- Page 1 Installation and Operation Manual VTM6801+ Three-Channel Serial Monitoring Distribution Amplifier Edition A 175-000412-00 Delivering the Moment...
-
Page 2: Contact Information
This publication does not in any way warrant description accuracy or guarantee the use for the product to which it refers. Imagine Communications reserves the right, without notice to make such changes in equipment, design, specifications, components, or documentation as progress may warrant to improve the performance of the product. - Page 3 VTM6801+ Three-Channel Serial Monitoring Distribution Amplifier Installation and Operation Manual Edition A December 2007...
-
Page 5: Table Of Contents
Contents Preface Manual Information ................vii Purpose ................... vii Audience ..................vii Revision History ................vii Writing Conventions ..............viii Obtaining Documents ..............viii Unpacking/Shipping Information ............ix Unpacking a Product ............... ix Product Servicing ................ix Returning a Product ................ ix Restriction on Hazardous Substances (RoHS) Compliance ....x Waste from Electrical and Electronic Equipment (WEEE) Compliance xi Safety .................... - Page 6 Contents Checking the Packing List ............. 11 Setting the Jumper ................. 12 Installing 6800+ Modules ..............14 Required Frames and Back Connector Types ........ 14 Installing and Removing VTM6801+ Modules ......14 Chapter 3: Operation Overview ....................15 Understanding Card-Edge Controls ............16 Introducing Controls Types ............
- Page 7 Contents + Pilot Lite Cannot Control a Module Showing in the Control Window ..............32 + Pilot Lite Status Bar Reports “Not Ready” .........32 CCS Software Application or Remote Control Panel Does Not Communicate with Module ............33 Alarm Query Fails When a Device Reboots ........33 Hardware Communication and Control Issues ........34 Frames Fail to Communicate with the PC after a Power Failure ...34 Module Does Not Seem to Work ............34...
- Page 8 Contents VTM6801+ Installation and Operation Manual...
-
Page 9: Preface
Preface Manual Information Purpose This manual details the features, installation, operation, maintenance, and specifications for the VTM6801+ Three-Channel Serial Monitoring Distribution Amplifier. Audience This manual is written for engineers, technicians, and operators responsible for installation, setup, maintenance, and/or operation of the VTM6801+ Three-Channel Serial Monitoring Distribution Amplifier. -
Page 10: Writing Conventions
Preface Writing Conventions To enhance your understanding, the authors of this manual have adhered to the following text conventions: Table P-2. Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus, windows, lists, and selection names Italics Indicates E-mail addresses, the names of books or... -
Page 11: Unpacking/Shipping Information
Preface Unpacking/Shipping Information Unpacking a Product This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble-free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3. -
Page 12: Restriction On Hazardous Substances (Rohs) Compliance
Preface Restriction on Hazardous Substances (RoHS) Compliance Directive 2002/95/EC—commonly known as the European Union (EU) Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain substances found in electrical and electronic equipment. The intent of this legislation is to reduce the amount of hazardous chemicals that may leach out of landfill sites or otherwise contaminate the environment during end-of-life recycling. -
Page 13: Waste From Electrical And Electronic Equipment (Weee) Compliance
Preface Waste from Electrical and Electronic Equipment (WEEE) Compliance The European Union (EU) Directive 2002/96/EC on Waste from Electrical and Electronic Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of electrical and electronic waste products. The objective of the WEEE Directive is to assign the responsibility for the disposal of associated hazardous waste to either the producers or users of these products. -
Page 14: Safety
Preface Safety Carefully review all safety precautions to avoid injury and prevent damage to this product or any products connected to it. If this product is rack-mountable, it should be mounted in an appropriate rack using the rack-mounting positions and rear support guides provided. It is recommended that each frame be connected to a separate electrical circuit for protection against circuit overloading. -
Page 15: Overview
Chapter 1 Introduction Overview The VTM6801+ is a three-channel serial monitoring distribution amplifier. It combines the functions of an equalizing, reclocking serial distribution amplifier, and a 4:2:2 to NTSC/PAL converter of 3 channels on a single distribution-amplifier sized card. The following topics are described in this chapter: •... -
Page 16: Vtm6801+ Module Product Description
Chapter 1: Introduction VTM6801+ Module Product Description The VTM6801+ monitors three serial digital video 4:2:2 isolated inputs. Each SDI input has one corresponding composite output and one corresponding copy output that is equalized and reclocked. You can set up, control, and monitor the VTM6801+ either locally via card-edge switches or remotely on a PC. -
Page 17: Module Descriptions
Chapter 1: Introduction Module Descriptions Front Module Figure 1-1 for an illustration showing a partial top view of the VTM6801+ module, and the general location of LEDs, switches, and jumpers. Gain pots switches Remote/local control jumper Channel LEDs Module Extractor status handle Figure 1-1. - Page 18 Chapter 1: Introduction For a brief description of the general VTM6801+ LEDs, switches, and jumpers, see Table 1-1. See Chapter 3: “Operation” for more information on specific VTM6801+ front module controls and jumpers. Table 1-1. Generic 6800+ Front Module Features Feature Description Module status...
