SERVICE MANUAL
AV RECEIVER
HT-RC270(B)
MODEL
Black model
B MDC
120V AC, 60Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
Ref. No. 4214
ON THE
HT-RC270
062010
RC-768M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-RC270(B) and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo HT-RC270(B)

Summary of Contents for Onkyo HT-RC270(B)

  • Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...

  • Page 2: Service Procedure

    HT-RC270 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol. Ce symbole indique que le fusible utilise est e lent.
  • Page 3 HT-RC270 SERVICE PROCEDURE-2 5. To check version of Microprocessor, DSP and Video FW(Firmware) 1. ON/STANDBY (Power On) 2. DISPLAY + ON/STANDBY. [e.g.] TX-NR808 M a i n : 1 .0 3 /1 0 7 2 9 A M 3. TONE [Tone ] --->...
  • Page 4 HT-RC270 EXPLODED VIEWS-1 A715 A703 P921 x 6 pcs. A253, <MDC, MDF> ONLY A279 A137 A143 A261 A269 x 2 pcs. A281 x 2 pcs. x 5 pcs. A145 A285 A245 U0013 A283 A251 A267 A029 A241 U0011 A289 x 7 pcs. A259 x 2 pcs.

  • Page 5: Exploded Views

    HT-RC270 EXPLODED VIEWS-2 P7501 <Fig-1> A317 x 2 pcs. A317 U0065 x 18 pcs. A321 A327 P3101 A323 U0060 A307 A301 A305 U0062 U0055 A325 x 3 pcs. A313 A702 A317 x 5 pcs. U0061 A351 A303 A317 A315 x 2 pcs. A373 U0067 A371...
  • Page 6 HT-RC270 EXPLODED VIEWS-3 <Fig-2> Q6050A A007 x 14 pcs. Q6056 Q6066 Q6054 Q6064 Q6051 Q6061 Q6052 Q6062 Q6050 Q6060 Q6053 Q6063 Q6050B Q6055 Q6065...
  • Page 7 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 1 BLOCK DIAGRAM AUDIO SECTION HEADPHONES except onk JJ TUNER UNIVERSAL PACK PORT POWER AMPLIFIER MAINR SPEAKER TERMINALS +29dB TONE FRONT LEFT for US SIRIUS_L Down mix : No use R2A15220FP Tone : Use for Z3 SIRIUS MAINL SIRIUS...
  • Page 8 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 2 BLOCK DIAGRAM VIDEO SECTION U007 BAHDM-0471 TC74HC4052 HDMI BOARD Scanning Line Aspect Ratio JJ ONLY TX-NA708/NA808/NA1008 only DACV U0053 BAVD-0465 DACSC DACSY D TERMINAL BOARD DACPR DACPB DACY ADCY NJW1325 ADCPB ADCPR ADCSY YOUT...
  • Page 9 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 3 BLOCK DIAGRAM HDMI SECTION HDMISPF_DL2 ARC_SPDIF HP DET HPD1 SPDIF/DL2 RPWR SD0-3 R1PWR5V SD0-7 YKF45-7037V DDC DATA DDC DATA PCMLRCK_DR0_A TXPIXCLK TMDS DATA2 +/- DDC DATA RSDA TSDA DSDA1 IDCK TX2+/- D2+/- TC74VHC157FT DDC CLK...
  • Page 10 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 USB FS USB HS SCHEMATIC DIAGRAMS - 4 RJ-45 Reserved HOST BLOCK DIAGRAM DSP/ETHERNET/USB SECTION Reserved HiSideSw SDR SDRAM(x16bit) EtherMAC 256Mb?? x2pcs HiSideSw from HDMI block EMIFB x32DataBus NAND Controles NANDFlash EMFB_A[1:2] EMIFA EMFA_D[0:7] Reserved 256Mbit Level Convert UART2...
  • Page 11 10/50 Q4504A RWRH R4749 R4764 Subwoofer 6.8K Av=22dB SBR/Z2R/BiAmpR NJM4580M-D C4726 471J Q4606 Q4616 RN1441 RN1441 C4746 151J C4762 103J for ONKYO C4744 R4759 SR/Z3R R4825 123J 332J C4745 220K NJM4580M-D R4745 R4744 270K Q4504B Q4617 C4607 Q4607 RN1441 C4749...
  • Page 12 TX-NR708, TX-NA708, HT-RC270, DTR-40.2 SCHEMATIC DIAGRAMS - 6 NOTE: AMP (VOLTAGE AMP) SECTION XY in “SCHEMATIC-a / PART-b:XY” indicates the target location of the plug or socket, X=A to E/H/K, Y=1 to 4/5/8. U0011 BACLA-0445 R5182 +60.5V +B1C POWER AMP. BOARD (1/4W) NOTE +58.5V...
  • Page 13 TX-NR808/1008, TX-NA808/1008, DTR-50.2 SCHEMATIC DIAGRAMS - 7 NOTE: AMP (VOLTAGE AMP) SECTION XY in “SCHEMATIC-a / PART-b:XY” indicates the target IDLING CURRENT ADJUSTMENT location of the plug or socket, X=A to E/H/K, Y=1 to 4/5/8. 1. Wait for 4 - 6 minutes after power on. (Heat running) BACLA-0484 U0024 BACLA-0484...
  • Page 14 TX-NR708, TX-NA708, HT-RC270, DTR-40.2 SCHEMATIC DIAGRAMS - 8 NOTE: XY in “SCHEMATIC-a / PART-b:XY” indicates the target POWER AMP (FINAL STAGE) SECTION location of the plug or socket, X=A to E/H/K, Y=1 to 4/5/8. U001 BAAMP-0444 P6901B P6902B POWER AMP. BOARD P6901:2069925119UL P6902:2069925188UL +60.5V...
  • Page 15 TX-NR808/1008, TX-NA808/1008, DTR-50.2 SCHEMATIC DIAGRAMS - 9 NOTE: XY in “SCHEMATIC-a / PART-b:XY” indicates the target POWER AMP (FINAL STAGE) SECTION location of the plug or socket, X=A to E/H/K, Y=1 to 4/5/8. TO BAAF0475 PART-10:E3 P6340B NPLG-2P631 +B1R +B1L U0010 BAAMP-0474 PLUG...
  • Page 16 TX-NR808/1008, TX-NA808/1008, DTR-50.2 SCHEMATIC DIAGRAMS - 10 AMP (POWER SUPPLY, PROTECT, ETC.) SECTION U0010 BAAF-0475 PROTECT, ETC. BOARD inputC TO BACLA-0487 RWRH AGND_inputC PART-7 : A6 AGND_NFC SBR/Z2R/BiAmpR IN SBR_IN SR/Z3R IN SR_IN P5022B NTM-1P232 FR_IN TA_0.5_DIM J5014 C_IN inputSR AGND_inputSR TO BACLA-0486 PART-7 : A5...
  • Page 17 TX-NR708/808/1008, TX-NA708/808/1008. HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 11 SPEAKER TERMINALS, PRIMARY POWER SUPPLY SECTION U0063 BAETC-0113 U0062 BAETC-0123 U0031 BATRM-0451 P6635 NTM-2PDMCR400 U0062 BAETC-0137 U0063 BAETC-0149 E6611 GND_RLY JL4103B NTM-1P232(M1700) NSCT-5P97 +22V GND_DG GND_DG C6655 -15V 102J +15V HPDET HPDET HP_R HP_R...
  • Page 18 R2274,C2261 SHIELD VOUT1 SYIN1 GNDA R2294 SHIELD SIRIUS_L C2263 R2226 NC +12V Component Terminals R2276 C2229 NC P2114 R2283 Onkyo= Silver NJM4580M-D D2104 NEJITANSI_ST3 R2287 D2105 Integra= Gold C2231 104Z R2234 R2284 C2233 C2234 C2235 47/25(UTSP) 3.9K +5VVD1 R2285 1/50(UTSP)

