[MAIN UNIT]
REF ORDER
NO. NO.
R151 7030005100 S.RESISTOR
R152 7030005310 S.RESISTOR
R153 7030009320 S.RESISTOR
R155 7030007350 S.RESISTOR
R157 7030005220 S.RESISTOR
R159 7030005090 S.RESISTOR
R161 7030005070 S.RESISTOR
R162 7030005070 S.RESISTOR
R163 7030005060 S.RESISTOR
R164 7030005110 S.RESISTOR
R165 7030005600 S.RESISTOR
R166 7030005530 S.RESISTOR
R167 7030005170 S.RESISTOR
R168 7030007350 S.RESISTOR
R171 7030005070 S.RESISTOR
R172 7030005070 S.RESISTOR
R173 7030005100 S.RESISTOR
R174 7030005600 S.RESISTOR
R175 7030009290 S.RESISTOR
R176 7030005240 S.RESISTOR
R177 7030008290 S.RESISTOR
R178 7030005600 S.RESISTOR
R179 7030005600 S.RESISTOR
R180 7030007340 S.RESISTOR
R181 7030005600 S.RESISTOR
R182 7030005600 S.RESISTOR
R183 7030005030 S.RESISTOR
R184 7030008010 S.RESISTOR
R185 7030005310 S.RESISTOR
R186 7030005070 S.RESISTOR
R187 7030005040 S.RESISTOR
R188 7030005090 S.RESISTOR
R189 7030005000 S.RESISTOR
R190 7030005090 S.RESISTOR
R192 7030005090 S.RESISTOR
R193 7210003060 VARIABLE
R195 7030005040 S.RESISTOR
R196 7030005050 S.RESISTOR
R197 7030005040 S.RESISTOR
R198 7030005050 S.RESISTOR
R199 7030005040 S.RESISTOR
R200 7030005050 S.RESISTOR
R201 7030007290 S.RESISTOR
R202 7030005120 S.RESISTOR
R203 7030005050 S.RESISTOR
R206 7030004980 S.RESISTOR
R207 7030005220 S.RESISTOR
R208 7030007340 S.RESISTOR
R209 7030005230 S.RESISTOR
R210 7030006610 S.RESISTOR
R211 7030007570 S.RESISTOR
R212 7030003830 S.RESISTOR
R215 7030005090 S.RESISTOR
R216 7030005090 S.RESISTOR
R217 7030005000 S.RESISTOR
R218 7030007350 S.RESISTOR
R219 7030005050 S.RESISTOR
R220 7030005090 S.RESISTOR
R221 7030005060 S.RESISTOR
R222 7030005090 S.RESISTOR
R223 7410000580 S.ARRAY
R224 7030005090 S.RESISTOR
R225 7030005090 S.RESISTOR
R226 7510001470 S.THERMISTOR
R227 7030005090 S.RESISTOR
R228 7030010080 S.RESISTOR
R229 7030010080 S.RESISTOR
R230 7030008010 S.RESISTOR
R231 7030008010 S.RESISTOR
R232 7030008010 S.RESISTOR
R233 7030005090 S.RESISTOR
R234 7030005050 S.RESISTOR
R235 7030005120 S.RESISTOR
R236 7410000950 S.ARRAY
R237 7410000950 S.ARRAY
R238 7410000950 S.ARRAY
R239 7410000770 S.ARRAY
R240 7410000770 S.ARRAY
R241 7410000770 S.ARRAY
R242 7410000700 S.ARRAY
R243 7410000900 S.ARRAY
R244 7410000950 S.ARRAY
[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H]: H-band, [M]: ML and MH bands,
[GT]: IC-F40GT/F41GT, [GS]: IC-F40GS/F41GS, [F40G]: IC-F40GT/F40GS,
[F41G]: IC-F41GT/F41GS, [IS]: Intrinsically safe version
DESCRIPTION
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
TP76N00N-15F-10KA-2251
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 394 X (390 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ3GEYJ 185 V (1.8 MΩ)
ERJ2GEJ 104 X (100 kΩ) [GS] only
ERJ2GEJ 104 X (100 kΩ) [GT] only
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 104 X (100 kΩ)
EXB-V4V 224JV (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
NTCG20 4AG 473JT
ERJ2GEJ 104 X (100 kΩ)
ERJ2RHD 104 X (100 kΩ)
ERJ2RHD 104 X (100 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
EXB-V8V 102JV
EXB-V8V 102JV
EXB-V8V 102JV
EXB-V4V 102JV (1 kΩ)
EXB-V4V 102JV (1 kΩ)
EXB-V4V 102JV (1 kΩ)
EXB-V8V 105JV (1 MΩ)
EXB-V4V 105JV (1 MΩ)
EXB-V8V 102JV
[MAIN UNIT]
REF ORDER
NO. NO.
