Operating and assembly manual
Operating and assembly manual
Operating and assembly manual
Operating and assembly manual
240 PRO, 360 XT and 720 XT
© 2007-2009
aquaduct
mark III ceramic
mark III ceramic
mark III ceramic
mark III ceramic
August 2009
Aqua Computer GmbH & Co. KG
Gelliehäuser Str. 1, 37130 Gleichen, Germany
AQUADUCT
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquaduct 240 PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aqua Computer Aquaduct 240 PRO

Summary of Contents for Aqua Computer Aquaduct 240 PRO

  • Page 1 Operating and assembly manual aquaduct mark III ceramic mark III ceramic mark III ceramic mark III ceramic 240 PRO, 360 XT and 720 XT August 2009 © 2007-2009 Aqua Computer GmbH & Co. KG - 1 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 2: Table Of Contents

    3.1. aquaduct 240 PRO mark III............8 3.2. aquaduct 360 XT mark III..............8 3.3. aquaduct 720 XT mark III..............8 3.4. Optional accessory for aquaduct 240 PRO mark III......9 3.5. Optional accessory for aquaduct 360 XT mark III and aquaduct 720 XT......................9 4.

  • Page 3: Preface

    Dear Customer We congratulate you on the purchase of a water cooling system made by Aqua Computer GmbH & Co. KG. We are one of the most renowned manufacturers of PC water cooling systems in Germany. Our production meets highest quality standards. During the development we especially took into account that our cooling system is dependable and leak proof.

  • Page 4: Information On The Assembly Of A Water Cooling System

    This has always been our priority in developing water cooling equipment. Therefore high-quality plug-connectors are used for our plug&cool-system. These rather expensive, but by the in- - 4 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...
  • Page 5 (or even a fire). Therefore a powerful and dependable pump is essential. © 2007-2009 Aqua Computer GmbH & Co. KG - 5 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 6: Safety Precautions

    Make sure that your wall socket is protected by an FI-fuse! Make sure that your wall socket is protected by an FI-fuse! Make sure that your wall socket is protected by an FI-fuse! - 6 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...
  • Page 7 Co. KG customers using or selling this product for use in such applica- - - - tion do so at their own risk and agree to fully indemnify Aqua Computer tion do so at their own risk and agree to fully indemnify Aqua Computer...

  • Page 8: Scope Of Delivery

    3. Scope of delivery 3. Scope of delivery 3. Scope of delivery 3. Scope of delivery 3.1. aquaduct 240 PRO mark III 3.1. aquaduct 240 PRO mark III 3.1. aquaduct 240 PRO mark III 3.1. aquaduct 240 PRO mark III - aquaduct 240 PRO - 2 pcs.

  • Page 9: Optional Accessory For Aquaduct 240 Pro Mark Iii

    - manual „aquaduct controlling unit“ - this manual 3.4. Optional accessory for aquaduct 240 PRO 3.4. Optional accessory for aquaduct 240 PRO mark III mark III 3.4. Optional accessory for aquaduct 240 PRO 3.4. Optional accessory for aquaduct 240 PRO...

  • Page 10: Use Of The Plug&Cool Connectors

    For this purpose you can also use the separately available AC Multi-Tool. Slip it over the hose with the middle opening. - 10 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...

  • Page 11: Installation Of The Cpu Waterblock (Cuplex™ Series)

    Then take a razor blade or a plastic spatula and apply a © 2007-2009 Aqua Computer GmbH & Co. KG - 11 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 12: Installation Of "4-Hole-Mounting Kits" - Socket, 775, 1366, Am2

    M4 nuts up to the limit by hand. The screw should now be fixed to the board like a standing - 12 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...

  • Page 13: Installation Of „2-Hole-Mounting Kits" - Socket 754, 939, F

    The two bigger feathers of the mounting kit are used as feathers. Please gather the further procedure from chapter 6.3. © 2007-2009 Aqua Computer GmbH & Co. KG - 13 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 14: Installation Of "3-Nose-Mounting Kits" - Socket 370, A

    Avoid the cooler to get stuck, since this will risk a corner of the die to break off. Do not hook in one side after the other! - 14 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...

  • Page 15: Examination And Connection To The Cooling System

    When operated with reversed flow direction, the cooling performance is signi- ficantly reduced. © 2007-2009 Aqua Computer GmbH & Co. KG - 15 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 16: Installation Of The Pc Interface Circuit Board

    For details on BIOS configuration, please consult the manual for your motherboard, 7.3. Connector „flow“ (aquaduct 240 PRO only) 7.3. Connector „flow“ (aquaduct 240 PRO only) 7.3. Connector „flow“ (aquaduct 240 PRO only) 7.3.

  • Page 17: Connector „Fan" (Aquaduct 360 Xt And 720 Xt Only)

    7.8. Connectors „temp sensor 1/2“ (aquaduct 360 XT and 720 XT only) 7.8. Connectors „temp sensor 1/2“ (aquaduct 360 XT and 720 XT only) Please refer to the manual „aquaduct controlling unit“. © 2007-2009 Aqua Computer GmbH & Co. KG - 17 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 18: Connecting The Aquaduct

    To connect the hoses, at first the fittings included in delivery have to be screwed in. If alternatively special hoses are to be used, fittings with G1/8 thread can be used. - 18 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...

  • Page 19: Operation Of The Ball Valves

    This will considerably reduce the amount of water leaking from the tubes while disconnecting. © 2007-2009 Aqua Computer GmbH & Co. KG - 19 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 20: Initial Operation

    4-pin ATX12V power supply. Connect the aquaduct using the fif- teen-pin power supply cable to the PC interface card using the fif- - 20 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...
  • Page 21 If components have come into contact with water, do not put these into operation before they are completely dry again! © 2007-2009 Aqua Computer GmbH & Co. KG - 21 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...

  • Page 22: Mechanical Fill Level And Flow Indicator

    - 22 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...

  • Page 23: Maintenance And Care Instructions

    You can get spare gaskets from us or let us do the exchange. Also check the hoses for changes in material regularly. Should they get brittle or have scratches you should exchange them. © 2007-2009 Aqua Computer GmbH & Co. KG - 23 - Gelliehäuser Str. 1, 37130 Gleichen, Germany...
  • Page 24 If you do have any more questions we will be happy to help you per e- mail or in our support-forum. - 24 - Aqua Computer GmbH & Co. KG © 2007-2009 Gelliehäuser Str. 1, 37130 Gleichen...