  • Page 19: Schematic Diagrams

    TX-NA708/808/1008 SCHEMATIC DIAGRAMS - 13 D TERMINALS SECTION U0053 BAVD-0465 ONKYO MJJ only C2900 100/6.3(MA) +5VVD3 GNDVD D4SEL2 D4SEL1 CY_OUT_D GNDVD PB_OUT_D GNDVD PR_OUT_D C2902 C2901 104Z 104Z GNDVD CY_IN1 GNDVD PB_IN1 GNDVD PR_IN1 GNDVD CY_IN2 GNDVD PB_IN2 GNDVD PR_IN2...
  • Page 20 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 14 MAIN MICROPROCESSOR SECTION TO DEBUGER TO FLASH WRITER P7000A P7001A IMSA-9618S-09A IMSA-9618S-09A U0051 BACPU-0463 Power_GND GND_VD AUXCV_IN -12VA +12VA AUX_R GND_AUX GND_AUX Digital AUX_L SRZ3MUT3.3 MICOUT GND_DG MICMUT Q7001 HPDET MICDET KRA102S HPRL OPTF...
  • Page 21 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 15 DAC/DIR/ADC/VLSC2 SECTION TO BAHDM-0471 TO BAHDM-0471 TO BATRM-0450 SD-23 : B1 SD-23 : C1 SD-11 : A2 P3605B P3607B P1008B IMSA-9142S-18A IMSA-9142S-16A IMSA-9142B-22A U0050 BADG-0462 excptJJ excptJJ R1620-1629 R1640-1649 1.5K 3.3K Q1220-1227 Q1230-1237 Q1250-1251 Q1260-1261 R1300-1307...
  • Page 22 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 16 HDMI INPUT/OUTPUT SECTION HDMI IN1 P8601 Shield Shield U007 BAHDM-0471 C8612 N.M. VMPU PART PART-17 CONNECTOR PART PART-23 102K TO BAHDM-0290 or 0291(PART-32 or 33) SEQUOIA MEMORY / BUS SWITH PART R8620 0 HPD_IN2 R8607...
  • Page 23 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 17 VMPU/ENCODER SECTION U007 BAHDM-0471 +3.3VHD SEQUOIA(VSP) PART ANALOG INPUT Q8852 DIGITAL INPUT XC6221B182MR 3.3V PART-18 +1.8VEN VPOWER C8851 VOUT VSW_SDET 105Z KRC104S VSW_VDET C8875 Q8853 225K VSW_CDET C8852 C8854 VSW_SDA 106K/6.3 105Z L8852 VSW_SCL...
  • Page 24 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 18 VSP SECTION (PART 1/2) U007 BAHDM-0471 C8030 C8036 VMPU PART 106K/6.3 106K/6.3 3.3V BLM18PG181SN1 +3.3VIO 1.2V BLM18PG121SN1 1.2V L8204 C8031 C8037 PART-17 L8207 106K/6.3 106K/6.3 3.3V 1.2V 3.3V 1.2V 3.3V C8038 +3.3VADC +3.3V_LPM_S +1.2V_LPM_S...
  • Page 25 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 19 VSP SECTION (PART 2/2) U007 BAHDM-0471 R8281 22X4 Q8200:F RXY11 RXY11_I RXY7 RXY7_I RXY6 RXY6_I RXPIXCLK_I RXY2 RXY2_I DIN_0CLK DIN_1CLK R8282 2OE2 2OE1 RXBLNK_I RXCB0 TXCB0 22X4 DIN_HREF_DE 2D10 2Q10 RXCB11 RXCB11_I RXVSYNC_I RXCB1...
  • Page 26 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 20 DSP/AUDIO/GPIO SECTION U007 BAHDM-0471 SPI0 & control signals (Part-23) to CS498xx (Part-24) from HDMI Block (Part-16) from DIR Block (Part-23) VDD_MPU3.3V VDD_CSW3.3 C3202 105Z TC74VHC157FT Q3202 DIG/NETUSB R3233 +3.3V SELECT TP96 (Part-21) BOOT3 R3208...
  • Page 27 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 21 for Debugging Boot Opt. NAND UART1 SPI0 NET/USB POWER SECTION R3115 or R3116 BOOT2 BOOT7 +5VHD BOOT1 +5.0V R3111 or R3112 BOOT5 TPD2E001DRLR for HS ESD BOOT0 BOOT3 R3109 or R3110 BOOT6 BOOT2 R3107 or R3108...
  • Page 28 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 22 1ST DSP MEMORY SECTION U007 BAHDM-0471 GND_ARM VDD_MPU3.3V GND_ARM PA_12 MB_A12 C3001 105Z +3.3V R3009 L3001 PBA_0 MB_BA0 BLM18PG121SN1D PA_0 MB_A0 GND_ARM PA_1 MB_A1 C3002 105Z VDD_NAND3.3V C3003 106K/6.3 33x4 R3010 MB_A0 EMA_D0 +3.3V...
  • Page 29 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 23 DSP CONNECT SECTION U007 BAHDM-0471 TO BADG-0462 TO BACPU-0463 SD-15 : A1~C1 SD-14 : D1 IMSA-9142B-18A IMSA-9142B-16A P3608A IMSA-9142B-18A P3605A P3607A R3067 GND_ARM P8100 (Part-16) from HDMI Block (Part-20,21) SPI0 & control signals (Part-20) from DIR Block (Part-20,21,17)
  • Page 30 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS - 24 2ND DSP SECTION DSP_DBDA DSP_DBCK (Part-20) from1stDSP SPIflash (Part-23) toASP R3405 TP3403 TP3404 U007 BAHDM-0471 TP3405 TP3406 GND_ARM R3406 3.3K R3407 4.7K R3412 R3413 R3414 R3434 3.3K +3.3V DSPC_RST R3435 Q3401 VDD_2NDIO_3.3V VDD_2NDCOR_1.1V EN25Q32A-100HIP...
  • Page 31 TX-NR708, TX-NA708, HT-RC270 SCHEMATIC DIAGRAMS - 25 DISP SECTION U006 BADIS-0110 U0060 BADIS-0110 TO BAPS-0112 NSCT-5P876 FLAC1 FLAC1 JL9303A FLAC2 P9301A U0062 BAPS-0112 NPLG-6P120 +3.3VMP FLAC2 TO P TRANS R7810 33(1/2W) -VP_AC1 D7813 D7812 -VP_AC2 RL1N4003 Q7801 RL1N4003 R7804 D7816 FLAC2 10(1/2W) 2SC2235-O(TPE6_F)
  • Page 32 DTR-40.2, DHC-40.2 SCHEMATIC DIAGRAMS - 26 DISPLAY SECTION U006 BADIS-0146(1/2) U0060 BADIS-0146 NSCT-5P876 FLAC1 FLAC1 JL9303A FLAC2 +3.3VMPU FLAC2 Q7500 U0062 BAPS-0148 HNA-16SL05T P9301A NPLG-6P120 Q7500A +3.3VMPU FL HOLDER R7810 33(1/2W) -VP_AC1 D7813 D7812 -VP_AC2 Q7801 RL1N4003 RL1N4003 R7804 D7816 FLAC2 2SC2235-O(TPE6_F) 10(1/2W)
  • Page 33 DHC-40.2 SCHEMATIC DIAGRAMS - 27 HEAD PHONE AMP SECTION U006 BADIS-0146 U0065 BAAF-0152 R6639 1.8K NE5532APSR C6611 47/50(UTSP) Q6607A R6645 C6613 330J GNDL RL6610 NRL-2P5A-DC24-193 GNDR HP_L HP_GND HP_R HPDET GNDDG D6621 1SS352 R6640 1.8K C6617 NE5532APSR 103J Q6613 C6612 2SC2712-GR 47/50(UTSP) Q6607B...
  • Page 34 TX-NR808/1008, TX-NA808/1008 SCHEMATIC DIAGRAMS - 28 DISPLAY SECTION U0060 BADIS-0135 U0065 BAPS-0140 NPLG-5P588 JL9303A JL9303B NSCT-5P876 FLAC1 FLAC1 FLAC1 R9308 D9312 D9313 FLAC2 FLAC2 0.1(1/2W) RL1N4003 RL1N4003 Q9301 R9304 D9316 10(1/2W) 2SC2235-Y(TPE6_F) RL1N4003 0.05A +3.3VMPU +3.3VMPU FLAC2 Q7500 D9314 D9315 RL1N4003 RL1N4003 HNA-16SL05T...
  • Page 35 DTR-50.2 SCHEMATIC DIAGRAMS - 30 DISPLAY SECTION U0060 BADIS-0121 U0065 BAPS-0126 JL9303B NSCT-5P876 NPLG-5P588 JL9303A FLAC1 R9308 FLAC1 FLAC1 0.1(1/2W) FLAC2 FLAC2 33(1/2W) R9310 +3.3VMPU +3.3VMPU FLAC2 D9312 D9313 RL1N4003 RL1N4003 Q9301 Q7500 2SC2235-Y(TPE6_F) D9316 R9304 0.05A 10(1/2W) HNA-16SL05T RL1N4003 FLAC2 D9314 D9315...
  • Page 36 TX-NR708,TX-NA708, HT-RC270, DTR-40.2, DHC-40.2 SCHEMATIC DIAGRAMS - 32 FRONT HDMI SECTION U0080 BAHDM-0290 3.3V HPD_IN8 R8670 HP DET +5V_IN8 R8669 C8676 102K DSDA_FTI DDC DATA DSCL_FTI DDC CLK C8675 R8680 105Z CERemote XCN_FTI R8681 C8680 CK Shield XCP_FTI 3.3V 106K/6.3 L8661 +3.3VHD2 X0N_FTI...
  • Page 37 TX-NR808/1008, TX-NA808/1008, DTR-50.2 SCHEMATIC DIAGRAMS - 33 FRONT HDMI / USB SECTION U0081 BAHDM-0291 3.3V R8870 HP DET R8869 C8876 102K DSDA_FTI DDC DATA DSCL_FTI DDC CLK C8875 105Z CERemote XCN_FTI CK Shield C8880 XCP_FTI 3.3V 106K/6.3 L8861 X0N_FTI BLM18PG181SN1 D0 Shield X0P_FTI R8880...
  • Page 38 TX-NR708/808/1008, TX-NA708/808/1008, HT-RC270, DTR-40.2/50.2, DHC-40.2 SCHEMATIC DIAGRAMS-34 WAVEFORM SECTION Video Waveform Part (SD12) Digital Audio Waveform Part (SD-15) Video source color and pattern Composite waveform S-Video Y waveform S-Video C waveform WF21 WF22 WF23 NOTE: LR CLOCK (SAI_LRCK, CX_LRCK) WF01 is short for Waveform01 . Fs=48kHz : DVD, Clock width=20.8us 2.
  • Page 39 TX-NR708/HT-RC270/TX-NA708/DTR-40.2 PRINTED CIRCUIT BOARD VIEW-1-1 U001 POWER AMP BOARD BAAMP-0444 U0011 VOLTAGE AMP PC board BACLA-0445 BCETC-0449 BCETC-0449 BCETC-0455 BCETC-0448 U0010 AMP (FINAL STAGE) PC board Assy BAAMP-0444...
  • Page 40 TX-NR708/HT-RC270/TX-NA708/DTR-40.2 PRINTED CIRCUIT BOARD VIEW-1-2 U001 Power AMP. board BAAMP-0444 BCETC-0446 25140446 P6010B P6900A J6115 J6109 BCETC-0449 BCETC-0449 25140449 25140449 P6606A RL692 JL6402B BLUE J6111 P6950 VPROTECT J6116 RL691 R6197 J6110 IPROTECT D6901 F6901A C6914 P6900B VOLH P6901A P6902A F6901B F6902A C6901 C6902...
  • Page 41 TX-NR708/HT-RC270/TX-NA708/DTR-40.2 PRINTED CIRCUIT BOARD VIEW-1-3 U001 Power AMP. board BAAMP-0444 C6911 D6902 R6902 C6713 R6712 Q6713 R6701 Q6707 R6165 R6024 R6014 R6004 R6022 R6025 R6023 R6020 R6021 R6015 R6013 R6010 R6011 R6005 R6003 R6012 R6000 R6002 R6001 R6163 R6161 R6160 R6162 R6164 R6166...
  • Page 42 TX-NR808/TXNA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-1-1 U001 Power AMP board BAAMP-0474 U0010 POWER AMP. PC board Assy BAAMP-0474 BCAMP-0474 U0012 THERMAL U0013 SENS. U0013 SPACER SPACER PC board PC board PC board BAETC-0477 BAETC-0477 BAETC-0476 U0011 POWER SUPPLY PC board Assy BAAF-0475...
  • Page 43 TX-NR808/TXNA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-1-2 U001 Power AMP board BAAMP-0474 P6075 P6061 P6071 J6021 J6017 P6063 P6065 P6060 J6039 P6066 J6035 P6076 P6068 P6078 P6064 P6074 P6062 P6072 P6073 P6077 P6067 P6070 J6004 (SL) (SR) P6350 P6360 P6340B R6801 R6806 R6808 R6804 R6802...
  • Page 44 TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-2-1 U002 Driver AMP board BACLA-0480 BCPS-0489...
