5112253/01
OWNER GUIDE
Model BR660VA
Heat Engine
POWER FLUE INSET GAS FIRE
(GC No. 32-032-44)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
WHEN CONVERTED USING CONVERSION KIT NO. 0591149 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31).
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
For technical advice firstly contact your retailer. If further advice is required then call
0161703 8157 for The Midlands and North or
01462 813 138 for The South.
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference
This guide to be left with the owner
© Baxi Heating U.K. Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BR660VA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baxi BR660VA

Summary of Contents for Baxi BR660VA

  • Page 1 01462 813 138 for The South. This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference This guide to be left with the owner © Baxi Heating U.K. Ltd.
  • Page 2 Installer Guide and should not be fitted directly on to a carpet. Baxi Fires Division, Erdington, Birmingham B24 9QP Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication...

  • Page 3: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Section Page SAFETY GAS CONSUMPTION OPERATING YOUR FIRE How to light your fire. How to turn your fire off. The flame sensing & flue blockage safety system. CLEANING YOUR FIRE Metal parts. Ceramic fuel effect and burner compartment rear wall. Ceramic burner.

  • Page 4: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.
  • Page 5 OWNER GUIDE within the fascia and flanges of the fire box. Do Switch the fire and fan off and allow to cool before attempting to clean, service, etc. This appliance retains heat for some time after it has been switched off Do always use a fireguard complying with BS 8423 for the protection of young children, the elderly or infirm.

  • Page 6: Gas Consumption

    Has a minimum natural gas input of 2.2kW (Gross) Has a minimum natural gas output of 1.1kW Model BR660VA when converted using kit number 0591149 Has a maximum propane gas input of 6.1kW (Gross) Has a maximum propane gas output of 3.6kW Has a minimum propane gas input of 3.6kW (Gross)

  • Page 7: How To Turn Your Fire Off

    OWNER GUIDE until you feel some resistance. Keep the knob depressed at this position for a few seconds to allow gas to flow to the pilot. While keeping the knob depressed, turn to the "PILOT/IGN" position. While turning, a spark should light the pilot. The pilot flame can be seen through the ceramic fuel effect at the front left side.

  • Page 8: Cleaning Your Fire

    OWNER GUIDE The system includes a probe that senses the heat from the pilot flame. If this probe is cool, the system will prevent any gas flow unless the control knob is kept depressed at the "PILOT/IGN" position. The system also includes an atmospheric pressure detector. This will shut off the gas supply if the fan is not working.

  • Page 9: Ceramic Burner

    OWNER GUIDE installer and owner guide. Ceramic burner. Remove any soot or other foreign matter from the solid areas of the burner with a dry soft brush. Be careful not to brush any particles into the open slots. Remove any particles from the slots with a vacuum cleaner fitted with a soft brush attachment.

  • Page 10: Servicing

    OWNER GUIDE Servicing. IMPORTANT To help us quickly help you, please try to have the following information available before you contact us: Type of fire. Model/Name. Serial Number. You will also be asked for the fault, problem or request plus your Post Code. If you wish to replace any of the ceramic fuel effect pieces, spare parts are available nationwide via the ‘interpart stockist network’.
