INSTALLER AND OWNER GUIDE
Model 807
Electric Heater
Fitted with the following fascia
Adage
Victorian
or
Dream
This guide is intended to help you install and care for your Valor electric heater. Please
read carefully before installing and using your heater. However, if further information is
required, our Valor Technical Helpline will be pleased to help.
Telephone 08706 061 065 (National call rates apply in the United Kingdom)
In the Republic of Ireland call 0044 08706 061 065
Important: Please keep your guide in a safe place for future reference
© Valor Heating
Advertisement
Table of Contents
Related Manuals for Valor 807
Summary of Contents for Valor 807
- Page 1 Victorian Dream This guide is intended to help you install and care for your Valor electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Valor Technical Helpline will be pleased to help.
- Page 2 INSTALLER AND OWNER GUIDE Safety First. Valor fires are CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence. At the heart of every Valor heater. All Valor fires are manufactured to the highest standards of quality and excellence and are manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.
-
Page 3: Handling And Unpacking
INSTALLER AND OWNER GUIDE HANDLING AND UNPACKING Before continuing any further with the installation of this heater please read the following: Unpacking Dream Heater. This heater has a fascia which is heavy (13.35 kG). To avoid damage it is packed in a separate box within the main box. When unpacking it is important that the box containing the fascia is removed before the main body of the heater. - Page 4 Always make sure the heater is firmly secured to prevent it from being tipped over. Always use a fireguard when young children and infirm persons can come into contact with the heater. Always use genuine Valor spares. Never Never leave children unsupervised in a room where the heater is ON and unguarded.
- Page 5 INSTALLER AND OWNER GUIDE Where can I fit the heater? This heater can be fitted into fireplaces or surrounds where the following dimensions are available. Width 390mm - 450 mm (15.35 inches - 17.72 inches) Height 555mm - 590 mm (21.9 inches - 23.2 inches) Depth At least 75mm (At least 3 inches) There should be at least 30mm (1.2 inches) clearance between the top of the fascia and...
- Page 6 Item 4 If the mains cable is damaged, to avoid a hazard it Figure 1. Removing and must be replaced by a Valor authorised service agent, positioning the cable guide. or similarly qualified person (See the last page of this guide for useful telephone numbers).
-
Page 7: Removing The Fascia
INSTALLER AND OWNER GUIDE Removing the fascia Victorian Heater 1. Remove the two fascia securing screws (See figure 2). Remove the front fascia by gently pulling the base of the fascia forward whilst lifting clear of the support brackets at the top of the heater (See figure 2). - Page 8 INSTALLER AND OWNER GUIDE Method A - Screw fixing Note - If fixing to marble it is recommended that Method B - ‘Wire fixing’ is used. Drilling marble without the correct tools and experience may result in the marble cracking. 1.
- Page 9 INSTALLER AND OWNER GUIDE side of the heater. Continue to push the wire through this hole until there is only a small loop of wire at the front of the heater (See figure 6 - item 3). 9. At the back of the heater there will be a long piece and a short piece of wire coming through the two holes.
- Page 10 INSTALLER AND OWNER GUIDE spacer frame is removed. 3. Remove the spacer frame. 4. Drill appropriate sized holes in the marked position. 5. Insert a wallplug into the drilled holes. 6. Place the spacer frame so that the holes in the brackets are in line with the wallplugs in the fixing surface.
- Page 11 INSTALLER AND OWNER GUIDE How will I know which position to set the light bulb shroud? Positioning the dark area of the shroud underneath the light bulb will reduce the amount of light onto the hearth or floor surface. Positioning the dark area to the rear of the light bulb will reduce the amount of light to the flame effect at the rear of the heater.
-
Page 12: Fitting The Dream Fascia
INSTALLER AND OWNER GUIDE figure 13) 4. Place the loose coals onto the fuel support (a glove is provided with the coal pack). It is not necessary to use all the coal supplied. Fitting the Dream Fascia Note: A certain amount of self-assembly is required in building up this fascia. - Page 13 INSTALLER AND OWNER GUIDE Figure 16. Page 13...
- Page 14 INSTALLER AND OWNER GUIDE Assembling the Dream Fascia Step 1. Locate the hood into the brackets at the top of the casting and secure with 4 off screws 'A' (See figure 14 & 16 - step 1). Step 2. Locate the lower brackets onto the fascia and secure with 3 off screws 'B' and 1 off screw 'C' as in figure 16 - step 2.
-
Page 15: Using The Heater
INSTALLER AND OWNER GUIDE USING THE HEATER Important Safety Never cover the heater or obstruct the openings at the base of the heater, this could cause overheating and consequent risk of fire. What are the three switches for? The heater is operated by three switches located below the hood on the left hand side of the heater. - Page 16 INSTALLER AND OWNER GUIDE The light bulb fitted to this heater is a long life compact fluorescent type, but due to the indeterminate life span and ease of replacement, it is specifically excluded from the guarantee. To replace the light bulb. 1.
- Page 17 4. I Have a problem that is different to those in the previous examples 1- 3. Below is a list of Useful Telephone numbers For general advice about your heater: VALOR TECHNICAL HELPLINE 08706 061 065. To report faults or arrange for your heater to be serviced: VALOR SERVICE 08706 090 081.
