4. Two Din Mounting Dimension

1. MIC
2. Power ON/OFF
3. Mute
4. VOL-
5. VOL+
6. USB Port
7. LCD Touch screen
8. IR Receiver
9. Down Slide
10. Up Slide
11. Eject
12. Reset
Diagram of panel 02
1. Power ON/OFF
2. MODE
3. IR RECEIVER
4. LCD Touch Screen
5. Down Slide
6. Select
7. UP Slide
8. Reset
9. Eject
10. USB Port
Diagram of panel 03
1. LCD Touch Screen
2. IR Receiver
3. Power ON/OFF
4. SEL
5. VOL-
6. VOL+
7. UP Slide
8. Down Slide
9. Eject
10. MUTE
11. Reset
12. USB Port
Diagram of panel 01
