Positive and negative pole are correctly connected.

  • Page 26: Working Environment

      Connect power cable and ignition cable of H332x MDVR to stabilized voltage supply correctly and then switch on the power supply.   2.6 Working environment      Voltage   DC+8~36V      Working temperature   0 ºC ~+65ºC      Store temperature  ...

  • Page 27: Indicator On Mdvr Panel

    3.4 Register to platform To introduce how to register the MDVR into the platform server. server   3.1 Indicator on MDVR panel   All indicators of H332x MDVR are on its front panel.   Indicator on   flicker   name  ...

  • Page 28: Connect To Local Pc

    3.2 Connect to local PC   Background Hongdian H332x MDVR is configured in a friendly GUI. so firstly the local PC shall be configured correctly and then connect the MDVR to PC to configure it in GUI.   Precondition HD has been installed in MDVR.  ...
  • Page 29           3 -3...
  • Page 30 IP address: 192.168.8.* (*indicates any integral between 2 to 254)   Subnet mask: 255.255.255.0 Default gateway: 192.168.8.1     Remember:   H332x LAN port factory default parameter:   IP address: 192.168.8.1;   Subnet mask: 255.255.255.0   H332x factory default login parameter:   Management interface login IP address:  ...
  • Page 31   Advanced configuration    If you don’t want to interrupt local PC LAN communication and configure H332x when the former network configuration exists, it is required add route (IP).   The configuration operation is shown as below:   Click the “Advanced…”button to enter the interface as below:  ...
  • Page 32 Internet through original local network configuration. If Internet is accessed through original local network, the default gateway setting does not need to be modified; if H332x is used, you need to modify the default gateway and configure it as H332x ’s default LAN IP address 192.168.8.1. ‐‐‐END   ...

  • Page 33: Download & Install "Hd_Videoplayer Activex Control

      Default IP address of H332x MDVR is 192.168.8.1, default user name is admin, default password is   admin。 Step3 Click “run add‐in” to install HD_VideoPlayer ActiveX Control.    If the ActiveX control is successfully installed, the configuration GUI will appear.   If the ActiveX control is not sucessufully installed, “digital signature detailed info” shall be confirmed, see “5 FAQ how to install Hongdian Video play control”.
  • Page 34       click “Unknown Publisher” and then click “View Certificate”          Then install Certificate and follow the instruction to finish it.            3 -8...
  • Page 35         After succeed install the certificate, please refresh the page and install the Active X control.       a., Enter main page of H3225 MDVR   3 -9...

  • Page 36: Register To Platform Server

      Background info Register H332x MDVR to platform server is to configure some parameters to connect MDVR to platform server. After configuration, MDVR can be controlled through the platform.   H332x MDVR supports access of different platforms. Here is an example of iSCAN platform which is developed by Hongdian itself.
  • Page 37     Step3 Click “Device info > net info” to confirm it shows connecting, and IP address has been  acquired    Wirelss network info         3 -11...
  • Page 38   Step4 Click “server setup > CMS setup”, and interface will be shown. Access server setting interface         Step5 Input parameters in the interface. “CMS address” parameter, please check CMS platform  user manual for more details.        Server address and equipment ID shall be input based on specific cases. Other parameters are suggestedto   to default setting. After setting, pls restart the MDVR. Step6 Click “save” to complete setting ...
  • Page 39             ---end     3 -13...

  • Page 41: Advanced Guide

        Advanced guide       About this charpter   subject   content 4.1 Video play   To introduce video play operation procedure.   4.2 Device info   To introduce how to search equipment info.   4.3 Video & Audio   To introduce how to set AV parameter.

  • Page 42: Device Info

     At this page you could fullscreen play one channel video or split the screen to play four channel video.   PTZ control    H332x support PTZ control the camera.   4.2 Device Info This part shows Hardware and software info & 3G/4G network status.etc.    4.2.1 Version “version” shows basic system hardware info of H3225, when need repairs or debug, those info are ...

  • Page 43: Net Status

          4.2.2 Net Status “Net Status” shows wire and wireless network status, you could check H3225 network status by check  this page.         4.2.3 System Info “System Info” shows MDVR ID, hard disk status and connection status with MDVR Server.          Device ID length is 12/20   4 -3  ...