  • Page 45 TX-NR808/TXNA808/HT-RC280/TX-NR1008/TXNA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-2-2 U002 Driver AMP board BACLA-0480 BCPS-0489 25140489 P6950 BIAS BIAS BIAS BIAS R6307 R6303 R6305 R6300 R6267 R6263 R6265 R6260 R6047 Q6047 R6043 Q6043 R6045 Q6045 R6040 Q6040 Q6017 Q6013 Q6015 Q6010 C6027 C6023 C6025 C6020 Q6037 Q6033...
  • Page 46 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-3-1 U003 Speaker Terminal board BATRM-0450 U0034 POWER SUPPLY PC board BAPS-0454 U0031 SPEAKER TERMINAL-2 PC board U0033 BATRM-0451 CONNECTOR PC board BATRM-0453 BCTRM-0451 BCTRM-0450 U0030 SPEAKER TERMINAL-1 PC board BATRM-0450...
  • Page 47 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-3-2 U003 TRANS Speaker Terminal board P911 F901B BATRM-0450 P2102A P2103A JL4A TO BCCPU-0463 C901 JL2A P921C '10 MID RCV JL3A TO BCVD-0464 JL1A P2102B P2103B P902B E901 C903 J905 J902 F901A P6639 P6635 P6637 C6639 C9301 C9300 C9303...
  • Page 48 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-3-3 U003 TRANS Speaker Terminal board F901B P911 BATRM-0450 P2103A P2102A TO BCCPU-0463 JL4A C901 P921C JL2A '10 MID RCV JL3A JL1A TO BCVD-0464 P2103B P2102B P902B E901 C903 J905 J902 F901A P6635 P6639 P6637 C6639 C9301 C9300 C9303...
  • Page 49 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-4-1 U004 AMP (Audio IN/OUT) PC board BAASP-0458 U0040 ANALOG AUDIO PC board BAASP-0458 (1/2) U0041 D-SUB TERMINAL PC board BAETC-0459 (1/2) U0040 ANALOG AUDIO PC board BAASP-0458 (2/2)
  • Page 50 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-4-2 U004 AMP (Audio IN/OUT) PC board BAASP-0458 PREWLMUT SRZ3MUT Z3MUT P4511A PRESRMUT R4845 SWMUT R4849 SPRLF R4842 PRESBMUT -12.6V +12.6V R4835 R4836 R4912 P4511A Z2MUT SBZ2MUT AMUT R4830 Z2VOLCK -12.6V R4829 VOLCLK D4911 D4901 P4510A R4827 VOLDATA R4826...
  • Page 51 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-4-3 U004 AMP (Audio IN/OUT) PC board BAASP-0458 E4521 R4848 R4840 Z3MUT SBZ2MUT Z2MUT P4516B P4515B PREWLMUT JL104A JL4518A P4517B SRZ3MUT C4840 Q4551B Q4551 Q4561 C4526 C4912 C4900 C4902 C4910 RWRH C4903 C4913 Q4618 R4648 LWLH R4911 RWRH Q4608...
  • Page 52 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-5-1 U0055 FRONT USB PC board BAETC-0468 U005 Digital (Main CPU/DAC) Board BADG-0462 U0050 DAC PC board BADG-0462 U0051 CPU PC board BACPU-0463 U0052 ANALOG VIDEO PC board BAVD-0464...
  • Page 53 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-5-2 Digital (Main CPU/DAC) Board U005 BADG-0462 R7156 R7158 R7161 R7016 R7172 Q1303 R1570 R1550 R7233 R7207 C7054 œ œ +5VDAC R1668 R1648 R7151 R1658 R7154 R1820 R7015 C1306 R7043 R1649 R1551 R1659 R1571 R7185 R1669 R1382 R1342 C7025...
  • Page 54 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT VIEW-5-3 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40.2/TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 U005 R1778 R1540 C1480 C1470 C1618 R1590 R1580 R1510 R1520 Digital (Main CPU/DAC) Board R1678 R1608 C1450 P7000A R7167 R7163 BADG-0462 R1618 R1114 C1140 R1115 R1619 C1333 R7231 R1541 P3608B C7044 R1609 R1117 R1880 R1779 R1830 R1521 R1679...
  • Page 55 TX-NR708/HT-R270/TX-NA708 PRINTED CIRCUIT BOARD VIEW-6-1 U006 DISPLAY PC BOARD BADIS-0110 U0060 DISPLAY PC board BADIS-0110 U0065 VOLUME LED PC board U0062 BAETC-0116 FL POWER SUPPLY PC board U0061 BAPS-0112 DISPLAY SW PC board BCETC-0115 BASW-0111 U0067 U0064 HOLD FRONT HDMI TERMINAL HOLD IDE CABLE PART1 PC board PC board BAETC-0114...
  • Page 56 TX-NR708/HT-R270/TX-NA708 PRINTED CIRCUIT BOARD VIEW-6-2 U006 DISPLAY PC BOARD BADIS-0110 Q7597 Q7598 DIGCLK Q7533 DIGSDO GNDDG GNDDG Q7503 Q7504 +3.3VMPU LEDSTBY +3.3VST LEDREADY ~KEYINT0 LEDZ2 ~KEYINT1 LEDZ3 KEY1 LEDZ4 KEY2 LEDPURE KEY3 KEY0 +5VMPU ~REMIN VOLB REMO_IN VOLA LED_REMO Q7532 OPTF ~FLD1CS +3.3VMC...
  • Page 57 TX-NR708/HT-R270/TX-NA708 PRINTED CIRCUIT BOARD VIEW-6-3 U006 DISPLAY PC BOARD BADIS-0110 P7590A P7511 J5799 J7597 P7303A Q7500 TUNING S7643 S7590 J7557 U7560 PRESET PRESET S7642 S7646 J7555 TUNING S7645 RETURN ENTER SETUP DISPLAY TUNING MODE MEMORY DIMMER GAME MUSIC MOVIE/TV TONE ZONE2 S7641 S7644...
  • Page 58 DTR-50.2 PRINTED CIRCUIT BOARD VIEW-6-1 U006 DISPLAY PC BOARD BADIS-0121 U0064 VOLUME (ROT ENCODER) PC board U0060 BAETC-0125 DISPLAY PC board BADIS-0121 U0066 U0063 HOLDER PC board FRONT OPT TERMINAL BAETC-0127 U0061 PC board SWITCH/ LED PC board BAETC-0124 BASW-0122 U0069 HOLDER PC board U0065...
  • Page 59 DTR-50.2 PRINTED CIRCUIT BOARD VIEW-6-2 U006 DISPLAY PC BOARD BADIS-0121 Q7540 œ œ R7511 œ œ R7512 Q7504 œ œ œ œ œ œ œ œ Q7503 C7515 C7512 œ œ œ œ LEDZ4 œ œ œ œ œ LEDSTBY LEDZ2 œ...
  • Page 60 DTR-50.2 PRINTED CIRCUIT BOARD VIEW-6-3 U006 DISPLAY PC BOARD BADIS-0121 BCDIS-0121 25140121C œ J7675 œ œ œ Q7500 œ S7641 J7681 J7629 J7630 D7570 J7680 J7678 J7679 U7560 J7674 J7677 S7642 LEFT J7663 J7623 J7672 S7645 J7671 RIGHT S7643 J7624 ENTER J7664 LEDZ4...
  • Page 61 TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008 PRINTED CIRCUIT BOARD VIEW-6-1 U006 DISPLAY PC BOARD BCDIS-0135 BADIS-0135 U0060 DISPLAY PC board BADIS-0135 U0066 HOLDER PC board BAETC-0144 BCETC-0138 U0061 SWITCH/ LED PC board U0062 BASW-0136 HP JACK PC board BAETC-0137 BCPS-0140 U0065 BCETC-0142 POWER SUPPLY PC board BAPS-0140 BCETC-0145 U00610...
  • Page 62 TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008 PRINTED CIRCUIT BOARD VIEW-6-2 U006 C7507 C7508 DISPLAY PC BOARD FLAC1 œ FLAC2 C7509 +3.3VMPU LEDSTBY BADIS-0135 C7510 GNDDG LEDZ3 LEDZ2 LEDZ4 LEDPURE KEY0 REMIN REMO_IN LREMO FLD1CS FLD2CS GNDDG FLDRST DIGSDO DIGCLK GNDDG œ œ GNDDG +3.3VST œ œ...
  • Page 63 TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008 PRINTED CIRCUIT BOARD VIEW-6-3 U006 P7591A DISPLAY PC BOARD P7501B C7506 JL9303A BCDIS-0135 25140135E BADIS-0135 J7642 LEDSTBY GNDDG LEDZ2 LEDZ3 LEDZ4 LEDPURE KEY0 REMIN REMO_IN LED_REMO FLD1CS FLD2CS Q7500 FLDRST GNDDG DIGCLK DIGSDO GNDDG GNDDG +3.3VST +3.3VMPU U7560 œ J7633 œ...
  • Page 64 DTR-40.2/DHC-40.2 PRINTED CIRCUIT BOARD VIEW-6-1 U006 DISPLAY BOARD BADIS-0146 U0060 DISPLAY PC board BADIS-0146 U0067 HOLD IDE CABLE PART2 PC board BAETC-0155 U0065 U0061 HEADPHONE AMP PC board U0068 DISPLAY SW PC board BAAF-0152 U0066 HOLD HEADPHONE BASW-0147 HOLD FRONT HDMI TERMINAL TERMINAL PC board PC board...
  • Page 65 DTR-40.2/DHC-40.2 PRINTED CIRCUIT BOARD VIEW-6-2 U006 DISPLAY BOARD BADIS-0146 LEDSTBY ~KEYINT0 LEDREADY ~KEYINT1 LEDZ2 KEY1 LEDZ3 KEY2 LEDZ4 KEY3 LEDPURE +5VMPU KEY0 VOLB ~REMIN VOLA REMO_IN OPTF LED_REMO ~MICDET ~FLD1CS MICMUTE ~FLD2CS ~FLDRST AUX2_L LEDLATCH GNDAUX2 DIGCLK GNDAUX2 DIGSDO AUX2_R GNDDG +15VA GNDDG...
  • Page 66 DTR-40.2/DHC-40.2 PRINTED CIRCUIT BOARD VIEW-6-3 U006 DISPLAY BOARD P7590A BADIS-0146 J7584 TUNING Q7500 S7641 J7577 PRESET PRESET S7645 S7642 U7560 S7590 J7560 ENTER S7643 J7544 J7545 MOVIE/TV DISPLAY TUNING MODE DIMMER GAME S7644 S7635 S7634 S7631 S7647 S7648 S7638 S7636 TUNING J7550 J7551...
  • Page 67 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40./TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-7-1 U007 HDMI board BAHDM-0471 P8006 R8078 R8042 R8018 TP3405 R8005 R8077 19PIN D8202 TP3406 R8076 C8008 R8287 Q8204 R8957 R8079 R8045 PWM2 C8014 Q8205 D8203 R8044 R8288 R8286 PWM3 C8020 R8032 R8029 R8289 Q3401 R8033 R8017 R8291 R8290...
  • Page 68 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40./TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-7-2 U007 HDMI board BAHDM-0471 B-SIDE B side view A side pattern B side pattern...
  • Page 69 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40./TX-NR808/TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-7-2 U007 HDMI board BAHDM-0471 B-SIDE B side view A side pattern B side pattern...
  • Page 70 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40./TX-NR808/ TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-8-1 U008 FRONT HDMI TERMINAL BOARD BAHDM-0290 U0080 Front HDMI terminal board BAHDM-0290...
  • Page 71 TX-NR708/HT-RC270/TX-NA708/DTR-40.2/DHC-40./TX-NR808/ TX-NA808/HT-RC280/TX-NR1008/TX-NA1008/DTR-50.2 PRINTED CIRCUIT BOARD VIEW-8-2 U008 FRONT HDMI C8680 C8680 TERMINAL BOARD L8661 L8661 BAHDM-0290 C8670 C8670 C8669 C8669 C8663 C8663 C8664 C8664 C8675 C8675 C8676 C8676 C8673 C8673 C8674 C8674 R8881 R8880 R8881 R8880 C3302 C3302 C3303 C3303 C8880 C8880 C3300...

