Installation and Operation Manual
DA-S6802+DL / DA-SR6802+DL /
DA-H6802+DL / DA-HR6802+DL
1×8 Looping Input SD/ASI Distribution
Amplifiers / 1×8 Looping Input SD/ASI
Distribution Amplifiers with Reclocking /
1×8 Looping Input 3 Gb/s, HD-SDI, SD-SDI,
and ASI Distribution Amplifiers / 1×8 Loop-
ing Input 3 Gb/s, HD-SDI, SD-SDI, and ASI
Distribution Amplifiers with Reclocking
Edition A
175-100071-00
Delivering the Moment
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Imagine DA-HR6802+DL
Summary of Contents for Imagine DA-HR6802+DL
- Page 1 Installation and Operation Manual DA-S6802+DL / DA-SR6802+DL / DA-H6802+DL / DA-HR6802+DL 1×8 Looping Input SD/ASI Distribution Amplifiers / 1×8 Looping Input SD/ASI Distribution Amplifiers with Reclocking / 1×8 Looping Input 3 Gb/s, HD-SDI, SD-SDI, and ASI Distribution Amplifiers / 1×8 Loop-...
-
Page 2: Contact Information
This publication does not in any way warrant description accuracy or guarantee the use for the product to which it refers. Imagine Communications reserves the right, without notice to make such changes in equipment, design, specifications, components, or documentation as progress may warrant to improve the performance of the product. -
Page 3: Installation And Operation Manual
DA-SR6802+DL:1×8 Looping Input SD/ASI Distribution Amplifiers with Reclocking DA-H6802+DL: 1×8 Looping Input 3 Gb/s, HD-SDI, SD-SDI, and ASI Distribution Amplifiers DA-HR6802+DL: 1×8 Looping Input 3 Gb/s, HD-SDI, SD-SDI, and ASI Distribution Amplifiers with Reclocking Installation and Operation Manual Edition A... -
Page 5: Table Of Contents
Product Description ....................1 Main Features ......................1 DA-S6802+DL ....................1 DA-SR6802+DL ....................2 DA-H6802+DL ....................2 DA-HR6802+DL ..................... 2 Back Modules ......................3 Signal Flow....................... 4 Chapter 2: Installation and Operation Installation Procedures ..................... 5 Unpacking the Module ..................5 Setting Jumpers .................... - Page 6 Contents Setting Locally Controlled Parameters ............9 Setting Remotely Controlled Parameters ............10 Recalling Default Parameter Settings ............10 Reading Software and Hardware Versions ............ 11 LEDs and Alarms ....................11 Module Status Indicator LED ................ 11 Module-Specific LEDs ................... 12 Alarms ......................
-
Page 7: Preface
• DA-H6802+DL: 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI distribution amplifiers • DA-HR6802+DL: 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI distribution amplifiers with reclocking Audience This manual is written for engineers, technicians, and operators responsible for the installation, setup, and / or operation of the DA-S/SR/H/HR6802+DL distribution amplifiers. -
Page 8: Writing Conventions
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Preface Writing Conventions To enhance your understanding, the authors of this manual have adhered to the following text conventions: Table P-2. Manual Style and Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus,... -
Page 9: Unpacking/Shipping Information
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Preface Unpacking/Shipping Information Unpacking a Product This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble free service. 1. Check equipment for any visible damage that may have occurred during transit. -
Page 10: Safety Standards And Compliances
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Preface Safety Standards and Compliances See the 6800+ Safety Instructions and Standards Manual to find the safety standards and compliances for this 6800+ series product. A safety manual is shipped with every host frame installation and operation manual and can be downloaded from our website. -
Page 11: Restriction On Hazardous Substances (Rohs) Directive
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Preface Restriction on Hazardous Substances (RoHS) Directive Directive 2002 / 95 / EC—commonly known as the European Union (EU) Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain substances found in electrical and electronic equipment. -
Page 12: Waste From Electrical And Electronic Equipment (Weee) Directive
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Preface Waste from Electrical and Electronic Equipment (WEEE) Directive The European Union (EU) Directive 2002 / 96 / EC on Waste from Electrical and Electronic Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of electrical and electronic waste products. -
Page 13: Chapter 1: Introduction
The DA-H6802+DL is a 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI distribution amplifier • The DA-HR6802+DL is a 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI distribution amplifier with reclocking You can control and monitor these distribution amplifier modules locally (via jumpers and card-edge LEDs) or remotely (via optional ICE6800+ or 6800+ETH Ethernet connection). -
Page 14: Da-Sr6802+Dl
• Automatic input cable equalization • Card edge control by jumpers with LED display • Remote control and monitoring via Ethernet DA-HR6802+DL • One input, eight reclocked outputs, one looping output • Passive looping • Handles data rates 3.0 Gb/s and below •... -
Page 15: Back Modules