  • Page 44: Video & Audio

      4.3 Video & Audio “Video & Audio” used to set parameters of Video & Audio encode, output and OSD, record.etc.    4.3.1 Video Encoding “Video Encoding” enables you set parameters for 4 ways video.       Video Resolution: set the video revolution among D1/HALF D1/CIF/QCIF, default CIF.    Frame Rate    Rate Control:   CBR) or  VBR).   Constant Bit Rate( Variable Bit Rate(  Bit Rate: Valid value 16~2000Kbps, Live Stream transfer by 3G/4G default value is 100Kbps,  Storage Stream saved in hard disk default value is 200Kbps.      Notice:  1. Data Rate: means video file size of every seconds, it is the most important parameters which determine    the quality of video.  Storage stream resolution must always higher then live stream. When set both live & storage stream to    D1, all live stream parameters will be same as storage stream.    Only 2 way video could be set to D1.

  • Page 45: Osd Setting

        4.3.3 OSD Setting “OSD” is abbreviation of “on screen display”, you could set a text to show time and some brief info.            Click add button to add an OSD, and you could set its type, which channel to show this OSD, also its  content (1‐16 characters), and its position.                 Notice:        OSD position:      One position could only show one OSD, after set one OSD, others cannot added at same position.      One video channel could only show 4 OSD.      4.3.4 Video Record “Video Record”  make H3225 MDVR record video into hard disk. You could set time length of every  video in “Basic Time slice”. And the record begin & end time of each day.         ...

  • Page 46: Image Setup

               Notice:        Begin time must before end time, and time setting must among 24 hours.      When hard disk is writing/reading, do not allow disconnect power or pull out hard disk. If you need do  so, please use power key shut the device down first.       4.3.5 Image Setup Basic parameters of video.                       Notice:    Default value is our recommend value, do not suggest change this.      4.3.6 Capture Setup H3225 support timing capture, you could set a time slot and an interval. MDVR will timing capture the  pictures and save the pictures.     ...

  • Page 47: Audio Setup

                Notice:    Begin time must before end time, and time setting must among 24 hours.  When hard disk is writing/reading, do not allow disconnect power or pull out hard disk. If you need do so,    please use power key shut the device down first.      4.3.7 Audio Setup In this part you could set audio quality.          Save Audio: whether enable save audio in hard disk.     Real Time Audio: whether enable audio in live stream.        Notice:  When you need store remote video on server, you need correct set both MDVR and your server.      4.4 Server “Server” defines communication parameters between MDVR and center server    4.4.1 CMS setup MDVR need connect to “CMS” server and then upload real‐time videos, in this “CMS setup” part you ...

  • Page 48: Ftp Server Setup

             CMS port: CMS server service port, shoud be 5246 3    Device ID: the ID assigned by CMS server. A string of digitals length12, must keep consistency with  ISCAN ManagerServer.     NAT: intranet get through, when MDVR working in intranet, please enable this.     Protocol Version: set this option according to CMS server setting.        Notice:      Please set CMS address & port, device ID according to actual situation. Other parameters recommend    keep default.      You need reboot system to make this parameters available.      4.4.2 FTP Server Setup MDVR could upload its video to FTP server, in this “FTP Server Setup” part you could set basic network  parameters of FTP server.            4.5 Dialup “Dialup” part includes two parts: Mobile Network, Timing Dialup ...

  • Page 49: Mobile Network

        4.5.1 Mobile Network When need to use mobile network to upload video, you need config “Mobile Network” part. This part  determine how the MDVR connect to mobile network.         Please set the follow part according to your local network. Other parameters suggested to keep  default.        Notice:      Auto dialup default is disable, if enable this option without insert SIM card and correct config, MDVR  will repeat reboot itself to dialup.  2.     Advance setup only for experienced network manager.      4.5.2 Timing Dialup According to customers’ need, “Timing Dialup” could make MDVR connect mobile network in certain  period, to save network cost.      4 -9  ...

  • Page 50: Network

                    Notice:    You could set two period at most, the setting must be logical and cannot conflict.      4.6 Network “Network” contains all settings about network:    Ethernet, DDNS, DNS Setup, Route Setup, ICMP, NAT & DMZ.    4.6.1 Ethernet You could set static IP address of MDVR here:                  4 -10...

  • Page 51: Ddns

        4.6.2 DDNS DDNS (Dynamic Domain System) function allow others to visit MDVR by a  domain name instead of a IP  address.               Right now H3225 MDVR support following DDNS service provider:               88IP（www.88ip.net）                               3322（www.3322.org）          DNSEXIT（www.dnsexit.com ）                         ...