  • Page 72: Exploded View Parts List

    1/135 PAGE HT-RC270 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
  • Page 73 2/135 PAGE Q6062 2SA1962-O 2202833 Q6062 or 2SA1962-R ( 1) 2202832 Q6063 2SA1962-O 2202833 Q6063 or 2SA1962-R ( 1) 2202832 Q6064 2SA1962-O 2202833 Q6064 or 2SA1962-R ( 1) 2202832 Q6065 2SA1962-O 2202833 Q6065 or 2SA1962-R ( 1) 2202832 Q6066 2SA1962-O 2202833 Q6066 or 2SA1962-R...
  • Page 74 3/135 PAGE A113 HOLDER KGLS-4S 27190009 A117 HOLDER HOLDER KGLS-8S 27190480 A119 HOLDER HOLDER KGLS-8S 27190480 A121 HOLDER KGPS-14RF 27190802 A123 HOLDER KGPS-14RF 27190802 A125 HOLDER KGPS-14RF 27190802 A127 HOLDER HOLDER KGLS-18S 27190470 A129 HOLDER HOLDER KGLS-18S 27190470 A131 HOLDER KGLS-14S 27190164 A133...
  • Page 75 4/135 PAGE A257 SCREW 3TTB+8B(3BC) 838430088GR A259 SCREW 3TTB+8B(3BC) 838430088GR A261 SCREW 3TTB+8B(3BC) 838430088GR A263 SCREW 3TTB+8B(3BC) 838430088GR A264 SCREW 3TTB+8B(3BC) 838430088GR A267 SCREW 3P+6FN(3BC) 82143006GR A269 SCREW 3P+6FN(3BC) 82143006GR A279 SCREW 3TTB+8B(3CM)SR 801637 A281 WASHER W3*10F(3BC) 87643010GR A283 LABEL (SP1) 29390790 A285...
  • Page 76 (B) (Bent) 28184972 A701 COVER (B) (Not Bent) 28184972Z A702 TAPE TAPE(CLOTH-8U) 29110082 A703 LABEL (COVER) 29364123 A705 LABEL HOOKUP-ONKYO 29363194 A715 SCREW 3TTB+8B(3BC) 838430088GR [TRANS COIL] T901 P TRANS NPT-1594D 2301990 [SW TRM] F2000 FUSE 4A-UL/T-233 252325GR F2000 or...

  • Page 77: Tuner Unit

    6/135 PAGE U0012 AMP HOLD PC BOARD AS BAETC-0446-1A 1B2485446-1A U0013 AMP HOLD PC BOARD AS BAETC-0447-1A 1B2485447-1A U0014 THERMAL PC BOARD AS BAETC-0448-1A 1B2485448-1A U0015 THERMAL PCB HOLD PC BOARD AS BAETC-0449-1A 1B2485449-1A U0016 HOLD FRONT HDMI CABLE PC BOARD AS BAETC-0455-1A 1B2485455-1A U003...
  • Page 78 INST SHEET U11(2010M/H_A.P.D.) 29355790 A1120 INST SHEET U3EnFrEs(FW_Update_270) 29355801 A851 POLY BAG D250xd300xW300(t0.04) 29100256A A855 TAPE (SEROHAN)NITTO NO.29 29110149 A861 LABEL (SPCABLE)2009 29390881 A881 WRNTY CARD (ONKYO) 29365135 A990 REMO CON RC-768M 24140768 A991 BATTERY R6/AA(UM-3) 3010194 A992 MIC-7000 245044...

