Xtrons TD714GT User Manual

7" 1080p video hd digital motorized touch screen gps double din car dvd player dj series

Advertisement

Quick Links

DJ Series User Manual
REV0.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the TD714GT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Xtrons TD714GT

  • Page 1 DJ Series User Manual REV0.0...
  • Page 2 Common Troubleshooting Guide Reason Solution Fault Using the same insurance Power fuse was burnt. with main unit to replace No boot up. After pressing the RESET key Other factors caused the with a small nib on the face microprocessorincorrect panel, power on again. operation After ignition starting The BATT of ACC ignition...
  • Page 3 Hua Wei E220 Hua Wei E1750(Modem:COM6,ATCMD:COM8,COM7 not use) Hua Wei E1550 Hua Wei E156G(Modem:COM6,ATCMD:COM7) Hua Wei Vodafone K3765(Modem:COM6,ATCMD:COM9,COM7&COM8 not use) Hua Wei Vodafone K3565-Rev2(Modem:COM6,ATCMD:COM7) ZTE Vodafone K3565-Z(Modem:COM6,ATCMD:COM7,COM8&COM9 not use) ZTE Vodafone K4505-Z(Modem:COM6,ATCMD:COM7&COM9,COM8 not use) ZTE MF637U(Modem:COM6,ATCMD:COM7,COM9 not use) MOBIDATA HSPA-500HU SAMELINE UM200(Modem:COM6,ATCMD:COM7,COM8&COM9 not use) Vtion E1916(Modem:COM6,ATCMD:COM7,COM9 not use) 2.
  • Page 4 3G settings Enter into 3G settings: On the screen,please click "Settings" icon of main interface to enter into the system setting interface ,Dragging the option bar up and down to find "APN" setting option . Unicom: Telecommunications/Telecom: Network access point : 3GNET Network Access Point: ( empty ) Phone Number : * 99 # Phone Number : # 777...
  • Page 5 USB-IMUSIC installation diagram/Instruction ( optional ) This unit supports USB-IMUSIC function,which only supports our company's USB-IMUSIC products .When using it, please insert USB-IMUSIC into the jack which is marked with the word of LICENSE on the back of this device,then inserting Apple audio device into the jack which is marked with the word of MEDIA in the tail ,then,you can use it now.
  • Page 6 Map installation and parameter(specification) M ap i nst allat ion s teps: 1.Users can insert the SD card of pre-installed GPS navigation map software into the GPS card slot on the face panel of this device(unit). 2.On the screen, please click the "Settings" icon of main interface to enter into the system settings interface,dragging the options bar up and down to find the settings option of"...
  • Page 7 Steering wheel control connections instruction. Enter i nto t he s teer ing w heel c ont rol: Please click the "Settings" icon to enter into the system setup interface on the screen, then,dragging option bar up and down to find the settings option of " How to learn steering wheel control "...
  • Page 8 ARM software upgrade instructions Copying ARM softwares(total 7pcs files, see picture 1) into SD card and please ensure the SD card is full empty. Under the device was powered off, inserting the SD card into this device's GPS card slot,then,turning on the device (unit), at this time, the device(unit) will automatically search files to run upgrade (see picture 2), after it completes the upgrade successfully, it will switch to main UI interface automatically, then, you can use it now.
  • Page 9 MCU Software Upgrade Instructions Copying MCU softwares (total two files )into the SD card ( please ensure the SD card is full empty ) , then, inserting into the device's GPS card slot, then,on the screen, please click "Settings" icon of the main interface, thus, it will enter into system setup interface, dragging the option bar up and down to find the settings option of "...
  • Page 10 The notes about the full unit's connection diagram ◆ The product is used for such cars with 12V batter y and negative grounding , before installing this product on these cars with 24V batteries,such as truck ,bus, big coach etc.cars), please install the reduction voltage equipment firstly. ◆...
  • Page 11: Functions And Features

    Functions and features DVD disc playing functions. ◆ Be compatible with DVD-R, DVD-RW, DVD + R, DVD + RW, CD-R,CD-RW CD-DA, MP3, WMA, SVCD, VCD and MPEG1, MPEG2,MPEG4, JPEG format discs . USB/SD card playing functions ◆ Be compatible with DVD-R, DVD-RW, DVD + R, DVD + RW, CD-R,CD-RW CD-DA, MP3, WMA, SVCD, VCD and MPEG1, MPEG2,MPEG4, JPEG format discs .
  • Page 12: Platform Features

    Platform features ◆ 1080p Full format decoding , which can decode the vast majority of film sources. ◆ Supports lossless musics . ◆ Full-digital DVD, no analog signal, shows is absolutely clear. ◆ Real 5.1 sound channel. ◆ Audio DSP processing , 10 -band EQ to enhance the listening experience ◆...
  • Page 13 Warning 1.Do not expose the unit in the damp environment to prevent from fire or electric shock accident. 2.Any change or modification to this unit without the clear priorconsent of the authorization party may bring inconvenience to the users. 3.This unit is made up of high-precision accessories,do not dismantle the device or adjust any accessories inside this device ifwithout authorization.
  • Page 14: Safety Warning

    Thank patronage! Thank you ver y much for purchasing and using our digital car audio-visual series products! To ensure you can use this product correctly,please read this user manual carefully before use it and keep it well for your future reference. Safety Warning ●...
