Summary of Contents for Reverse Osmosis Genesis
-
Page 2: Starting Your Installation
In-line carbon polishing filter Introduction Our reverse osmosis drinking water systems have been designed for quick and simple installation and maintenance. By carefully reading this instruction manual and following the operational guidelines you will insure a successful installation and reliable operation. Routine maintenance is essential to the longevity and performance of the system. Filters should be changed regularly, depending on the quality of the feed water supply and quantity of water used. -
Page 3: Faucet Installation
1. Faucet Installation Drilling the Faucet Hole The product water faucet may be installed on any flat surface at least 2” in diameter. Check the underside of the location for interference Drill a hole through the countertop where the faucet will be mounted at least 7/16" (11mm) in diameter. (Most faucets will mount to a hole diameter of up to 1 ¼”) Drilling a ¼”... -
Page 4: Drain Installation
*systems may not have color-coded tubing or different color codes Feed (Red) – connects main water supply feed to elbow fitting on right side of unit (ball valve for Genesis Series) Drain (Black) – connects drain saddle to bottom fitting on membrane housing (flow restrictor necessary on this line) Tank (White) –... -
Page 5: Unit Start Up
Note: The first tank of water is not recommended for consumption. Additionally, carbon filters may leach carbon dust fines on startup. This may discolor the water initially, but should clear up quickly. Typical Reverse Osmosis Contaminant Removal: *Results will vary based on feed water quality... - Page 6 FWC14K Storage Tank TATW Drain Line TPB14 Tank Line TPW14 Feed Line TPR14 Faucet Line TPBL14 Genesis Series Schematic (6 stage with UV) Auto Shutoff AS3WJG14 Bracket B3PW Ball Valve BVPAWFM14 Mem / Omni Clip Membrane Clip CSWM Check Valve...
-
Page 7: Warranty Information
Please contact your dealer with any questions on installation or servicing of your RO system. WARRANTY INFORMATION All reverse osmosis systems carry a limited liability warranty. Warranty period will vary per model and system options. Contact your local dealer for details on warranty information. -
Page 8: Troubleshooting Guide
(just like on a car or bicycle tire) and add air. If there is still water in the tank, continue to add air until all the water This is the #1 reason for low flow from Reverse Osmosis is removed.