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Back Modules DA-S/SR/H/HR6802+DL modules can be installed with double-width looping back modules in their host frames. These modules cannot be installed in 6800 / 7000 series frames. Figure 1-1 shows the double-width looping back connector module used by the DA-S/SR/H/HR6802+DL. -
Page 16: Signal Flow
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Signal Flow Figure 1-2. Signal Flow Diagram DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation... -
Page 17: Chapter 2: Installation And Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2 Installation and Operation Installation Procedures Caution Before installing this product, read the 6800+ Series Safety Instructions and Standards manual shipped with every host frame installation and operation manual, or downloadable from our website. This safety manual contains important information about the safe installation and operation of 6800+ series products. -
Page 18: Maximum 6800+ Frame Power Ratings
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Figure 2-1. J1 Jumper Set Location Maximum 6800+ Frame Power Ratings Power consumption information is listed in Chapter 3: “Specifications” on page Table 2-1 describes the maximum allowable power ratings for 6800+ frames. Note the given maximums before installing any 6800+ modules in your frame. -
Page 19: Installing 6800+ Modules
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Installing 6800+ Modules Back Module Types The DA-S/SR/H/HR6802+DL modules have double-width back modules (see Figure 1-1 on page 3). See the host frame installation and operation manual for details on back module installation. -
Page 20: Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Operation Operating Notes When you change a control parameter on a DA-S/SR/H/HR6802+DL module, the effect is immediate. However, the module requires up to 20 seconds to save the latest change. -
Page 21: Setting Locally Controlled Parameters
In the local control reclock setting operation mode, all of the settings’ data status information appears on the CCS control software application control screen; however, you cannot change any setting in this mode via the CCS control software application. Table 2-2. DA-SR6802+DL and DA-HR6802+DL Local Control Reclock Modes Reclock Mode Description AUTO (Default) Automatically detects the rate;... -
Page 22: Setting Remotely Controlled Parameters
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Setting Remotely Controlled Parameters Table 2-3 describes parameters that are accessible remotely. Select remote control mode by setting the J1 jumper to “Remote.” See your CCS control software application manual or online help for more information on setting and monitoring these parameters remotely. -
Page 23: Reading Software And Hardware Versions
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Reading Software and Hardware Versions The current software version of your DA-S/SR/H/HR6802+DL module can only be viewed using a CCS-enabled control panel or a CCS software application. -
Page 24: Module-Specific Leds
3.0G Green Input signal is relocked at 2.97 Gb/s Input signal is not relocked at 2.97 Gb/s Operational on DA-SR6802+DL and DA-HR6802+DL modules only † Operational on DA-HR6802+DL modules only DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation... -
Page 25: Alarms
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation Alarms If an alarm is triggered within your DA-S/SR/H/HR6802+DL module, the Status LED will turn amber. Alarms are usually logged and monitored within the available 6800+ software control applications. - Page 26 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation and Operation DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation...
-
Page 27: Chapter 3: Specifications
0–1,066 ft (0-325 m) Belden 1694A or equivalent 1.5 HD-SDI 0–459 ft (0-140 m) Belden 1694A or equivalent 3.0 HD-SDI 0–230 ft (0-70 m) Belden 1694A or equivalent DA-H6802+DL and DA-HR6802+DL only DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation... -
Page 28: Outputs
Rise and fall time SD-SDI/ASI 400-700 ps 1.5 HD-SDI < 270 ps 3.0 HD-SDI < 135 ps Overshoot < 10% Reclocking 2.97 Gb/s , 1.485 Gb/s , 270 Mb/s DA-H6802+DL and DA-HR6802+DL only DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation... -
Page 29: Performance
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Specifications Performance Table 3-3. Performance Specifications Item Specification Jitter 0.2 UI 1.5 HD 0.2 UI 3.0 HD 0.3 UI Propagation < 1.0 ns (for reference only) Power Consumption Power consumption for DA-S/SR/H/HR6802+DL modules is <... - Page 30 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Specifications DA-S/SR/H/HR6802+DL Installation and Operation Manual Copyright © 2009, Harris Corporation...
-
Page 31: Index
Index Keywords Introduction module descriptions Adjustable parameters 8 back modules 3 Alarms product description 1 configuring parameters 10 signal flow diagrams 4 definitions 13 Jumpers Back connectors. See Back modules J1 5 Back modules setting jumpers 5 Connections 7 LEDs descriptions 11–12 module specific 12 Descriptions... - Page 32 Index lists 9–10 RoHS directive ix recalling settings 10 standards viii setting parameters 9–10 symbols viii types 8 terms viii reading WEEE directive x hardware versions 11 Setting jumpers 5 software versions 11 Shipping information vii Output specifications 16 Signal flow diagrams 4 Software versions, reading 11 Specifications input 15...