-
Page 19: Back Connector
Chapter 1: Introduction Back Connector FR6802+ Frame Back Connector Figure 1-2 shows the double-slot back connector (VTM6801+DR) used by the VTM6801+ when installed in an FR6802+ frame. SDI IN 1 CMPST 1 SDI OUT 1 SDI IN 2 CMPST 2... - Page 20 Chapter 1: Introduction 6800/7000 Series Frame Back Connector Overlay Figure 1-3 shows the double-slot back connector overlay used by the VTM6801+ when installed in a 6800/7000 series frame. SDI IN 1 SDI OUT 1 CMPST 1 SDI IN 2 CMPST 2 SDI OUT 3 SDI OUT 2 CMPST 3...
-
Page 21: Signal Flow
Chapter 1: Introduction Signal Flow Figure 1-4 shows the basic signal flow of the VTM6801+: SD-SDI out 1 Serial Filter & Analog composite Equalizer Encoder SD-SDI in 1 decoder buffer video out 1 SD-SDI out 2 Serial Filter & Analog composite Equalizer Encoder SD-SDI in 2... - Page 22 Chapter 1: Introduction VTM6801+ Installation and Operation Manual...
-
Page 23: Overview
Chapter 2 Installation Overview This chapter describes the VTM6801+ installation process, including the following topics: • “Maximum 6800+ Frame Power Ratings” on page 10 • “Unpacking the Module” on page 11 • “Setting the Jumper” on page 12 • “Installing 6800+ Modules” on page 14 Caution Before installing this product, read the 6800+ Series Safety Instructions and Standards booklet that ships with every... -
Page 24: Maximum 6800+ Frame Power Ratings
Chapter 2: Installation Maximum 6800+ Frame Power Ratings The power consumption for the VTM6801+ module is typically less than 10 W. Table 2-1 describes the maximum allowable power ratings for 6800+ frames. Note the given maximums before installing any 6800+ modules in your frame. -
Page 25: Unpacking The Module
• One VTM6801+ Installation and Operation Manual • One VTM6801+ front module VTM6801+ D • One VTM6801+DR standard double-slot, 10-BNC back connector (for use in an FR6802+ frame) • One VTM6801+ Installation and Operation Manual • One VTM6801+DR standard double-slot, 10-BNC... -
Page 26: Setting The Jumper
Chapter 2: Installation Setting the Jumper The VTM6801+ module has one standard jumper (J1). Note You need to configure modules for local or remote operation prior to power-up. To change the configuration, first remove power from the module, reset the jumper, and then reapply power. Follow this procedure to set the J1 jumper for either local or remote control: 1. - Page 27 Chapter 2: Installation Remote control setting Local control setting Figure 2-2. The J1 Settings for Local and Remote Control Note The white triangle near the jumper pins on the module indicates pin 1. Table 1-1 on page 4 for more information on local/remote control jumper functionality.