  • Page 79: Pc Board Parts List

    8/135 PAGE A993 ANT COIL NMA-3057 232140 A994 FM ANT AS Type W 292191 HT-RC270 PC BOARD PARTS LIST U001 U0010~U0016 BAAMP-0444-1A * 1B248544-1A U0010 AMP (FINAL STAGE) PC BOARD AS BAAMP-0444-1A 1B2485444-1A U0011 VOLTAGE AMP PC BOARD AS BACLA-0445-1A 1B2485445-1A U0012 AMP HOLD PC BOARD AS...
  • Page 80 9/135 PAGE D6701 or C-DIODE 1SS355 ( 1) 223269R2 D6701 or C-DIODE KDS4148U ( 1) 223283R2 D6701 or C-DIODE MA2J1110GL ( 1) 223302R2 D6702 C-DIODE 1SS352 223234R2 D6702 or C-DIODE 1SS355 ( 1) 223269R2 D6702 or C-DIODE KDS4148U ( 1) 223283R2 D6702 or C-DIODE...
  • Page 81 10/135 PAGE Q5030 2SA949-Y(TPE6_F) 2211354T Q5030A RETAINER (CLA2) 27142140 Q5031 2SA949-Y(TPE6_F) 2211354T Q5031A RETAINER (CLA2) 27142140 Q5032 2SA949-Y(TPE6_F) 2211354T Q5032A RETAINER (CLA2) 27142140 Q5033 2SA949-Y(TPE6_F) 2211354T Q5033A RETAINER (CLA2) 27142140 Q5034 2SA949-Y(TPE6_F) 2211354T Q5034A RETAINER (CLA2) 27142140 Q5035 2SA949-Y(TPE6_F) 2211354T Q5035A RETAINER (CLA2)
  • Page 82 11/135 PAGE Q5065 2SA949-Y(TPE6_F) 2211354T Q5066 2SA949-Y(TPE6_F) 2211354T Q5070 2SC2229-Y(TPE6_F) 2211634T Q5071 2SC2229-Y(TPE6_F) 2211634T Q5072 2SC2229-Y(TPE6_F) 2211634T Q5073 2SC2229-Y(TPE6_F) 2211634T Q5074 2SC2229-Y(TPE6_F) 2211634T Q5075 2SC2229-Y(TPE6_F) 2211634T Q5076 2SC2229-Y(TPE6_F) 2211634T Q5250 2SA1930(ONK_Q) 2203000 Q5251 2SA1930(ONK_Q) 2203000 Q5252 2SA1930(ONK_Q) 2203000 Q5253 2SA1930(ONK_Q) 2203000 Q5254 2SA1930(ONK_Q)
  • Page 83 12/135 PAGE Q5431 or 2SC2229-O(TPE6_F) ( 1) 2211633T Q5432 2SC2229-Y(TPE6_F) 2211634T Q5432 or 2SC2229-O(TPE6_F) ( 1) 2211633T Q5433 2SC2229-Y(TPE6_F) 2211634T Q5433 or 2SC2229-O(TPE6_F) ( 1) 2211633T Q5434 2SC2229-Y(TPE6_F) 2211634T Q5434 or 2SC2229-O(TPE6_F) ( 1) 2211633T Q5435 2SC2229-Y(TPE6_F) 2211634T Q5435 or 2SC2229-O(TPE6_F) ( 1) 2211633T...
  • Page 84 13/135 PAGE Q6071 2SC2229-Y(TPE6_F) 2211634T Q6072 2SC2229-Y(TPE6_F) 2211634T Q6073 2SC2229-Y(TPE6_F) 2211634T Q6074 2SC2229-Y(TPE6_F) 2211634T Q6075 2SC2229-Y(TPE6_F) 2211634T Q6076 2SC2229-Y(TPE6_F) 2211634T Q6380 LM61CIZ 22242212 Q6380A RETAINER (PTH) 27141884-1 Q6502 2SA950-Y 2211504T Q6503 2SC1815-GR 2211255T Q6701 2SC2712-GR 2213145R2 Q6702 2SC2712-GR 2213145R2 Q6703 2SA1163-BL(TE85L_F) 2216756R2 Q6707...
  • Page 85 14/135 PAGE L6603 S-COIL SC-0.8X5.5X18.5T 231431S L6604 S-COIL SC-0.8X5.5X18.5T 231431S L6605 S-COIL SC-0.8X5.5X18.5T 231431S L6606 S-COIL SC-0.8X5.5X18.5T 231431S [CAPACITOR] C5000 UPZ C 2AUPZTF101JE 376331014T C5001 UPZ C 2AUPZTF101JE 376331014T C5002 UPZ C 2AUPZTF101JE 376331014T C5003 UPZ C 2AUPZTF101JE 376331014T C5004 UPZ C 2AUPZTF101JE 376331014T...
  • Page 86 15/135 PAGE C5050 UTSP C CE04W50V 47M(UTSP) 397584707T C5051 UTSP C CE04W50V 47M(UTSP) 397584707T C5052 UTSP C CE04W50V 47M(UTSP) 397584707T C5053 UTSP C CE04W50V 47M(UTSP) 397584707T C5054 UTSP C CE04W50V 47M(UTSP) 397584707T C5055 UTSP C CE04W50V 47M(UTSP) 397584707T C5056 UTSP C CE04W50V 47M(UTSP) 397584707T C5080...
  • Page 87 16/135 PAGE C5115 VR C CE04W100V-22M(VR) 394692207T C5116 VR C CE04W100V-22M(VR) 394692207T C5440 UTSP C CE04W50V-22M(UTSP) 397582207T C5441 UTSP C CE04W50V-22M(UTSP) 397582207T C5442 UTSP C CE04W50V-22M(UTSP) 397582207T C5443 UTSP C CE04W50V-22M(UTSP) 397582207T C5444 UTSP C CE04W50V-22M(UTSP) 397582207T C5445 UTSP C CE04W50V-22M(UTSP) 397582207T C5446...
  • Page 88 17/135 PAGE C6911 C-CERA C CC725CH1H-102J1 342101024R1 C6912 TF C ECQ-V100V-334J 374733344T C6913 TF C ECQ-V100V-334J 374733344T C6914 UTSP C CE04W50V-220M(UTSP) 397582217T [RESISTOR] R5000 CARBON R R16J-1.5K 417341524T R5001 CARBON R R16J-1.5K 417341524T R5002 CARBON R R16J-1.5K 417341524T R5003 CARBON R R16J-1.5K 417341524T R5004...
  • Page 89 18/135 PAGE R5040 CARBON R R16J-1K 417341024T R5041 CARBON R R16J-1K 417341024T R5042 CARBON R R16J-1K 417341024T R5043 CARBON R R16J-1K 417341024T R5044 CARBON R R16J-1K 417341024T R5045 CARBON R R16J-1K 417341024T R5046 CARBON R R16J-1K 417341024T R5050 CARBON R R16J-5.6K 417345624T R5051...
  • Page 90 19/135 PAGE R5095 CARBON R R16J-100K 417341044T R5096 CARBON R R16J-100K 417341044T R5100 CARBON R R16J-100K 417341044T R5101 CARBON R R16J-100K 417341044T R5102 CARBON R R16J-100K 417341044T R5103 CARBON R R16J-100K 417341044T R5104 CARBON R R16J-100K 417341044T R5105 CARBON R R16J-100K 417341044T R5106...
  • Page 91 20/135 PAGE R5143 NF CARBON R R25J-820 415478214T R5144 NF CARBON R R25J-820 415478214T R5145 NF CARBON R R25J-820 415478214T R5146 NF CARBON R R25J-820 415478214T R5150 NF CARBON R R25J-1.0K 415471024T R5151 NF CARBON R R25J-1.0K 415471024T R5152 NF CARBON R R25J-1.0K 415471024T R5153...
  • Page 92 21/135 PAGE R5191 NF CARBON R R25J-10 415471004T R5192 NF CARBON R R25J-10 415471004T R5193 NF CARBON R R25J-10 415471004T R5194 NF CARBON R R25J-10 415471004T R5195 NF CARBON R R25J-10 415471004T R5196 NF CARBON R R25J-10 415471004T R5200 CARBON R R16J-18K 417341834T R5201...
  • Page 93 22/135 PAGE R5276 NF CARBON R R25J-120 415471214T R5280 NF CARBON R R25J-120 415471214T R5281 NF CARBON R R25J-120 415471214T R5282 NF CARBON R R25J-120 415471214T R5283 NF CARBON R R25J-120 415471214T R5284 NF CARBON R R25J-120 415471214T R5285 NF CARBON R R25J-120 415471214T R5286...
  • Page 94 23/135 PAGE R5364 NF CARBON R R25J-18 415471804T R5365 NF CARBON R R25J-18 415471804T R5366 NF CARBON R R25J-18 415471804T R5370 NF CARBON R R25J-2.2 415470224T R5371 NF CARBON R R25J-2.2 415470224T R5372 NF CARBON R R25J-2.2 415470224T R5373 NF CARBON R R25J-2.2 415470224T R5374...
  • Page 95 24/135 PAGE R5452 CARBON R R16J-3.3K 417343324T R5453 CARBON R R16J-3.3K 417343324T R5454 CARBON R R16J-3.3K 417343324T R5455 CARBON R R16J-3.3K 417343324T R5456 CARBON R R16J-3.3K 417343324T R5470 NF CARBON R R25J-82 415478204T R5471 NF CARBON R R25J-82 415478204T R5472 NF CARBON R R25J-82 415478204T...
  • Page 96 25/135 PAGE R6010 C-CARBON R RN72K1J-332JE 435033324R1 R6011 C-CARBON R RN72K1J-332JE 435033324R1 R6012 C-CARBON R RN72K1J-332JE 435033324R1 R6013 C-CARBON R RN72K1J-332JE 435033324R1 R6014 C-CARBON R RN72K1J-332JE 435033324R1 R6015 C-CARBON R RN72K1J-332JE 435033324R1 R6016 C-CARBON R RN72K1J-332JE 435033324R1 R6020 C-CARBON R RN72K1J-000JE 435030004R1 R6021...
  • Page 97 26/135 PAGE R6145 CARBON R R16J-56K 417345634T R6146 CARBON R R16J-56K 417345634T R6150 CARBON R R16J-10K 417341034T R6151 CARBON R R16J-10K 417341034T R6152 CARBON R R16J-10K 417341034T R6153 CARBON R R16J-10K 417341034T R6154 CARBON R R16J-10K 417341034T R6155 CARBON R R16J-10K 417341034T R6156...
  • Page 98 27/135 PAGE R6507 C-CARBON R RN72K1J-473JE 435034734R1 R6508 C-CARBON R RN72K1J-182JE 435031824R1 R6509 C-CARBON R RN72K1J-331JE 435033314R1 R6600 METAL O R RS1/2WBJ-10 443521004T R6601 METAL O R RS1/2WBJ-10 443521004T R6602 METAL O R RS1/2WBJ-10 443521004T R6603 METAL O R RS1/2WBJ-10 443521004T R6604 METAL O R...
  • Page 99 28/135 PAGE E6009A NTM-1P232(M1700) 25060301 E6010A NTM-1P232(M1700) 25060301 F6901A FUSE HOLDER SN5051 250113 F6901B FUSE HOLDER SN5051 250113 F6902A FUSE HOLDER SN5051 250113 F6902B FUSE HOLDER SN5051 250113 JL6401A WIRE HOL NSCT-3P874 25051087 JL6401B WIRE HOL NSCT-3P874 25051087 JL6402A WIRE HOL NSCT-3P874 25051087 JL6402B...

  • Page 100: Pc Board Parts List

    29/135 PAGE P6082 PLUG NPLG-2P29 25055038 P6083 PLUG NPLG-2P29 25055038 P6084 PLUG NPLG-2P29 25055038 P6085 PLUG NPLG-2P29 25055038 P6086 PLUG NPLG-2P29 25055038 P6500 PLUG NPLG-2P83 25055099 P6600 SOCKET AS NSAS-14P1821 2009991176UL P6603A SOCKET AS NSAS-22P1828 2009991180UL P6606A SOCKET AS NSAS-18P1857 20099911815UL P6900 CRIMP AS...
  • Page 101 30/135 PAGE D6605 DIODE 1SS133 223163T D6606 DIODE 1SS133 223163T D6610 DIODE 1SS133 223163T D911 DIODE 1SS133 223163T D912 DIODE 1SS133 223163T D921 DIODE 1SS133 223163T D922 DIODE 1SS133 223163T D923 DIODE 1SS133 223163T D924 DIODE 1SS133 223163T D925 DIODE 1SS133 223163T D926...
  • Page 102 31/135 PAGE Q6606 or DTC123JS ( 1) 2213640T Q6608 2SC2235-Y(TPE6_F) 2211654T Q901 2SC1815-GR 2211255T Q901 or 2SC1815-Y ( 1) 2211254T Q9301 2SK365-GR 2212445T Q9302 2SK365-GR 2212445T Q9303 2SC1815-GR 2211255T Q9303 or 2SC1815-Y ( 1) 2211254T Q9304 2SA1015-GR 2211455T Q9304 or 2SA1015-Y ( 1) 2211454T...
  • Page 103 32/135 PAGE C6643 MKT C B32529C0472J289 376494724T C6644 MKT C B32529C0472J289 376494724T C6645 MKT C B32529C0472J289 376494724T C6646 MKT C B32529C0472J289 376494724T C6647 MKT C B32529C0472J289 376494724T C6648 MKT C B32529C0472J289 376494724T C6649 MKT C B32529C0472J289 376494724T C6650 MKT C B32529C0102J289 376491024T C6651...
  • Page 104 33/135 PAGE C9306 TF C ECQ-V50V-334J 374723344T C933 UTSP C CE04W50V-4.7M(UTSP) 397580477T [RESISTOR] R6601 METAL O R RS1/2WBJ-220 443522214T R6691 METAL O R RS1/2WBJ-390 443523914T R6692 METAL O R RS1/2WBJ-390 443523914T R921 METAL O R RS1/2WBJ-47 443524704T R922 METAL O R RS1/2WBJ-68 443526804T R9302...
  • Page 105 34/135 PAGE P6601A SOCKET IMSA-9142S-16A 25053230 P6603B PLUG NPLG-11P493 25055518 P6605A SOCKET IMSA-9142S-22A 25053233 P6606B PLUG NPLG-9P356 25055373 P6610 NTM-2PDMCR400 25060472 P6630 NTM-2PDMCR400 25060472 P6631 NTM-2PDMCR400 25060472 P6632 NTM-2PDMCR400 25060472 P6633 NTM-2PDMCR400 25060472 P6634 NTM-2PDMCR400 25060472 P6635 NTM-2PDMCR400 25060472 P6636 NTM-2PDMCR400 25060472 P6637...
  • Page 106 35/135 PAGE U004 U0040~U0041 BAASP-0458-1A * 1B248558-1A U0040 ANALOG AUDIO PC BOARD AS BAASP-0458-1A 1B2485458-1A U0041 D-SUB TERMINAL PC BOARD AS BAETC-0459-1A 1B2485459-1A CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [SEMI CONDUCTOR] D4505 C-DIODE KDS4148U 223283R2 D4505 or C-DIODE 1SS352 ( 1)
  • Page 107 36/135 PAGE D4910 ZENER D UDZS7.5B 224550750R2 D4911 ZENER D UDZS13B 224551300R2 Q4500 R2A15220FP 22242600R3 Q4502 NJM4580M-D 22241448R2 Q4503 NJM4580M-D 22241448R2 Q4504 NJM4580M-D 22241448R2 Q4550 2SK365-GR 2212445T Q4551 2SA1488-Y 2203394 Q4552 2SC1815-GR 2211255T Q4553 2SC2235-Y(TPE6_F) 2211654T Q4560 2SK365-GR 2212445T Q4561 2SC3851-Y 2203384 Q4562...
  • Page 108 37/135 PAGE P4520 HOLDER HOLDER(CLAMP) 27190540-1 [CAPACITOR] C4503 UPZ C 2AUPZTF221JE 376332214T C4504 UPZ C 2AUPZTF221JE 376332214T C4505 C-CERA C CC725CH1H-221J1 342102214R1 C4506 C-CERA C CC725CH1H-221J1 342102214R1 C4507 C-CERA C CC725CH1H-221J1 342102214R1 C4508 C-CERA C CC725CH1H-221J1 342102214R1 C4509 C-CERA C CC725CH1H-221J1 342102214R1 C4510...
  • Page 109 38/135 PAGE C4537 C-CERA C CC725CH1H-221J1 342102214R1 C4540 C-CERA C CC725CH1H-221J1 342102214R1 C4541 C-CERA C CC725CH1H-221J1 342102214R1 C4570 UTSP C CE04W50V 47M(UTSP) 397584707T C4571 UTSP C CE04W50V 47M(UTSP) 397584707T C4572 UTSP C CE04W50V 47M(UTSP) 397584707T C4573 UTSP C CE04W50V 47M(UTSP) 397584707T C4574 UTSP C...
  • Page 110 39/135 PAGE C4743 C-CERA C CK725B1H-152K1 332101525R1 C4744 TF C ECQ-V50V-123J 374721234T C4745 MKT C B32529C0332J289 376493324T C4746 C-CERA C CC725CH1H-151J1 342101514R1 C4747 UTSP C CE04W10V-220M(UTSP) 397532217T C4748 C-CERA C CC725CH1H-101J1 342101014R1 C4749 UTSP C CE04W50V-10M(UTSP) 397581007T C4750 C-CERA C CC725CH1H-102J1 342101024R1 C4751...
  • Page 111 40/135 PAGE C4833 UTSP C CE04W50V-10M(UTSP) 397581007T C4834 UTSP C CE04W50V-10M(UTSP) 397581007T C4835 UTSP C CE04W50V-10M(UTSP) 397581007T C4836 UTSP C CE04W50V-10M(UTSP) 397581007T C4840 TF C ECQ-V50V-104J 374721044T C4900 VR C CE04W35V-470M(VR) 394664717T C4901 UTSP C CE04W50V-22M(UTSP) 397582207T C4902 UTSP C CE04W25V-220M(UTSP) 397552217T C4903...
  • Page 112 41/135 PAGE R4518 C-CARBON R RN72K1J-331JE 435033314R1 R4519 C-CARBON R RN72K1J-331JE 435033314R1 R4520 C-CARBON R RN72K1J-331JE 435033314R1 R4521 C-CARBON R RN72K1J-331JE 435033314R1 R4522 C-CARBON R RN72K1J-331JE 435033314R1 R4523 METAL O R RS1/2WBJ-22 443522204T R4524 METAL O R RS1/2WBJ-22 443522204T R4526 C-CARBON R RN72K1J-101JE 435031014R1...
  • Page 113 42/135 PAGE R4565 C-CARBON R RN72K1J-224JE 435032244R1 R4566 C-CARBON R RN72K1J-223JE 435032234R1 R4567 C-CARBON R RN72K1J-224JE 435032244R1 R4570 C-CARBON R RN72K1J-101JE 435031014R1 R4571 C-CARBON R RN72K1J-101JE 435031014R1 R4572 C-CARBON R RN72K1J-101JE 435031014R1 R4573 C-CARBON R RN72K1J-101JE 435031014R1 R4574 C-CARBON R RN72K1J-101JE 435031014R1 R4575...
  • Page 114 43/135 PAGE R4642 C-CARBON R RN72K1J-101JE 435031014R1 R4643 C-CARBON R RN72K1J-101JE 435031014R1 R4644 C-CARBON R RN72K1J-101JE 435031014R1 R4645 C-CARBON R RN72K1J-101JE 435031014R1 R4646 C-CARBON R RN72K1J-101JE 435031014R1 R4647 C-CARBON R RN72K1J-101JE 435031014R1 R4650 C-CARBON R RN72K1J-224JE 435032244R1 R4651 C-CARBON R RN72K1J-224JE 435032244R1 R4652...
  • Page 115 44/135 PAGE R4747 C-CARBON R RN72K1J-101JE 435031014R1 R4748 C-CARBON R RN72K1J-224JE 435032244R1 R4749 C-CARBON R RN72K1J-220JE 435032204R1 R4750 C-CARBON R RN72K1J-331JE 435033314R1 R4751 C-CARBON R RN72K1J-563JE 435035634R1 R4752 C-CARBON R RN72K1J-474JE 435034744R1 R4753 C-CARBON R RN72K1J-561JE 435035614R1 R4754 C-CARBON R RN72K1J-274JE 435032744R1 R4755...
  • Page 116 45/135 PAGE R4800 C-CARBON R RN72K1J-122JE 435031224R1 R4801 C-CARBON R RN72K1J-122JE 435031224R1 R4806 C-CARBON R RN72K1J-000JE 435030004R1 R4807 C-CARBON R RN72K1J-000JE 435030004R1 R4820 C-CARBON R RN72K1J-104JE 435031044R1 R4821 C-CARBON R RN72K1J-104JE 435031044R1 R4822 C-CARBON R RN72K1J-104JE 435031044R1 R4823 C-CARBON R RN72K1J-104JE 435031044R1 R4825...
  • Page 117 46/135 PAGE R4911 METAL O R RS1/2WBJ-330 443523314T R4912 C-CARBON R RN72K2E-221JE 435222214R1 R4921 C-CARBON R RN72K1J-104JE 435031044R1 R8030 C-CARBON R RN72K1J-105JE 435031054R1 R8031 C-CARBON R RN72K1J-105JE 435031054R1 R8032 C-CARBON R RN72K1J-105JE 435031054R1 R8033 C-CARBON R RN72K1J-105JE 435031054R1 [SW TRM] E4520 TRM-423(SCREW) NEJITANSI ST3...