R245 7410000770 S.ARRAY
R246 7410000950 S.ARRAY
R247 7410000950 S.ARRAY
R248 7030005120 S.RESISTOR
R249 7410000950 S.ARRAY
R250 7410000770 S.ARRAY
R251 7410000950 S.ARRAY
R252 7410000950 S.ARRAY
R253 7410000750 S.ARRAY
R254 7030008300 S.RESISTOR
R257 7030005220 S.RESISTOR
R258 7030005220 S.RESISTOR
R259 7030007350 S.RESISTOR
R260 7030005240 S.RESISTOR
R261 7030005240 S.RESISTOR
R262 7030009290 S.RESISTOR
R264 7030005000 S.RESISTOR
R266 7030005240 S.RESISTOR
R267 7030005240 S.RESISTOR
R268 7030004980 S.RESISTOR
R269 7030005310 S.RESISTOR
R270 7030008290 S.RESISTOR
R271 7030005110 S.RESISTOR
R272 7030005070 S.RESISTOR
R273 7030005220 S.RESISTOR
R274 7030005220 S.RESISTOR
R275 7030005220 S.RESISTOR
R276 7030004970 S.RESISTOR
R277 7030005800 S.RESISTOR
R278 7030005120 S.RESISTOR
R279 7030005120 S.RESISTOR
R280 7030005120 S.RESISTOR
R281 7030005600 S.RESISTOR
R283 7030005090 S.RESISTOR
R284 7030005120 S.RESISTOR
R285 7030005050 S.RESISTOR
R288 7030005530 S.RESISTOR
R289 7030005090 S.RESISTOR
R291 7030005090 S.RESISTOR
R292 7030009290 S.RESISTOR
R293 7030005090 S.RESISTOR
R294 7030005240 S.RESISTOR
R295 7030005240 S.RESISTOR
R296 7030005240 S.RESISTOR
R297 7410000950 S.ARRAY
R298 7030005090 S.RESISTOR
R299 7030005120 S.RESISTOR
R307 7030005090 S.RESISTOR
R312 7030005220 S.RESISTOR
R313 7030005060 S.RESISTOR
R314 7030005060 S.RESISTOR
R315 7030005060 S.RESISTOR
R316 7030009140 S.RESISTOR
R317 7030005170 S.RESISTOR
R318 7030005060 S.RESISTOR
R321 7030007290 S.RESISTOR
7030005030 S.RESISTOR
R322 7410000710 S.ARRAY
R323 7030005090 S.RESISTOR
R324 7030005000 S.RESISTOR
R325 7030005820 S.RESISTOR
R326 7030005120 S.RESISTOR
R327 7030005120 S.RESISTOR
7030009280 S.RESISTOR
R329 7030005050 S.RESISTOR
R330 7030009320 S.RESISTOR
R331 7030005170 S.RESISTOR
R332 7030005090 S.RESISTOR
R333 7030005090 S.RESISTOR
R334 7030005080 S.RESISTOR
R336 7030005600 S.RESISTOR
R337 7030005120 S.RESISTOR
R338 7030007570 S.RESISTOR
R339 7030007570 S.RESISTOR
R340 7030007570 S.RESISTOR
R342 7030007300 S.RESISTOR
R343 7030007570 S.RESISTOR
R346 7030007570 S.RESISTOR
R347 7030007570 S.RESISTOR
R348 7030007570 S.RESISTOR
R349 7030007570 S.RESISTOR
R350 7030007570 S.RESISTOR
*=Safety critical components
6 - 4
DESCRIPTION
EXB-V4V 102JV (1 kΩ)
EXB-V8V 102JV
EXB-V8V 102JV
ERJ2GEJ 102 X (1 kΩ)
EXB-V8V 102JV
EXB-V4V 102JV (1 kΩ)
EXB-V8V 102JV
EXB-V8V 102JV
EXB-V4V 104JV (100 kΩ)
ERJ2GEJ 184 X (180 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 470 X (47 Ω)
RR0510P-102-D (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
EXB-V8V 102JV
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 222 X (2.2 kΩ) [L], [M]
ERJ2GEJ 152 X (1.5 kΩ) [H]
EXB-V8V 224JV (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 471 X (470 Ω)
RR0510P-103-D (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ) [L]-F41G
ERJ2GE 391 X (390 Ω)
other
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
S.=Surface mount
