INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
RUBY
SERIES
Models: MDVI30IN
MDVI35IN
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
Owner's Manual
Care and Operation
Majestic • MDVI30IN, MDVI35IN Owner's Manual • 2205-981 Rev. D • 8/16
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Majestic fireplaces MDVI30IN
Summary of Contents for Majestic fireplaces MDVI30IN
-
Page 1: Care And Operation
fi tter. appliance is not convertible for use with other See appliance installation manual for additional Commonwealth of Massachusetts requirements. gases, unless a certifi ed kit is used. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 2: Welcome
00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX XXXXXXXX XXXXXXXX (Serie): (Serie): Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 3: Table Of Contents
C. Contact Information ......23 = Contains updated information. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 4: Limited Lifetime Warranty
3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... - Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16...
-
Page 6: Product Specifi C Information
B. Glass Specifi cations This appliance is equipped with 5 mm ceramic glass. Re- place glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 7: Important Safety And Operating Information
• Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. • Never leave children alone near a hot fi replace, whether operating or cooling down. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 8: General Operating Parts
fi replace with fi xed glass assembly removed. ensure wall temperature will not exceed temperatures for This fi replace has an Intellifi re Plus ignition system. operation of TV designated by TV manufacturer. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 9: Lighting Instructions (Ipi)
Keep burner and control compartment clean. See installation and operating instruc- Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 10: Appliance Break-In
Replace door or decorative front on appliance. Wireless Remote: • Slide the ON/REMOTE/OFF switch to the REMOTE position. Remove the batteries from the battery tray. Replace decorative front on appliance. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 11: Detailed Component Operating Instructions - Intellifire Tm Plus
LED. Flame • Check battery tray. Remove batteries if installed. Adjust the fl ame height. Batteries should only be installed for use during power outages. See Section 3.I. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 12: Maintenance And Service
CAUTION! Risk of Burns! The fi replace should be turned off and cooled before servicing. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 13: Remote Control
Tools needed: Protective gloves, stable work surface • Assess condition of screen and replace as necessary. • Inspect for scratches, dents or other damage and repair as necessary. • Vacuum and dust surfaces. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 14: Maintenance Tasks - Qualifi Ed Service Technician
Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided. • Remove all foreign objects. • Verify unobstructed air circulation. Figure 4.2 IPI Pilot Flame Patterns Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 15: Frequently Asked Questions And Troubleshooting
Refer to (battery backup) Section 3.H for more details. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.majesticproducts.com to locate a dealer. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 16: Troubleshooting
D. Pilot valve solenoid. Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module. If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... - Page 17 fi ne steel wool to remove any contaminants that may have accumulated on fl ame sensing rod. Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16...
-
Page 18: Reference Materials
Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative front. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 19: Service Parts
Control Panel 2205-129 Blower Assembly GFK210MAJ 2206-068 Wire Assembly Cord Assembly 2201-017 Fuse Wire Assembly Qty 2 req 2206-085 Additional service part numbers appear on following page. 8/16 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... - Page 20 Glass Door Assembly GLA-2205 Control Panel 2205-129 GFK210MAJ Blower Assembly Wire Assembly 2206-068 Cord Assembly 2201-017 Fuse Wire Assembly 2206-085 Additional service part numbers appear on following page. 8/16 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16...
- Page 21 11.12 11.13 Battery Pack 2166-323 11.14 Power Supply 2326-131 11.15 Wire Harness 2166-304 11.16 Module 2166-307 11.17 AUX RC200 2166-325 Additional service part numbers appear on following page. Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16...
-
Page 22: Service Parts
Conversion Kit LP LPKMDVI Conversion Kit NG NGKMDVI MDVI35IN Conversion Kit LP LPKMDVI Pilot Ori ce NG 593-528 Pilot Ori ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16... -
Page 23: Contact Information
5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2016 Majestic • MDVI30IN, MDVI35IN Owner’s Manual • 2205-981 Rev. D • 8/16...