  • Page 52: Icmp

          4.6.5 ICMP “ICMP” means Internet Control Message Protocol, used to check network availability, this function  could used to avoid fake connection.            4.7 Alarm 4.7.1 Video Alarm “Video Alarm”: when pre‐set incident triggered MDVR, react will be done. There are four kind of  reactor: I/O output, snapshot, record, pre‐set position.        You could add at most 16 alarms, after add succeed, you could edit or delete it. More details please  check below:          4 -12...
  • Page 53              Name: set a name     Event name: could be triggered by camera or alarm input.     Event Type: when choose camera 1‐ 4, they are two types:    Event dropout: signal lose    MD: Move detection    When choose input port, only one type could be choose: Alarm         Linkage Schedule: directly click the time block you want to set, or click the first row on the left  to choose whole day. Green block means already choosen.  Linkage Action Setup: set a reaction way  when trigger.      4 -13  ...

  • Page 54: I/O Setup

          1） Alarm Output Setup    H3225 provides 4 alarm outputs ports    2） Record Setup    When triggers, choose to record video of one camera    3） Capture Setup    Capture Parameter: set the amount you need to capture when alarm happens.    Capture Interval: the interval between every snapshots.    Alarm Channel: snapshot on which camera.    4） Preset Setup    Linkage Camera: which camera will move to preset position when being triggered.    Preset Position: which position will be moved into.        Notice:      Video record saved in the hard disk.      Pictures snapshot during alarm time will send to FTP server.       ...

  • Page 55: Peripheral Device

    4.8 Peripheral Device “Peripheral Device” includes follow parts:    PTZ Setup  RS‐485 Setup  DTU Setup  Storage Management  Format the memory 4.8.1 PTZ Setup “PTZ” means Pan/Tilt/Zoom, by PTZ control, camera could move and zoom as you demand. In this part  you should set PTZ parameters if your camera supports PTZ.    Figure 4‐8‐1:PTZ Setting About PTZ address: PTZ device has dial switch, ON means 1, OFF means 0, whole 8 digits determine  PTZ address.    4.8.2 RS-485 Setup In this part you could set RS485 parameters, RS485 used to connect PTZ of  camera. 4.8.3 DTU “DTU” function receives data from RS232 port. And it send all the data it received to a IP address or a  domain on the Internet. All these are automatically and based on mobile network and data will be  sends transparently without any change.         4 -15...

  • Page 56: Storage Management

           DTU Service: Set whether enable the DTU Service.    Work Mode: Work as a Server or a Client. Client will register to server automatically.    Transmit Protocol: Select the protocol used to transmit.    Port: Set the receive port if work mode is server.    Received Packet Max Length: Set the max length of received packet, this value must smaller than 1024.  Data Center Configure: If work mode is client, then set parameters of data center here.    Heartbeat Settings: Enable Heartbeat will make the router send certain data every certain interval, this  function is used to keep the link active, also avoid fake link or offline. This function may cause extra  traffic fees.    Rs232 Setting: Set parameters of Rs232 port, please set these according to your device’s Rs232 port  parameters.        4.8.4 Storage Management MDVR support local download video from its built‐in FTP server, when use this function, a hard disk is  needed.      4 -16...

  • Page 57: Format The Memory

             Click Storage icon to enter FTP server, default username: admin, default password: 123456, default  port 21.        You could input a new password and click Save to change the password.              Notice：  FTP server not allow anonymous access。        4.8.5 Format the memory After format, system will reboot itself automatically.         4.9 System “System”  main includes system time setting, log, reboot and recover.        4.9.1 NTP In this “NTP” page you could set MDVR time by NTP which is recommended or manually.         ...

  • Page 58: Log Management

            Notice:  If MDVR already connect to the server, please manually set the time.      4.9.2 Log Management “Log Management” provide two methods to record log: local and remote            Remote IP & port: remoter log will send to this IP and port, please receive these logs by log tool.    4.9.3 Log You could check local log in this page.      4 -18...

  • Page 59: Update

              Notice:  When hard disk is available, “Application Layer” log will saved in hard disk.           4.9.4 Update In this page you could choose a new firmware to update MDVR. Or you could put the update file in a  USB disk and insert it into MDVR, then after power on, it will automatically update in 4~5 minutes.         Notice:  Do not click cancel or do any other operation during updating, otherwise may cause errors. When use USB  disk to update, do not change the firmware name or pull out disk during u         4.9.5 Account Management Account Management used to manage your password. If you forget your password, press DEF button  for 10 seconds under power on status.      4 -19  ...

  • Page 60: Reboot

               4.9.6 Reboot Manually reboot system.        4.9.7 System Recover Make device return to factory setting.           4 -20...