  • Page 118: Pc Board Parts List

    47/135 PAGE HT-RC270 PC BOARD PARTS LIST U005 U0050~U0054 BADG-0462-1H * 1B248562-1H U0050 DAC PC BOARD AS BADG-0462-1H 1B2485462-1H U0051 CPU PC BOARD AS BACPU-0463-1H 1B2485463-1H U0052 ANALOG VIDEO PC BOARD AS BAVD-0464-1H 1B2485464-1H U0053 UNIVERSAL PORT PC BOARD AS BAETC-0466-1H 1B2485466-1H U0054...
  • Page 119 48/135 PAGE D2008 DIODE RL1N4003 22380260T D2021 DIODE D5SBA20 22380130 D2022 DIODE D3SBA20 22380271F D2022 or DIODE RBV402 ( 1) 22380022F D7000 C-DIODE KDS4148U 223283R2 D7000 or C-DIODE 1SS352 ( 1) 223234R2 D7000 or C-DIODE MA2J111 ( 1) 223279R2 D7001 C-DIODE KDS4148U 223283R2...
  • Page 120 49/135 PAGE Q2109 NJW1325 22242596R3 Q7000 KRC104S 2216210R2 Q7000 or RN1404 ( 1) 2214490R2 Q7001 KRA102S 2216220R2 Q7001 or RN2402 ( 1) 2214530R2 Q7003 KRC104S 2216210R2 Q7003 or RN1404 ( 1) 2214490R2 Q7004 KRA102S 2216220R2 Q7004 or RN2402 ( 1) 2214530R2 Q7005 KRC102S...

  • Page 121: Choke Coil

    50/135 PAGE Q7019 KRA102S 2216220R2 Q7019 or RN2402 ( 1) 2214530R2 Q7020 MPD70F3746GJ-GAE-AX 222W0079R3 Q7021 KRC104S 2216210R2 Q7021 or RN1404 ( 1) 2214490R2 Q7022 KRA102S 2216220R2 Q7022 or RN2402 ( 1) 2214530R2 Q7023 XC6202P502FR 22242331R2 Q7024 KRC104S 2216210R2 Q7024 or RN1404 ( 1) 2214490R2...
  • Page 122 51/135 PAGE L1101 CHOKE COIL LBC2518T4R7M 231364M047R2 L1102 CHOKE COIL LBC2518T4R7M 231364M047R2 L1110 EMIFIL BK1608LM182-T 230958R1 L1111 CORE MMZ1608Y601BT 2350004R1 L1301 CHOKE COIL LBC2518T470M 231364M470R2 L1305 CHOKE COIL LBC2518T2R2M 231364M022R2 L1307 CHOKE COIL LBC2518T2R2M 231364M022R2 L1308 CHOKE COIL LBC2518T2R2M 231364M022R2 L1312 CHOKE COIL LBC2518T470M...
  • Page 123 52/135 PAGE L7905 EMIFIL BK1608LM182-T 230958R1 L7906 EMIFIL BK1608LM182-T 230958R1 L7907 EMIFIL BK1608LM182-T 230958R1 L7908 EMIFIL BK1608LM182-T 230958R1 L7909 EMIFIL BK1608LM182-T 230958R1 L7910 EMIFIL BK1608LM182-T 230958R1 L7911 EMIFIL BK1608LM182-T 230958R1 L7912 EMIFIL BK1608LM182-T 230958R1 L7913 EMIFIL BK1608LM182-T 230958R1 L7914 CHOKE COIL BLM21PG221SN1 230949R2 L7917...
  • Page 124 53/135 PAGE C1113 C-CERA C CK725F1E-104Z1 332161040R1 C1116 C-CERA C CC725CH1H-330J1 342103304R1 C1117 C-CERA C CC725CH1H-330J1 342103304R1 C1119 C-CERA C CC725CH1H-221J1 342102214R1 C1120 UTSJ C CE04W25V-47M(UTSJ) 398054707AT C1121 C-CERA C CC725CH1H-221J1 342102214R1 C1122 C-CERA C CK725F1E-104Z1 332161040R1 C1125 C-CERA C CC725CH1H-330J1 342103304R1 C1141...
  • Page 125 54/135 PAGE C1389 UTSP C CE04W10V-470M(UTSP) 397534717T C1390 UTSP C CE04W10V-470M(UTSP) 397534717T C1391 C-CERA C CK725F1E-104Z1 332161040R1 C1399 VR C CE04W16V-100M(VR) 394641017T C1400 C-CERA C CK725F1E-104Z1 332161040R1 C1401 C-CERA C CK725F1E-104Z1 332161040R1 C1408 C-CERA C CC725CH1H-080D1 342100802R1 C1409 C-CERA C CC725CH1H-080D1 342100802R1 C1415...
  • Page 126 55/135 PAGE C1615 UPZ C 2AUPZTF101JE 376331014T C1616 UPZ C 2AUPZTF101JE 376331014T C1617 UPZ C 2AUPZTF101JE 376331014T C1620 UPZ C 2AUPZTF101JE 376331014T C1621 UPZ C 2AUPZTF101JE 376331014T C1622 UPZ C 2AUPZTF101JE 376331014T C1623 UPZ C 2AUPZTF101JE 376331014T C1624 UPZ C 2AUPZTF101JE 376331014T C1625...
  • Page 127 56/135 PAGE C2044 C-CERA C CK725B1E-106K 332221065R2 C2115 UTSP C CE04W50V-10M(UTSP) 397581007T C2116 UTSP C CE04W50V-2.2M(UTSP) 397580227T C2127 C-CERA C CK725B1H-102K1 332101025R1 C2128 UTSP C CE04W50V-2.2M(UTSP) 397580227T C2137 C-CERA C CK725F1E-104Z1 332161040R1 C2138 UTSP C CE04W50V-2.2M(UTSP) 397580227T C2144 UTSP C CE04W50V-2.2M(UTSP) 397580227T C2147...
  • Page 128 57/135 PAGE C2208 UTSP C CE04W25V-47M(UTSP) 397554707T C2210 VR C CE04W6.3V-470M(VR) 394624717T C2212 C-CERA C CK725B1H-102K1 332101025R1 C2213 VR C CE04W6.3V-470M(VR) 394624717T C2214 VR C CE04W6.3V-470M(VR) 394624717T C2216 UTSP C CE04W25V-47M(UTSP) 397554707T C2217 C-CERA C CK725F1E-104Z1 332161040R1 C2219 VR C CE04W6.3V-470M(VR) 394624717T C2222...
  • Page 129 58/135 PAGE C2265 C-CERA C CK725B1A-105K1 332131055R1 C2267 UTSP C CE04W50V-1M(UTSP) 397580107T C2268 UTSP C CE04W50V-2.2M(UTSP) 397580227T C2270 C-CERA C CK725B1H-102K1 332101025R1 C2280 C-CERA C CC725CH1H-151J1 342101514R1 C2281 C-CERA C CC725CH1H-151J1 342101514R1 C2282 C-CERA C CC725CH1H-151J1 342101514R1 C2287 C-CERA C CK725F1E-104Z1 332161040R1 UTSP C...
  • Page 130 59/135 PAGE C7024 C-CERA C CK725B1H-102K1 332101025R1 C7025 C-CERA C CK725B1H-102K1 332101025R1 C7026 C-CERA C CK725F1A-105Z1 332181050R1 C7027 UTSP C CE04W50V-10M(UTSP) 397581007T C7028 UTSP C CE04W10V-100M(UTSP) 397531017T C7029 C-CERA C CK725F1E-104Z1 332161040R1 C7030 C-CERA C CK725F1E-104Z1 332161040R1 C7031 C-CERA C CK725B0J-106K 332091065R2 C7032...
  • Page 131 60/135 PAGE C7907 C-CERA C CK725B1H-102K1 332101025R1 C7908 C-CERA C CC725CH1H-101J1 342101014R1 C7909 C-CERA C CC725CH1H-101J1 342101014R1 C7910 C-CERA C CK725F1E-104Z1 332161040R1 C7912 C-CERA C CC725CH1H-471J1 342104714R1 C7914 UTSP C CE04W50V-10M(UTSP) 397581007T C7915 C-CERA C CC725CH1H-471J1 342104714R1 C7916 C-CERA C CC725CH1H-221J1 342102214R1 C7917...
  • Page 132 61/135 PAGE C7959 C-CERA C CC725CH1H-101J1 342101014R1 C7960 C-CERA C CC725CH1H-101J1 342101014R1 [RESISTOR] R1004 C-CARBON R RN72K1J-271JE 435032714R1 R1005 C-CARBON R RN72K1J-750JE 435037504R1 METAL O R RS1/2WBJ-10 443521004T R1100 C-CARBON R RN72K1J-221JE 435032214R1 R1101 C-CARBON R RN72K1J-681JE 435036814R1 R1102 C-CARBON R RN72K1J-103JE 435031034R1 R1103...
  • Page 133 62/135 PAGE R1233 C-CARBON R RN72K1J-331JE 435033314R1 R1241 C-CARBON R RN72K1J-151JE 435031514R1 R1242 C-CARBON R RN72K1J-750JE 435037504R1 R1243 METAL O R RS1WBJ-10 443621004T R1244 METAL O R RS1WBJ-15 443621504T R1245 C-CARBON R RN72K1J-470JE 435034704R1 R1246 C-CARBON R RN72K1J-000JE 435030004R1 R1248 C-CARBON R RN72K1J-470JE 435034704R1...
  • Page 134 63/135 PAGE R1522 C-CARBON R RN72K1J-103JE 435031034R1 R1523 C-CARBON R RN72K1J-103JE 435031034R1 R1524 C-CARBON R RN72K1J-823JE 435038234R1 R1529 C-CARBON R RN72K1J-470JE 435034704R1 R1532 C-CARBON R RN72K1J-103JE 435031034R1 R1534 C-CARBON R RN72K1J-823JE 435038234R1 R1567 C-CARBON R RN72K1J-331JE 435033314R1 R1568 C-CARBON R RN72K1J-221JE 435032214R1 R1569...
  • Page 135 64/135 PAGE R1623 C-CARBON R RN72K1J-332JE 435033324R1 R1624 C-CARBON R RN72K1J-332JE 435033324R1 R1625 C-CARBON R RN72K1J-332JE 435033324R1 R1626 C-CARBON R RN72K1J-332JE 435033324R1 R1627 C-CARBON R RN72K1J-332JE 435033324R1 R1630 C-CARBON R RN72K1J-183JE 435031834R1 R1631 C-CARBON R RN72K1J-183JE 435031834R1 R1632 C-CARBON R RN72K1J-183JE 435031834R1 R1633...
  • Page 136 65/135 PAGE R1664 C-CARBON R RN72K1J-471JE 435034714R1 R1665 C-CARBON R RN72K1J-471JE 435034714R1 R1666 C-CARBON R RN72K1J-471JE 435034714R1 R1667 C-CARBON R RN72K1J-471JE 435034714R1 R1670 C-CARBON R RN72K1J-471JE 435034714R1 R1671 C-CARBON R RN72K1J-471JE 435034714R1 R1672 C-CARBON R RN72K1J-471JE 435034714R1 R1673 C-CARBON R RN72K1J-471JE 435034714R1 R1674...
  • Page 137 66/135 PAGE R1831 C-CARBON R RN72K1J-562JE 435035624R1 R1840 C-CARBON R RN72K1J-393JE 435033934R1 R1841 C-CARBON R RN72K1J-393JE 435033934R1 R1850 C-CARBON R RN72K1J-103JE 435031034R1 R1851 C-CARBON R RN72K1J-103JE 435031034R1 R1860 C-CARBON R RN72K1J-103JE 435031034R1 R1861 C-CARBON R RN72K1J-103JE 435031034R1 R1870 C-CARBON R RN72K1J-562JE 435035624R1 R1871...
  • Page 138 67/135 PAGE R2146 C-CARBON R RN72K1J-101JE 435031014R1 R2147 C-CARBON R RN72K1J-750JE 435037504R1 R2150 C-CARBON R RN72K1J-000JE 435030004R1 R2154 C-CARBON R RN72K1J-101JE 435031014R1 R2155 C-CARBON R RN72K1J-750JE 435037504R1 R2156 C-CARBON R RN72K1J-101JE 435031014R1 R2157 C-CARBON R RN72K1J-103JE 435031034R1 R2159 C-CARBON R RN72K1J-392JE 435033924R1 R2161...
  • Page 139 68/135 PAGE R2238 C-CARBON R RN72K1J-105JE 435031054R1 R2239 C-CARBON R RN72K1J-105JE 435031054R1 R2240 C-CARBON R RN72K1J-105JE 435031054R1 R2241 C-CARBON R RN72K1J-105JE 435031054R1 R2243 C-CARBON R RN72K1J-682JE 435036824R1 R2244 C-CARBON R RN72K1J-101JE 435031014R1 R2245 C-CARBON R RN72K1J-104JE 435031044R1 R2246 C-CARBON R RN72K1J-104JE 435031044R1 R2247...
  • Page 140 69/135 PAGE R2305 C-CARBON R RN72K1J-750JE 435037504R1 R2307 C-CARBON R RN72K1J-750JE 435037504R1 R2308 C-CARBON R RN72K1J-104JE 435031044R1 R2309 C-CARBON R RN72K1J-104JE 435031044R1 R2310 C-CARBON R RN72K1J-104JE 435031044R1 NF CARBON R R25J-10 415471004T C-CARBON R RN72K1J-273JE 435032734R1 C-CARBON R RN72K1J-273JE 435032734R1 C-CARBON R RN72K1J-273JE 435032734R1...
  • Page 141 70/135 PAGE R7021 C-CARBON R RN72K1J-470JE 435034704R1 R7022 C-CARBON R RN72K1J-470JE 435034704R1 R7023 C-CARBON R RN72K1J-221JE 435032214R1 R7024 C-CARBON R RN72K1J-221JE 435032214R1 R7025 C-CARBON R RN72K1J-221JE 435032214R1 R7026 C-CARBON R RN72K1J-470JE 435034704R1 R7027 C-CARBON R RN72K1J-470JE 435034704R1 R7028 C-CARBON R RN72K1J-221JE 435032214R1 R7029...
  • Page 142 71/135 PAGE R7065 C-CARBON R RN72K1J-473JE 435034734R1 R7066 C-CARBON R RN72K1J-472JE 435034724R1 R7067 C-CARBON R RN72K1J-473JE 435034734R1 R7068 C-CARBON R RN72K1J-473JE 435034734R1 R7069 C-CARBON R RN72K1J-473JE 435034734R1 R7070 C-CARBON R RN72K1J-473JE 435034734R1 R7071 C-CARBON R RN72K1J-473JE 435034734R1 R7072 C-CARBON R RN72K1J-473JE 435034734R1 R7073...
  • Page 143 72/135 PAGE R7103 C-CARBON R RN72K1J-470JE 435034704R1 R7104 C-CARBON R RN72K1J-221JE 435032214R1 R7105 C-CARBON R RN72K1J-470JE 435034704R1 R7107 C-CARBON R RN72K1J-221JE 435032214R1 R7108 C-CARBON R RN72K1J-221JE 435032214R1 R7110 C-CARBON R RN72K1J-221JE 435032214R1 R7111 C-CARBON R RN72K1J-470JE 435034704R1 R7113 C-CARBON R RN72K1J-102JE 435031024R1 R7114...
  • Page 144 73/135 PAGE R7145 C-CARBON R RN72K1J-221JE 435032214R1 R7146 C-CARBON R RN72K1J-221JE 435032214R1 R7147 C-CARBON R RN72K1J-470JE 435034704R1 R7148 METAL R RNU1WCJ-1.5 453630154T R7149 METAL R RNU1WCJ-1.5 453630154T R7150 C-CARBON R RN72K1J-473JE 435034734R1 R7151 C-CARBON R RN72K1J-470JE 435034704R1 R7152 C-CARBON R RN72K1J-102JE 435031024R1 R7153...
  • Page 145 74/135 PAGE R7186 C-CARBON R RN72K1J-473JE 435034734R1 R7187 C-CARBON R RN72K1J-473JE 435034734R1 R7188 C-CARBON R RN72K1J-473JE 435034734R1 R7189 C-CARBON R RN72K1J-272JE 435032724R1 R7190 C-CARBON R RN72K1J-272JE 435032724R1 R7191 C-CARBON R RN72K1J-272JE 435032724R1 R7192 C-CARBON R RN72K1J-272JE 435032724R1 R7194 C-CARBON R RN72K1J-272JE 435032724R1 R7195...
  • Page 146 75/135 PAGE R7222 C-CARBON R RN72K1J-273JE 435032734R1 R7224 C-CARBON R RN72K1J-473JE 435034734R1 R7225 C-CARBON R RN72K1J-470JE 435034704R1 R7227 C-CARBON R RN72K1J-470JE 435034704R1 R7228 C-CARBON R RN72K1J-470JE 435034704R1 R7229 C-CARBON R RN72K1J-470JE 435034704R1 R7230 C-CARBON R RN72K1J-470JE 435034704R1 R7231 C-CARBON R RN72K1J-103JE 435031034R1 R7232...
  • Page 147 76/135 PAGE R7917 C-CARBON R RN72K1J-123JE 435031234R1 R7930 C-CARBON R RN72K1J-750JE 435037504R1 R7931 C-CARBON R RN72K1J-220JE 435032204R1 R7932 C-CARBON R RN72K1J-222JE 435032224R1 R7933 THERMISTOR FUSB090F 4000252T R7934 C-CARBON R RN72K1J-220JE 435032204R1 R7935 C-CARBON R RN72K1J-220JE 435032204R1 R7936 C-CARBON R RN72K1J-103JE 435031034R1 R7937 C-CARBON R...
  • Page 148 77/135 PAGE P2102A PLUG IMSA-9142B-16A 25056598 P2102B SOCKET IMSA-9142S-16A 25053230 P2103A PLUG IMSA-9142B-18A 25056599 P2103B SOCKET IMSA-9142S-18A 25053231 P2107 RETAINER (JOINT) 27142069 P2108 PIN JACK NPJ-9PDGLRGLRGLR563 25045781 P2108 or PIN JACK NPJ-9PDGLR519 ( 1) 25045731 P2114 TRM-423(SCREW) NEJITANSI ST3 25060495 P2115 PIN JACK NPJ-10PDBY621...

