Example:
Assume
that the horizontal distance between
the
B
amplitude
points
is
3
divisions,
and
the
TIME/DIV
switch
setting
is .1
ms
(see Fig, 2-7).
Using the formula:
Horizontal
TIME/DIV
Pulse
Width
=
distance x
setting
Magnification
Substituting values:
Pulse
Width
=
—
=
0.3 millisecond
Operating Instructions— 7B 10
Operators
DELAYED-SWEEP MEASUREMENTS
The
time-base
unit
may
be used with
a delaying time-
base
unit
in
a
mainframe
with
two
horizontal
compartments
to
make
delayedsweep measurements.
See
the Tektronix Products
Catalog
for
compatible
delaying
time-base
plug-in
units.
If
a
compatible delaying
time-base
unit
is
available,
refer to
the
instruction
manual
for that unit for detailed delayed-sweep
measurement
procedures.
