QuickSpecs
Overview
The HP Smart Array P712m mezzanine card is the preferred high value solution for 6Gb/s Shared SAS Storage for the HP ProLiant
BladeSystem servers. It is one of the highest performing controllers in the SAS portfolio and provides new levels of reliability for the
HP BladeSystem through its support of the latest SCSI technology and advanced RAID capabilities
What's New
What's New
What's New
What's New
256 Cache
Support for 6 Gb/s SAS
Support for 6G SAS Switch
2 internal SAS 1x ports and 2 external SAS 2x ports
Support for externally attached Shared storage
Support for Internal SATA/SSD drives on BL280c, BL490c, and BL495c
Models
Models
Models
Models
HP Smart Array P712m/ZM 2-ports Int PCIe x8 SAS Controller
HP Smart Array P712m/256 6Gb 2-ports Int/2-ports Ext Mezzanine SAS Controller
NOTE: In order to support SAS Hard Drives the server blade must have a P712m Controller installed in server
NOTE:
NOTE:
NOTE:
mezzanine slot 1 or mezzanine slot 2.
DA - 13296
Worldwide — Version 10 — June 20, 2011
HP Smart Array P712m Controller
HP Smart Array P712m Controller
HP Smart Array P712m Controller
HP Smart Array P712m Controller
484299-B21
488348-B21
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Smart Array P712m and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP Smart Array P712m

Summary of Contents for HP Smart Array P712m

  • Page 1 Overview The HP Smart Array P712m mezzanine card is the preferred high value solution for 6Gb/s Shared SAS Storage for the HP ProLiant BladeSystem servers. It is one of the highest performing controllers in the SAS portfolio and provides new levels of reliability for the...

  • Page 2: Standard Features

    Use of Smart Array products across multiple applications results in a much lower Total Cost of Ownership (TCO) than any other server storage RAID product. The HP Smart Array family brings an unparalleled return on investment.
  • Page 3 The following features offer detection of possible failures before they occur, allowing preventive action to be taken: S.M.A.R.T.: Self Monitoring Analysis and Reporting Technology first developed at HP detects possible hard disk failure before it occurs, allowing replacement of the component before failure occurs.
  • Page 4 QuickSpecs HP Smart Array P712m Controller HP Smart Array P712m Controller HP Smart Array P712m Controller HP Smart Array P712m Controller Standard Features Fault Tolerance RAID Fault Tolerance RAID Fault Tolerance RAID Fault Tolerance RAID Keeps data available and server running while a failed drive is being replaced; two fault tolerance...
  • Page 5 Red Hat Enterprise Linux 6 NOTE: NOTE: NOTE: NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at: http://www.hp.com/go/supportos. Software Suite...
  • Page 6 QuickSpecs HP Smart Array P712m Controller HP Smart Array P712m Controller HP Smart Array P712m Controller HP Smart Array P712m Controller Compatibility HP Storage Management HP Storage Management HP Storage Management HP Storage Management Initial System Configuration Wizard is the easiest and simplest method...
  • Page 7 HP Care Pack Information HP Care Pack Information HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific duration and hours of coverage. Care Packs for this option is sold at the system level this option attaches too.

  • Page 8: Related Options

    3.5-inch Disk Enclosure 3.5-inch Disk Enclosure 3.5-inch Disk Enclosure 3.5-inch Disk Enclosure HP StorageWorks P2000 1TB 6G SAS 7.2K LFF (3.5-inch) Dual Port MDL Hard Drive AP861A HP StorageWorks P2000 2TB 6G SAS 7.2K LFF (3.5-inch) Dual Port MDL Hard Drive AW555A...
  • Page 9 Disk Enclosures Disk Enclosures Disk Enclosures Disk Enclosures HP StorageWorks P2000 Dual I/O LFF Drive Enclosure, twelve 3.5" drive bays AP843A (w/ two .5m mini-SAS to mini-SAS cables. Used with single or dual controller LFF or SFF array head) HP StorageWorks P2000 LFF Drive Enclosure I/O Module (no cable included.
  • Page 10 NOTE: NOTE: NOTE: HP recommends a maximum of 2 tape drives per 6Gb/s SAS BL Switch and 64K transfer sizes. Attaching a library with 4 tape drives requires purchasing a second tape library SAS cable (AN975A or AN976A) and attaching 2 drives to the redundant 6Gb/s SAS BL Switch.

  • Page 11: Technical Specifications

    The information contained herein is subject to change without notice. Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