-
Page 28: Installing 6800+ Modules
Chapter 2: Installation Installing 6800+ Modules Required Frames and Back Connector Types The VTM6801+ modules have double-width back connectors that can be installed in an FR6802+XF or FR6802+QXF frame. See the FR6802+ Frame Installation and Operation Manual for details on installing back connectors in an FR6802+ frame. Installing and Removing VTM6801+ Modules These modules require no specialized installation or removal procedures. -
Page 29: Overview
Chapter 3 Operation Overview This chapter describes how to operate the VTM6801+ using card-edge controls only. See the following documents for information on how to operate this product remotely: + Pilot Lite User Manual for serial control interface • • CCS™... -
Page 30: Chapter 3: Operation
Chapter 3: Operation Understanding Card-Edge Controls Introducing Controls Types You can operate and monitor settings for the VTM6801+ using the three banks of DIP switches and the LED indicators on the card edge of the module. As with all 6800+ products, external local or remote monitoring equipment (for example, a PC or control panel) is also required. - Page 31 Chapter 3: Operation Figure 3-1 for the location of these controls. Gain 1 pot Gain 2 pot Gain 3 pot S1 DIP switches S2 DIP switches S3 DIP switches J1 jumper Module Channel 1 LEDs Channel 2 LEDs Channel 3 LEDs Status LED Figure 3-1.
-
Page 32: Operating Notes
Chapter 3: Operation Operating Notes You can affect the composite output of each of the three channels by adjusting the DIP switches for each channel. Each of the three banks of DIP switches has the following five controls: Table 3-1. DIP Switch Functions Function Description Switch This setting controls standard selection. -
Page 33: Reading Hardware And Software Version
Chapter 3: Operation Table 3-2. DIP Switch Controls and LED Indicators (Continued) Switch Function Action Switch Position Setup Down Test Test off Test on Down B&W Black and white off Black and white on Down Reading Hardware and Software Version The current software version of your VTM6801+ module can only be viewed using a CCS-enabled control panel or a CCS software application, such as Pilot or + Pilot Lite. -
Page 34: Leds And Alarms
Chapter 3: Operation LEDs and Alarms Channel LEDs The VTM6801+ has 18 channel LEDs (6 for each channel) that serve as a quick reference to channel settings. See Table 3-3 for details about the channel LEDs. Table 3-3. Channel LEDs Function Color Description •... -
Page 35: Module Status Leds
Chapter 3: Operation Module Status LEDs Module status LEDs on the corner of the module light up if an error is detected. See Figure 3-1 for the location of these LEDs, and Table 3-4 for a definition of the LED colors. Table 3-4. - Page 36 Chapter 3: Operation VTM6801+ Installation and Operation Manual...
-
Page 37: Overview
Chapter 4 Specifications Overview The following specification tables appear in this chapter: • “Serial Digital Video Input” on page 24 • “Serial Digital Video Output” on page 25 • “Composite Analog Output” on page 25 • “Performance” on page 26 •... -
Page 38: Chapter 4: Specifications
Chapter 4: Specifications Input Serial Digital Video Input Table 4-1. Serial Digital Video Input Specifications Item Specification Format compatibility 4:2:2 serial component Connector BNC per IEC169-8 Impedance 75Ω Return loss >18 dB from 5 MHz to 270 MHz Signal level 800 mV ±10% Max. -
Page 39: Output
Chapter 4: Specifications Output Serial Digital Video Output Table 4-2. Serial Digital Video Output Specifications Item Specification Quantity 1 BNC per channel Connector BNC per IEC169-8 Overshoot <10% (all outputs terminated) Impedance 75Ω Return loss >18 dB to clock frequency Signal level 800 mV ±10% Jitter... -
Page 40: Miscellaneous
Chapter 4: Specifications Miscellaneous Performance Table 4-4. Performance Specifications Item Specification Processing delay 1.6µs Test signal Color bar: NTSC 100/7.5/75/7.5, PAL 100/0/75/0 Power Consumption The power consumption for the VTM6801+ module is typically less than 10 W. Start-up Time The start-up time for the VTM6801+ module is typically less than 1 second. -
