INSTRUCTIONS
U-RFL-T

POWER SUPPLY UNIT

This instruction manual only covers the power supply that is for the Olympus Power Supply Unit
U-RFL-T. To obtain optimum performance and to familiarize yourself fully with the use of this
power supply unit, we recommend that you also study the instruction manual for the microscope
to be used. Retain this instruction manual in an easily accessible place near the work desk for
future reference.
A X 7 1 1 4
This publication is printed on 100% recycled paper

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-RFL-T and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus U-RFL-T

Summary of Contents for Olympus U-RFL-T

  • Page 1: Power Supply Unit

    U-RFL-T POWER SUPPLY UNIT This instruction manual only covers the power supply that is for the Olympus Power Supply Unit U-RFL-T. To obtain optimum performance and to familiarize yourself fully with the use of this power supply unit, we recommend that you also study the instruction manual for the microscope to be used.

  • Page 3: Safety Precautions

    U-RFL-T IMPORTANT This mercury burner power supply unit is only designed for use with Olympus mercury burner light source attachments. When using this power supply unit, always refer to the instruction manual for the AX, BX, BX2, IX, etc., reflected light fluorescence module.
  • Page 4 3. To avoid a potential shock hazard and ensure the electrical safety, be sure to ground the power cord wire. If the power supply unit is not grounded, Olympus can no longer warrant the electrical safety and performance of the equipment.

  • Page 5: Table Of Contents

    U-RFL-T CONTENTS NOMENCLATURE ASSEMBLY Assembly Diagram ..........1 Mounting the Mercury Burner .

  • Page 6: Nomenclature

    Lamp housing U-ULH (Mercury burner configuration) Mercury burner Collector lens unit USH102D U-UCLHG/XEA, HBO103W/2 U-UCLHG/XEB Socket or IX-UCLHG/XEB U-ULS100HG To illuminator of microscope frame 100W lamp housing (AX, BX, BX2, IX etc.) U-LH100HG U-LH100HGAPO Mercury burner: USH102D HBO103W/2 Power Supply Unit U-RFL-T...

  • Page 7: Mounting The Mercury Burner

    U-RFL-T 2-2 Mounting the Mercury Burner High voltage is applied to ignite the mercury burner, to prevent any hazards, conform that the main switch on the power supply unit is switched to "O" (OFF), unplug the lamp housing cord and power cord plug, and wait at least 10 minutes before proceeding with the replacement.

  • Page 8: Cable And Cord Connections

    2. Plug the mercury burner socket connecting cord plug ² firmly into the output connector ³. (Fig. 5) Always use the power cord provided by Olympus. If no power Fig. 5 cord is provided, please select the proper power cord by refer- ring to the section "PROPER SELECTION OF THE POWER SUPPLY...

  • Page 9: Preparation For Observation

    U-RFL-T PREPARATION TO OBSERVATION 3-1 Igniting the Mercury Burner Never switch the main switch to "I" (ON) while the mercury burner socket connecting cord plug is not plugged in. Dangerous high voltage may be output from the output connector. Move the main switch @ on the power supply unit to "I" (ON). Between 5 to 10 minutes are required for the arc to stabilize after the burner is ignited.

  • Page 10: Specifications

    1. Illumination system Auto-ignition 2. Life meter (counter) Indicates accumulated burner ignition time. 220–240V $ 1.8A 50/60 Hz (U-RFL-T-200) 3. Input rating 150 mm (W) X 295 mm (D) X 200 mm (H) 4. Dimensions (5.91 in. (W) X 11.6 in. (D) X 7.87 in. (H)) 5.

  • Page 11: Troubleshooting Guide

    Under certain conditions, performance of this unit may be adversely affected by factors other than defects. If problems occur, please review the following list and take remedial action as appropriate. If you cannot solve the problem after checking the entire list, please contact your local Olympus representative for assistance. Problem...

  • Page 12: Proper Selection Of The Power Supply Cord

    If no power supply cord is provided, please select the proper power supply cord for the equipment by referring to “Specifications” and “Certified Cord” below: CAUTION: In case you use a non-approved power supply cord for Olympus products, Olympus can no longer warrant the electrical safety of the equipment.
  • Page 13 U-RFL-T Table 2 HAR Flexible Cord APPROVAL ORGANIZATIONS AND CORDAGE HARMONIZATION MARKING METHODS Alternative Marking Utilizing Printed or Embossed Harmoniza- Black-Red-Yellow Thread (Length tion Marking (May be located on Approval Organization of color section in mm) jacket or insulation of internal wir-...
  • Page 14 MEMO...
  • Page 16 Shinjuku Monolith, 3-1, Nishi Shinjuku 2-chome, Shinjuku-ku, Tokyo, Japan Postfach 10 49 08, 20034 Hamburg, Germany 2 Corporate Center Drive, Melville, NY 11747-3157, U.S.A. 491B River Valley Road, #12-01/04 Valley Point Office Tower, Singapore 248373 2-8 Honduras Street, London EC1Y OTX, United Kingdom. 31 Gilby Road, Mt.