  • Page 149: Pc Board Parts List

    78/135 PAGE HT-RC270 PC BOARD PARTS LIST U006 U0060~U0067 BADIS-0110-1F * 1B234510-1F U0060 DISPLAY PC BOARD AS BADIS-0110-1F 1B2485110-1F U0061 DISPLAY SW PC BOARD AS BASW-0111-1F 1B2485111-1F U0062 FL POWER SUPPLY PC BOARD AS BAPS-0112-1F 1B2485112-1F U0063 HEADPHONE TERMINAL PC BOARD AS BAETC-0113-1F 1B2485113-1F U0064...
  • Page 150 79/135 PAGE D7523 or C-DIODE KDS4148U ( 1) 223283R2 D7530 ZENER D UDZS5.1B 224550510R2 D7531 C-DIODE 1SS355 223269R2 D7531 or C-DIODE 1SS352 ( 1) 223234R2 D7531 or C-DIODE MA2J111 ( 1) 223279R2 D7531 or C-DIODE KDS4148U ( 1) 223283R2 D7532 C-DIODE 1SS355 223269R2...
  • Page 151 80/135 PAGE D7583 or C-DIODE KDS4148U ( 1) 223283R2 D7590 SCB3318E-D2 225487 D7590A HOLDER (LED)LH-5-5 27191312 D7593 SLI-343Y8C-TE7 225490T D7595 SLI-343URC-TE7 225449T D7597 SLR-342MGTE7P 225455T D7599 SCB3318E-D2 225487 D7599A HOLDER (LED)LH-5-5 27191312 D7806 ZENER D UDZS22B 224552200R2 D7810 ZENER D UDZS24B 224552400R2 D7812...
  • Page 152 81/135 PAGE L7530 CHOKE COIL LBC2518T2R2M 231364M022R2 L7580 CHOKE COIL LBC2518T2R2M 231364M022R2 L7581 CHOKE COIL LBC2518T2R2M 231364M022R2 L7582 CHOKE COIL LBC2518T2R2M 231364M022R2 [CAPACITOR] C7501 C-CERA C CK725B1H-223K1 332102235R1 C7502 C-CERA C CK725F1E-104Z1 332161040R1 C7503 C-CERA C CK725F1E-104Z1 332161040R1 C7504 C-CERA C CK725B1H-473K1 332104735R1 C7505...
  • Page 153 82/135 PAGE C7563 C-CERA C CK725F1E-104Z1 332161040R1 C7580 MKT C B32529C0102J289 376491024T C7581 MKT C B32529C0102J289 376491024T C7582 MKT C B32529C0102J289 376491024T C7583 MKT C B32529C0102J289 376491024T C7590 C-CERA C CK725B1H-103K1 332101035R1 C7591 C-CERA C CK725B1H-103K1 332101035R1 C7804 VR C CE04W63V-220M(VR) 394672217T C7805...
  • Page 154 83/135 PAGE R7533 C-CARBON R RN72K1J-182JE 435031824R1 R7534 C-CARBON R RN72K1J-104JE 435031044R1 R7535 C-CARBON R RN72K1J-102JE 435031024R1 R7536 C-CARBON R RN72K1J-333JE 435033334R1 R7537 C-CARBON R RN72K1J-333JE 435033334R1 R7538 C-CARBON R RN72K1J-221JE 435032214R1 R7539 C-CARBON R RN72K1J-221JE 435032214R1 R7540 C-CARBON R RN72K1J-473JE 435034734R1 R7560...
  • Page 155 84/135 PAGE R7624 C-CARBON R RN72K1J-561JE 435035614R1 R7625 C-CARBON R RN72K1J-821JE 435038214R1 R7626 C-CARBON R RN72K1J-122JE 435031224R1 R7627 C-CARBON R RN72K1J-222JE 435032224R1 R7628 C-CARBON R RN72K1J-392JE 435033924R1 R7629 C-CARBON R RN72K1J-123JE 435031234R1 R7631 C-CARBON R RN72K1J-271JE 435032714R1 R7632 C-CARBON R RN72K1J-331JE 435033314R1 R7633...
  • Page 156 85/135 PAGE E7530 RETAINER (EARTH) 27142136B E7580 TRM-423(SCREW) NEJITANSI ST3 25060495 E7601 TRM-423(SCREW) NEJITANSI ST3 25060495 JL4103A WIRE HOL NSCT-5P896 25051109 JL9303A WIRE HOL NSCT-5P876 25051089 JL9303B WIRE TRAP NPLG-5P588 25055626 P7303A PLUG NPLG-2P130 25055146 P7303B SOCKET AS NSAS-4P0867 2002E390415 P7501B PLUG A2545WR2-2x20P(IDE40SIDE)
  • Page 157 86/135 PAGE S7620 or PUSH SW NPS-111-S677 ( 1) 25035714T S7621 PUSH SW NPS-111-S681 25035718T S7621 or PUSH SW NPS-111-S677 ( 1) 25035714T S7622 PUSH SW NPS-111-S681 25035718T S7622 or PUSH SW NPS-111-S677 ( 1) 25035714T S7624 PUSH SW NPS-111-S681 25035718T S7624 or PUSH SW...
  • Page 158 87/135 PAGE S7641 PUSH SW NPS-111-S681 25035718T S7641 or PUSH SW NPS-111-S677 ( 1) 25035714T S7642 PUSH SW NPS-111-S681 25035718T S7642 or PUSH SW NPS-111-S677 ( 1) 25035714T S7643 PUSH SW NPS-111-S681 25035718T S7643 or PUSH SW NPS-111-S677 ( 1) 25035714T S7644 PUSH SW...
  • Page 159 88/135 PAGE D8161 ZENER D UDZS3.6B 224550360R2 D8204 DIODE DAN217T146 223285R2 D8205 DIODE DAN217T146 223285R2 D8301 DIODE DAN217T146 223285R2 D8302 C-DIODE KDS4148U 223283R2 D8302 or C-DIODE 1SS352 ( 1) 223234R2 D8302 or C-DIODE MA2J111 ( 1) 223279R2 D8701 C-DIODE KDS4148U 223283R2 D8701 or C-DIODE...
  • Page 160 89/135 PAGE Q3102 BD2224G-TR 22242672R2 Q3103 XC6221B182MR 22242632R2 Q3103 or BH18LB1WG-TR ( 1) 22242562R2 Q3105 MFI341S2164 22242594R2 Q3106 XC6221B332MR 22242633R2 Q3106 or BH33FB1WG-TR ( 1) 22242585R2 Q3107 NJM2855DL1-33 22278033QR2JR Q3108 KSZ8041NL 22242591R2 Q3109 BD7820 22242300R2 Q3202 TC74VHC157FT 22274157ER2TO Q3204 TC74VHC74FT（EKJ) 22274074E1R2TO Q3204 or TC74VHC74FT...
  • Page 161 90/135 PAGE Q8201 BR24S32FJ-WE2 22242569R2 Q8201 or 24LC32A-I/SN ( 1) 22242521R2 Q8201 or M24C32-WMN6TP ( 1) 22242644R2 Q8206 AT25DF641-S3H-T 222W0110R2 Q8207 TC74LCX125FT(EL_K) 22274125BR2TO Q8305 S-812C50BUC-C5ET2G 22242407R2 Q8306 NC7SZ08P5X_F042 22242482R2 Q8306 or TC7SZ08FU(TE85L_F) ( 1) 22242071R2TO Q8401 SII9136CTU 22242630R3 Q8402 TC7WHU04FU(TE12L) 22242231R2 Q8501 SII9233ACTU...
  • Page 162 91/135 PAGE Q8952 MP2363DN-LF-Z 22242627R2 Q8961 KRC104S 2216210R2 Q8961 or RN1404 ( 1) 2214490R2 Q8962 MP2363DN-LF-Z 22242627R2 Q8963 2SC2712-GR 2213145R2 Q8971 KRC104S 2216210R2 Q8971 or RN1404 ( 1) 2214490R2 Q8972 MP2363DN-LF-Z 22242627R2 Q8981 KRC104S 2216210R2 Q8981 or RN1404 ( 1) 2214490R2 Q8982 MP2363DN-LF-Z...
  • Page 163 92/135 PAGE L3202 CORE MMZ1608Y601BT 2350004R1 L3203 CORE MMZ1608Y601BT 2350004R1 L3205 CORE BLM18PG121SN1D 2350006R1 L3206 CORE BLM18PG121SN1D 2350006R1 L3207 CORE MMZ1608Y601BT 2350004R1 L3208 CORE MMZ1608Y601BT 2350004R1 L3209 CORE MMZ1608Y601BT 2350004R1 L3401 CORE BLM18PG121SN1D 2350006R1 L3402 CORE MMZ1608Y601BT 2350004R1 L3403 CORE MMZ1608Y601BT 2350004R1 L3404...
  • Page 164 93/135 PAGE L8207 CORE BLM18PG121SN1D 2350006R1 L8208 CORE BLM18PG181SN1D 2350005R1 L8209 CORE BLM18PG181SN1D 2350005R1 L8210 CORE BLM18PG181SN1D 2350005R1 L8211 CORE BLM18PG181SN1D 2350005R1 L8212 CORE BLM18PG181SN1D 2350005R1 L8213 CORE BLM18PG181SN1D 2350005R1 L8214 CORE BLM18PG181SN1D 2350005R1 L8215 C-CARBON R RN72K1J-000JE 435030004R1 L8216 CORE BLM18PG181SN1D 2350005R1...
  • Page 165 94/135 PAGE L8931 CORE BLM18PG181SN1D 2350005R1 L8941 CHOKE COIL BLM21PG221SN1 230949R2 L8951 CHOKE COIL BLM21PG221SN1 230949R2 L8952 CHOKE COIL 0182-7E08Q-100M-RA 231396M100R2 L8953 CHOKE COIL BLM21PG221SN1 230949R2 L8954 CHOKE COIL BLM21PG221SN1 230949R2 L8955 CHOKE COIL BLM21PG221SN1 230949R2 L8956 CHOKE COIL BLM21PG221SN1 230949R2 L8961 CHOKE COIL...
  • Page 166 95/135 PAGE C3001 C-CERA C CK725F1A-105Z1 332181050R1 C3002 C-CERA C CK725F1A-105Z1 332181050R1 C3003 C-CERA C CK725B0J-106K 332091065R2 C3004 C-CERA C CK725B0J-106K 332091065R2 C3005 C-CERA C CK725F1A-105Z1 332181050R1 C3006 C-CERA C CC725CH1H-102J1 342101024R1 C3007 C-CERA C CK725F1A-105Z1 332181050R1 C3008 C-CERA C CC725CH1H-102J1 342101024R1 C3009...
  • Page 167 96/135 PAGE C3034 C-CERA C CC725CH1H-120J1 342101204R1 C3035 C-CERA C CC725CH1H-102J1 342101024R1 C3036 C-CERA C CC725CH1H-120J1 342101204R1 C3037 C-CERA C CK725F1A-105Z1 332181050R1 C3038 C-CERA C CK725F1A-105Z1 332181050R1 C3039 C-CERA C CK725B1H-103K1 332101035R1 C3040 C-CERA C CK725F1A-105Z1 332181050R1 C3041 C-CERA C CK725B0J-106K 332091065R2 C3042...
  • Page 168 97/135 PAGE C3126 C-CERA C CK725B0J-106K 332091065R2 C3127 C-CERA C CK725F1A-105Z1 332181050R1 C3128 C-CERA C CK725F1A-105Z1 332181050R1 C3129 C-CERA C CK725F1A-105Z1 332181050R1 C3130 C-CERA C CK725B0J-106K 332091065R2 C3131 C-CERA C CK725F1A-105Z1 332181050R1 C3132 C-CERA C CC725CH1H-101J1 342101014R1 C3133 C-CERA C CK725F1A-105Z1 332181050R1 C3134...
  • Page 169 98/135 PAGE C3204 C-CERA C CK725B0J-106K 332091065R2 C3205 C-CERA C CK725F1A-105Z1 332181050R1 C3206 C-CERA C CK725F1A-105Z1 332181050R1 C3207 C-CERA C CK725B0J-106K 332091065R2 C3208 C-CERA C CK725F1A-105Z1 332181050R1 C3209 C-CERA C CK725F1A-105Z1 332181050R1 C3210 CHIP ELECT C CEWX16V-100M 398141017R2 C3211 C-CERA C CC725CH1H-221J1 342102214R1 C3213...
  • Page 170 99/135 PAGE C3411 C-CERA C CK725F1E-104Z1 332161040R1 C3412 C-CERA C CK725F1E-104Z1 332161040R1 C3413 C-CERA C CC725CH1H-180J1 342101804R1 C3414 C-CERA C CC725CH1H-180J1 342101804R1 C3415 C-CERA C CK725F1E-104Z1 332161040R1 C3416 C-CERA C CK725F1E-104Z1 332161040R1 C3418 C-CERA C CK725F1E-104Z1 332161040R1 C3419 C-CERA C CK725F1E-104Z1 332161040R1 C3420...
  • Page 171 100/135 PAGE C3447 C-CERA C CK725F1A-105Z1 332181050R1 C3448 CHIP ELECT C CEWX6.3V-22M 398122207R2 C3449 CHIP ELECT C CEWX4V-220M 3981G2217R2 C3457 C-CERA C CK725F1A-105Z1 332181050R1 C3458 C-CERA C CK725F1A-105Z1 332181050R1 C3459 C-CERA C CK725F1A-105Z1 332181050R1 C3460 C-CERA C CK725F1E-104Z1 332161040R1 C3461 C-CERA C CK725F1E-104Z1 332161040R1...
  • Page 172 101/135 PAGE C8032 CHIP TANTAL TEESVA0J226M8R 398422207R2 C8032 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 C8032 or CHIP TANTAL TCSCS0J226MAAR ( 1) 396522207R2 C8033 C-CERA C CK725F1E-104Z1 332161040R1 C8034 C-CERA C CK725B1H-102K1 332101025R1 C8035 C-CERA C CK725F1E-104Z1 332161040R1 C8036 C-CERA C CK725B0J-106K 332091065R2 C8037...
  • Page 173 102/135 PAGE C8070 C-CERA C CK725B1H-102K1 332101025R1 C8071 C-CERA C CK725B1H-103K1 332101035R1 C8072 C-CERA C CK725B1H-102K1 332101025R1 C8073 C-CERA C CK725B1H-103K1 332101035R1 C8074 CHIP TANTAL TEESVA0J226M8R 398422207R2 C8074 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 C8074 or CHIP TANTAL TCSCS0J226MAAR ( 1) 396522207R2 C8075...
  • Page 174 103/135 PAGE C8162 C-CERA C CK725F1E-104Z1 332161040R1 C8165 C-CERA C CK725F1E-104Z1 332161040R1 C8166 C-CERA C CK725B1H-102K1 332101025R1 C8167 C-CERA C CK725F1E-104Z1 332161040R1 C8168 C-CERA C CK725B1H-102K1 332101025R1 C8169 C-CERA C CK725F1E-104Z1 332161040R1 C8170 C-CERA C CK725B1H-102K1 332101025R1 C8171 C-CERA C CK725F1E-104Z1 332161040R1 C8172...
  • Page 175 104/135 PAGE C8198 C-CERA C CK725B1A-105K1 332131055R1 C8199 C-CERA C CK725B0J-106K 332091065R2 C8200 C-CERA C CK725F1E-104Z1 332161040R1 C8201 C-CERA C CK725B1H-102K1 332101025R1 C8202 CHIP TANTAL TEESVA0J226M8R 398422207R2 C8202 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 C8202 or CHIP TANTAL TCSCS0J226MAAR ( 1) 396522207R2 C8203...
  • Page 176 105/135 PAGE C8225 C-CERA C CK725B1H-102K1 332101025R1 C8226 C-CERA C CK725F1E-104Z1 332161040R1 C8227 C-CERA C CK725B1H-102K1 332101025R1 C8228 C-CERA C CK725F1E-104Z1 332161040R1 C8229 C-CERA C CK725F1E-104Z1 332161040R1 C8230 CHIP TANTAL TEESVA0J226M8R 398422207R2 C8230 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 C8230 or CHIP TANTAL TCSCS0J226MAAR...
  • Page 177 106/135 PAGE C8258 C-CERA C CK725F1E-104Z1 332161040R1 C8259 C-CERA C CK725F1E-104Z1 332161040R1 C8260 C-CERA C CK725B0J-106K 332091065R2 C8261 C-CERA C CK725F1E-104Z1 332161040R1 C8262 C-CERA C CK725F1E-104Z1 332161040R1 C8263 C-CERA C CK725B0J-106K 332091065R2 C8264 C-CERA C CK725F1E-104Z1 332161040R1 C8265 C-CERA C CK725F1E-104Z1 332161040R1 C8266...
  • Page 178 107/135 PAGE C8287 C-CERA C CK725B1H-103K1 332101035R1 C8288 C-CERA C CK725B1H-102K1 332101025R1 C8289 C-CERA C CK725F1E-104Z1 332161040R1 C8290 C-CERA C CK725B1H-102K1 332101025R1 C8291 C-CERA C CK725F1E-104Z1 332161040R1 C8292 C-CERA C CK725F1A-105Z1 332181050R1 C8293 CHIP TANTAL TEESVA0J226M8R 398422207R2 C8293 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2...