Page 41: Appendix A: Communication And Control Troubleshooting Tips
Appendix A Communication and Control Troubleshooting Tips Overview Find the following troubleshooting information in this appendix: • “General Troubleshooting Steps” on page 28 • “Software Communication and Control Issues” on page 30 • “Hardware Communication and Control Issues” on page 34 •... -
Page 42: General Troubleshooting Steps
Appendix A: Communication and Control Troubleshooting Tips General Troubleshooting Steps Follow these steps in troubleshooting 6800+ product problems: 1. Review the “Software Communication and Control Issues” on page 30 outlined in this chapter. 2. Search this product manual and other associated documentation for answers to your question. -
Page 43: Control And Monitoring Using Ccs Software
Appendix A: Communication and Control Troubleshooting Tips Control and Monitoring Using CCS Software Before using CCS software applications to control and monitor your module, you must refresh (+ Pilot Lite) or discover (Pilot and Navigator) the module. Refresh and Discovery are the processes by which your CCS software finds, and then connects to your module. -
Page 44: Software Communication And Control Issues
Appendix A: Communication and Control Troubleshooting Tips Software Communication and Control Issues • “+ Pilot Lite Fails to Communicate with Installed Modules” on page 30 • “+ Pilot Lite Does Not Find All Modules in Frame” on page 31 • “+ Pilot Lite or CCS Software Application Not Responding”... -
Page 45: Pilot Lite Does Not Find All Modules In Frame
If this is not possible, you can exchange the back module for a new one (order part number VTM6801+DR). Pilot Lite Does Not Find All Modules in Frame If a discovery is started too soon after frame power-up, + Pilot Lite will not find all the installed modules. -
Page 46: Pilot Lite Or Ccs Software Application Not Responding
Appendix A: Communication and Control Troubleshooting Tips If a module is plugged into the frame after a discovery, + Pilot Lite does not automatically detect the module. Refresh + Pilot Lite (File > Refresh) to discover the newly installed module. If a Legacy 6800 series product is in the frame, + Pilot Lite will not detect it. -
Page 47: Ccs Software Application Or Remote Control Panel Does Not Communicate With Module
Appendix A: Communication and Control Troubleshooting Tips CCS Software Application or Remote Control Panel Does Not Communicate with Module CCS software applications (such as Pilot, CoPilot, and Navigator) and remote control panels require the purchase and installation of an ICE6800+ module in an FR6802+ frame (or an ICE6800+ or 6800+ETH module in a FR6802+QXF frame) in order to communicate remotely via Ethernet. -
Page 48: Hardware Communication And Control Issues
Appendix A: Communication and Control Troubleshooting Tips Hardware Communication and Control Issues • “Frames Fail to Communicate with the PC after a Power Failure” on page 34 • “Module Does Not Seem to Work” on page 34 Frames Fail to Communicate with the PC after a Power Failure You must exit the software and restart after the frame recovers from its power failure. -
Page 49: Index
Index Keywords Alarms 21 DIP switches 16 alarm query failed 33 location on board 17 Application not responding 32 settings 18 Back connector Dip switches 3 6800/7000 frame 6 Discovering a module 29 FR6802+ frame 5 Discovery failure 31 installing 14 Black and white output DIP switch 18 Extractor handle 3 Features 2... - Page 50 Index setting jumper for 12 Remote/local control jumper 3 LEDs Required frames 14 Channel LEDs 20 Returning a product ix location on board 17 Revision history of the manual vii module status LEDs 21 RoHS-compliance x Local control 17 setting the jumper for 12 Safety precautions xii Setup DIP switch 18 Manual information vii...
- Page 52 Customer Service Support +1 888 534 8246 BCDService@harris.com Harris is a registered trademark of Harris Corporation. Trademarks and tradenames are the property of their respective companies. Broadcast Communications Division 4393 Digital Way | Mason, OH USA 45040 | Tel: 1 (513) 459 3400 www.broadcast.harris.com ©2007 Harris Corporation...
