Introduction

For More Information

The following table lists publications that provide general drive-related information.
Resource
PowerFlex 750-Series AC Drives Technical Data,
publication
PowerFlex 750-Series AC Drives Installation Instructions,
publication
PowerFlex 750-Series AC Drives Programming Manual,
publication
PowerFlex 750-Series AC Drives Reference Manual,
publication
Wiring and Grounding Guidelines for Pulse Width
Modulated (PWM) AC Drives Installation Instructions,
publication
PowerFlex 20-HIM-A6 / -C6S HIM (Human Interface
Module) User Manual, publication
PowerFlex Dynamic Braking Resistor Calculator
Application Technique, publication
PowerFlex 20-750-ENETR Dual-Port EtherNet/IP Option
Module User Manual, publication
PowerFlex 755 Drive Embedded EtherNet/IP Adapter User
Manual, publication
6
750-TD001
750-IN001
750-PM001
750-RM002
DRIVES-IN001
20HIM-UM001
PFLEX-AT001
750COM-UM008
750COM-UM001
Rockwell Automation Publication 750-QS001A-EN-P - March 2015
Description
Provides detailed information on:
• Drive specifications
• Option specifications
• Fuse and circuit breaker ratings
Provides detailed information on:
• Drive installation
• Power wiring
• I/O wiring
Provides detailed information on:
• I/O, control, and feedback options
• Parameters and programming
• Faults, alarms, and troubleshooting
Provides detailed information on utilizing specific drive
features in common applications.
Provides the basic information needed to properly install,
protect, wire, and ground pulse width modulated (PWM)
AC drives.
Provides detailed information on HIM components,
operation, and features.
Provides detailed information on dynamic braking
components, operation, and features.
Provides detailed information on installing, configuring,
using, and troubleshooting the dual-port EtherNet/IP
option module.
Provides detailed information on installing, configuring,
using, and troubleshooting the embedded EtherNet/IP
adapter.