  • Page 179 108/135 PAGE C8410 C-CERA C CK725B1H-103K1 332101035R1 C8411 C-CERA C CK725F1E-104Z1 332161040R1 C8412 C-CERA C CK725B1H-103K1 332101035R1 C8413 C-CERA C CK725F1E-104Z1 332161040R1 C8414 C-CERA C CK725B1H-103K1 332101035R1 C8415 C-CERA C CK725F1E-104Z1 332161040R1 C8416 C-CERA C CK725B1H-103K1 332101035R1 C8417 C-CERA C CK725F1E-104Z1 332161040R1 C8418...
  • Page 180 109/135 PAGE C8508 C-CERA C CK725F1A-105Z1 332181050R1 C8509 C-CERA C CK725B1H-102K1 332101025R1 C8510 C-CERA C CK725F1A-105Z1 332181050R1 C8511 C-CERA C CK725B1H-102K1 332101025R1 C8512 C-CERA C CK725F1E-104Z1 332161040R1 C8513 C-CERA C CK725B1H-102K1 332101025R1 C8514 C-CERA C CK725F1E-104Z1 332161040R1 C8515 C-CERA C CK725B1H-102K1 332101025R1 C8516...
  • Page 181 110/135 PAGE C8555 C-CERA C CK725B1H-102K1 332101025R1 C8556 C-CERA C CK725F1E-104Z1 332161040R1 C8557 C-CERA C CK725B1H-102K1 332101025R1 C8560 C-CERA C CK725B0J-106K 332091065R2 C8561 C-CERA C CK725B0J-106K 332091065R2 C8563 C-CERA C CK725B0J-106K 332091065R2 C8565 C-CERA C CK725B0J-106K 332091065R2 C8566 C-CERA C CK725B1H-102K1 332101025R1 C8567...
  • Page 182 111/135 PAGE C8706 C-CERA C CK725F1A-105Z1 332181050R1 C8707 C-CERA C CK725F1A-105Z1 332181050R1 C8708 C-CERA C CK725F1A-105Z1 332181050R1 C8709 C-CERA C CK725B0J-106K 332091065R2 C8710 C-CERA C CK725F1A-105Z1 332181050R1 C8801 C-CERA C CK725F1E-104Z1 332161040R1 C8802 C-CERA C CK725F1E-104Z1 332161040R1 C8803 C-CERA C CK725F1E-104Z1 332161040R1 C8804...
  • Page 183 112/135 PAGE C8934 C-CERA C CK725B1E-106K 332221065R2 C8935 CHIP ELECT C CEWX16V-100M 398141017R2 C8936 C-CERA C CK725B0J-106K 332091065R2 C8937 C-CERA C CK725B0J-106K 332091065R2 C8938 C-CERA C CK725B1C-104K1 332121045R1 C8939 C-CERA C CK725B0J-106K 332091065R2 C8940 C-CERA C CK725B0J-106K 332091065R2 C8942 CHIP TANTAL TEESVB20J107M8R 398421017R2 C8942 or...
  • Page 184 113/135 PAGE C8971 C-CERA C CK725B1C-104K1 332121045R1 C8972 C-CERA C CK725B1E-106K 332221065R2 C8973 C-CERA C CK725B1E-106K 332221065R2 C8974 C-CERA C CK725B1C-104K1 332121045R1 C8976 C-CERA C CK725B1H-223K1 332102235R1 C8977 C-CERA C CC725CH1H-331J1 342103314R1 C8978 C-CERA C CK725B0J-106K 332091065R2 C8979 C-CERA C CK725B0J-106K 332091065R2 C8980...
  • Page 185 114/135 PAGE R273 C-CARBON R RN72K1J-331JE 435033314R1 R274 C-CARBON R RN72K1J-470JE 435034704R1 R275 C-CARBON R RN72K1J-221JE 435032214R1 R276 C-CARBON R RN72K1J-221JE 435032214R1 R277 C-CARBON R RN72K1J-151JE 435031514R1 R278 C-CARBON R RN72K1J-331JE 435033314R1 R279 C-CARBON R RN72K1J-331JE 435033314R1 R280 C-CARBON R RN72K1J-470JE 435034704R1 R3009...
  • Page 186 115/135 PAGE R3037 C-CARBON R RN72K1J-470JE 435034704R1 R3038 C-CARBON R RN72K1J-470JE 435034704R1 R3039 C-CARBON R RN72K1J-470JE 435034704R1 R3040 C-CARBON R RN72K1J-103JE 435031034R1 R3041 C-R NET RM7LJ330X04 43484733004R2 R3042 C-R NET RM7LJ330X04 43484733004R2 R3043 C-CARBON R RN72K1J-000JE 435030004R1 R3044 C-R NET RM7LJ330X04 43484733004R2 R3045...
  • Page 187 116/135 PAGE R3117 C-CARBON R RN72K1J-103JE 435031034R1 R3119 C-CARBON R RN72K1J-472JE 435034724R1 R3122 C-CARBON R RN72K1J-102JE 435031024R1 R3123 C-CARBON R RN72K1J-000JE 435030004R1 R3124 C-CARBON R RN72K1J-331JE 435033314R1 R3125 C-CARBON R RN72K1J-470JE 435034704R1 R3126 C-CARBON R RN72K1J-470JE 435034704R1 R3127 C-CARBON R RN72K1J-470JE 435034704R1 R3128...
  • Page 188 117/135 PAGE R3158 C-CARBON R RN72K1J-000JE 435030004R1 R3159 C-CARBON R RN72K1J-000JE 435030004R1 R3160 C-CARBON R RN72K1J-000JE 435030004R1 R3162 C-CARBON R RN72K1J-390JE 435033904R1 R3163 C-CARBON R RN72K1J-220JE 435032204R1 R3164 C-CARBON R RN72K1J-472JE 435034724R1 R3168 C-CARBON R RN72K1J-220JE 435032204R1 R3169 C-CARBON R RN72K1J-220JE 435032204R1 R3170...
  • Page 189 118/135 PAGE R3200 C-CARBON R RN72K1J-103JE 435031034R1 R3201 C-CARBON R RN72K1J-103JE 435031034R1 R3202 C-CARBON R RN72K1J-103JE 435031034R1 R3203 C-CARBON R RN72K1J-103JE 435031034R1 R3204 C-CARBON R RN72K1J-103JE 435031034R1 R3205 C-CARBON R RN72K1J-103JE 435031034R1 R3208 C-CARBON R RN72K1J-271JE 435032714R1 R3212 C-CARBON R RN72K1J-220JE 435032204R1 R3215...
  • Page 190 119/135 PAGE R3247 C-CARBON R RN72K1J-121JE 435031214R1 R3248 C-CARBON R RN72K1J-220JE 435032204R1 R3249 C-CARBON R RN72K1J-470JE 435034704R1 R3250 C-CARBON R RN72K1J-470JE 435034704R1 R3251 C-CARBON R RN72K1J-470JE 435034704R1 R3253 C-CARBON R RN72K1J-470JE 435034704R1 R3254 C-CARBON R RN72K1J-470JE 435034704R1 R3255 C-CARBON R RN72K1J-103JE 435031034R1 R3256...
  • Page 191 120/135 PAGE R3287 C-CARBON R RN72K1J-220JE 435032204R1 R3288 C-CARBON R RN72K1J-223JE 435032234R1 R3289 C-CARBON R RN72K1J-472JE 435034724R1 R3290 C-CARBON R RN72K1J-221JE 435032214R1 R3291 C-CARBON R RN72K1J-105JE 435031054R1 R3293 C-CARBON R RN72K1J-560JE 435035604R1 R3294 C-CARBON R RN72K1J-561FE 435035612R1 R3295 C-CARBON R RN72K1J-560JE 435035604R1 R3296...
  • Page 192 121/135 PAGE R3408 C-CARBON R RN72K1J-331JE 435033314R1 R3409 C-CARBON R RN72K1J-331JE 435033314R1 R3412 C-CARBON R RN72K1J-472JE 435034724R1 R3414 C-CARBON R RN72K1J-103JE 435031034R1 R3415 C-CARBON R RN72K1J-331JE 435033314R1 R3416 C-CARBON R RN72K1J-331JE 435033314R1 R3417 C-CARBON R RN72K1J-331JE 435033314R1 R3418 C-CARBON R RN72K1J-331JE 435033314R1 R3419...
  • Page 193 122/135 PAGE R3455 C-CARBON R RN72K1J-121JE 435031214R1 R3456 C-CARBON R RN72K1J-470JE 435034704R1 R3457 C-CARBON R RN72K1J-470JE 435034704R1 R3458 C-CARBON R RN72K1J-470JE 435034704R1 R3459 C-CARBON R RN72K1J-470JE 435034704R1 R3460 C-CARBON R RN72K1J-470JE 435034704R1 R3461 C-CARBON R RN72K1J-470JE 435034704R1 R3462 C-CARBON R RN72K1J-102JE 435031024R1 R3464...
  • Page 194 123/135 PAGE R3502 C-CARBON R RN72K1J-470JE 435034704R1 R3503 C-CARBON R RN72K1J-470JE 435034704R1 R3504 C-CARBON R RN72K1J-470JE 435034704R1 R3505 C-CARBON R RN72K1J-470JE 435034704R1 R3506 C-CARBON R RN72K1J-470JE 435034704R1 R3508 C-CARBON R RN72K1J-470JE 435034704R1 R3510 C-CARBON R RN72K1J-470JE 435034704R1 R3512 C-CARBON R RN72K1J-470JE 435034704R1 R3513...
  • Page 195 124/135 PAGE R8034 C-CARBON R RN72K1J-471JE 435034714R1 R8035 C-CARBON R RN72K1J-680JE 435036804R1 R8038 C-CARBON R RN72K1J-220JE 435032204R1 R8039 C-CARBON R RN72K1J-220JE 435032204R1 R8042 C-CARBON R RN72K1J-750JE 435037504R1 R8043 C-CARBON R RN72K1J-750JE 435037504R1 R8044 C-CARBON R RN72K1J-471JE 435034714R1 R8045 C-CARBON R RN72K1J-680JE 435036804R1 R8046...
  • Page 196 125/135 PAGE R8080 C-CARBON R RN72K1J-750JE 435037504R1 R8160 C-CARBON R RN72K1J-472JE 435034724R1 R8161 C-CARBON R RN72K1J-104JE 435031044R1 R8162 C-CARBON R RN72K1J-104JE 435031044R1 R8163 C-CARBON R RN72K1J-104JE 435031044R1 R8164 C-CARBON R RN72K1J-104JE 435031044R1 R8165 C-CARBON R RN72K1J-104JE 435031044R1 R8166 C-CARBON R RN72K1J-000JE 435030004R1 R8204...
  • Page 197 126/135 PAGE R8231 C-CARBON R RN72K1J-103JE 435031034R1 R8232 C-CARBON R RN72K1J-103JE 435031034R1 R8233 C-CARBON R RN72K1J-102JE 435031024R1 R8234 C-CARBON R RN72K1J-103JE 435031034R1 R8236 C-CARBON R RN72K1J-103JE 435031034R1 R8245 C-CARBON R RN72K1J-222JE 435032224R1 R8246 C-CARBON R RN72K1J-222JE 435032224R1 R8251 C-CARBON R RN72K1J-221JE 435032214R1 R8252...
  • Page 198 127/135 PAGE R8277 C-CARBON R RN72K1J-220JE 435032204R1 R8281 C-R NET RM7LJ220X04 43484722004R2 R8282 C-R NET RM7LJ220X04 43484722004R2 R8283 C-CARBON R RN72K1J-220JE 435032204R1 R8284 C-R NET RM7LJ220X04 43484722004R2 R8285 C-CARBON R RN72K1J-220JE 435032204R1 R8286 C-CARBON R RN72K1J-220JE 435032204R1 R8287 C-R NET RM7LJ220X04 43484722004R2 R8288...
  • Page 199 128/135 PAGE R8418 C-R NET RM7LJ220X04 43484722004R2 R8419 C-R NET RM7LJ220X04 43484722004R2 R8420 C-R NET RM7LJ220X04 43484722004R2 R8421 C-R NET RM7LJ220X04 43484722004R2 R8422 C-R NET RM7LJ220X04 43484722004R2 R8423 C-R NET RM7LJ220X04 43484722004R2 R8424 C-R NET RM7LJ220X04 43484722004R2 R8425 C-CARBON R RN72K1J-220JE 435032204R1 R8426...
  • Page 200 129/135 PAGE R8516 C-CARBON R RN72K1J-101JE 435031014R1 R8517 C-CARBON R RN72K1J-101JE 435031014R1 R8518 C-CARBON R RN72K1J-472JE 435034724R1 R8519 C-CARBON R RN72K1J-220JE 435032204R1 R8520 C-CARBON R RN72K1J-330JE 435033304R1 R8521 C-CARBON R RN72K1J-330JE 435033304R1 R8522 C-R NET RM7LJ330X04 43484733004R2 R8523 C-CARBON R RN72K1J-330JE 435033304R1 R8524...
  • Page 201 130/135 PAGE R8642 C-CARBON R RN72K1J-000JE 435030004R1 R8643 C-CARBON R RN72K1J-472JE 435034724R1 R8644 C-CARBON R RN72K1J-472JE 435034724R1 R8647 C-CARBON R RN72K1J-473JE 435034734R1 R8648 C-CARBON R RN72K1J-473JE 435034734R1 R8649 C-CARBON R RN72K1J-000JE 435030004R1 R8650 C-CARBON R RN72K1J-000JE 435030004R1 R8657 C-CARBON R RN72K1J-473JE 435034734R1 R8658...
  • Page 202 131/135 PAGE R8730 C-CARBON R RN72K1J-222JE 435032224R1 R8731 C-CARBON R RN72K1J-222JE 435032224R1 R8733 C-CARBON R RN72K1J-103JE 435031034R1 R8738 C-CARBON R RN72K1J-103JE 435031034R1 R8742 C-CARBON R RN72K1J-103JE 435031034R1 R8743 C-CARBON R RN72K1J-103JE 435031034R1 R8746 C-CARBON R RN72K1J-103JE 435031034R1 R8747 C-CARBON R RN72K1J-103JE 435031034R1 R8749...
  • Page 203 132/135 PAGE R8937 C-CARBON R RN72K1J-473JE 435034734R1 R8941 C-CARBON R RN72K1J-683JE 435036834R1 R8942 C-CARBON R RN72K1J-472JE 435034724R1 R8943 C-CARBON R RN72K1J-103JE 435031034R1 R8951 C-CARBON R RN72K1J-103JE 435031034R1 R8952 C-CARBON R RN72K1J-682JE 435036824R1 R8954 C-CARBON R RN72K1J-822JE 435038224R1 R8955 C-CARBON R RN72K1J-563FE 435035632R1 R8956...
  • Page 204 133/135 PAGE JL2100B SOCKET NSCT-5P97 25050269 JL4518B WIRE TRAP NPLG-5P588 25055626 P2101B SOCKET NSCT-19P2112 25052215 P3001 SOCKET(B to B) IMSA-9850S-20Y900 25052813R2 P3101A PLUG NPLG-5P918 25055965R2 P3102A SOCKET NSCT-9P2472 25052575R2 P3104 SOCKET EJFR0002 25056668 P3104 or SOCKET SI-60073-F ( 1) 25053307 P3401 SOCKET(B to B) IMSA-9850S-16Y900...
  • Page 205 134/135 PAGE P8702 SOCKET NSCT-9P2472 25052575R2 HT-RC270 PC BOARD PARTS LIST U008 FRONT HDMI TERMINAL PC BOARD AS BAHDM-0290-1A 1B234590-1A REMARKS CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) [SEMI CONDUCTOR] D8661 C-DIODE KDS4148U 223283R2 D8661 or C-DIODE 1SS352 ( 1) 223234R2 D8662...
  • Page 206 135/135 PAGE R8668 C-CARBON R RN72K1J-473JE 435034734R1 R8669 C-CARBON R RN72K1J-000JE 435030004R1 R8670 C-CARBON R RN72K1J-000JE 435030004R1 R8672 C-CARBON R RN72K1J-103JE 435031034R1 R8673 C-CARBON R RN72K1J-472JE 435034724R1 R8674 C-CARBON R RN72K1J-103JE 435031034R1 R8675 C-CARBON R RN72K1J-103JE 435031034R1 R8676 C-CARBON R RN72K1J-103JE 435031034R1 R8680...
  • Page 207 Service Dept. Technical Support : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-229-1687, 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...

Table of Contents
