3002659/01
INSTALLER'S AND OWNER'S GUIDE
For
Electric Heater
Model 802
We trust that this Guide gives sufficient details to enable the appliance to be installed and
maintained satisfactorily. However, if further information is required, our Valor
Technical Helpline will be pleased to help.
Please telephone 08706 061 065 (National call rates apply in the United Kingdom).
KEEP IN A SAFE PLACE FOR FUTURE REFERENCE
©
Valor Heating
Advertisement
Table of Contents
Related Manuals for Valor alisa 802
Summary of Contents for Valor alisa 802
- Page 1 Model 802 We trust that this Guide gives sufficient details to enable the appliance to be installed and maintained satisfactorily. However, if further information is required, our Valor Technical Helpline will be pleased to help. Please telephone 08706 061 065 (National call rates apply in the United Kingdom).
-
Page 2: Customer Care
INSTALLER’S AND OWNER’S GUIDE CUSTOMER CARE All our heaters are designed to meet the most stringent quality, performance and safety requirements to provide our customers with many years of trouble free service. This guide aims to improve your understanding and appreciation of your new heater, by providing simple and informative instructions to enable you to install it and to ensure that you benefit from the excellent performance and features it has to offer. -
Page 3: Installation
INSTALLER’S AND OWNER’S GUIDE INSTALLATION Figure 1. Appliance Dimensions Location This heater is intended for use in a fireplace opening generally conforming to British Standard 1251 for a nominal 400mm (16 inch) or 450mm (18 inch) Fireplace. It may also be located in other fireplace openings or in a wooden surround, where the following dimensions are available. - Page 4 INSTALLER’S AND OWNER’S GUIDE The heater must not be located under a fixed electrical socket, the socket must always be accessible in order to disconnect the heater from the electrical supply for maintenance or when replacing a lamp. • Important! This appliance must be earthed. •...
- Page 5 INSTALLER’S AND OWNER’S GUIDE The heater body should be fixed in position before the front surround is finally fitted. Please study the illustrations carefully to avoid damage to the heater. Front Removal Carefully remove the front surround by lifting upward and forward (See figure 2).
- Page 6 INSTALLER’S AND OWNER’S GUIDE Method B – Wire Fix The fixing kit includes a steel wire and eyebolt to attach the heater to the back of the fireplace opening. Mark the position for the eyebolt at the back of the fireplace opening equal to the centre line of the heater and at a height of 533 –...
- Page 7 INSTALLER’S AND OWNER’S GUIDE Fitting the Front Carefully locate the bottom sides of the front surround into the side brackets on the heater body. Holding the top of the surround push it towards the top of the heater body. The top of the surround should locate over the top central bracket on the heater body.
-
Page 8: Operating Your Heater
INSTALLER’S AND OWNER’S GUIDE OPERATING YOUR HEATER Never cover the heater - there is a risk of fire if covered. The heater is operated by three switches located below the canopy. Switch 1 = Main On – Off In the On position only the fuel effect light operates ❙... -
Page 9: Maintaining Your Fire
INSTALLER’S AND OWNER’S GUIDE MAINTAINING YOUR FIRE Always disconnect the heater from the electricity supply by removing the 3 pin plug and allowing the heater to cool before undertaking maintenance or replacing lamps. Lamp Replacement The lamps fitted to this heater are long life types, but due to the indeterminate life span and ease of replacement are specifically excluded from the guarantee. - Page 10 INSTALLER’S AND OWNER’S GUIDE Valor Technical Helpline If you require any further assistance please call the Valor Technical Helpline on 08706 061 065 To help us quickly help you, please try to have the following information available before you contact us.
