Technical Specifications
Model
System Information
CPU
Flash
RAM
Camera Features
Image Sensor
Maximum Resolution
Lens Type
Focal Length
Aperture
Auto-iris
Field of View
Shutter Time
WDR Technology
Day/Night
Minimum Illumination
Pan/tilt/zoom Functionalities
IR Illuminators
On-board Storage
Video
Compression
Maximum Frame Rate
Maximum Streams
S/N Ratio
Dynamic Range
Video Streaming
Image Settings
Audio
Audio Capability
Compression
Interface
Network
Users
Protocols
Interface
ONVIF
Intelligent Video
Video Motion Detection
VCA*
* Available per project request
Compatible Accessories
Mounting Kits
AM-714
Junction Box
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
IB8382-T: Vari-focal, P-iris, Remote Focus
IB8382-ET: Vari-focal, P-iris, Remote Focus, Extreme
Weather
IB8382-F3: Fixed-focal
IB8382-EF3: Fixed-focal, Extreme Weather
Multimedia SoC (System-on-Chip)
1Gb
4Gb
1/3.2" Progressive CMOS
2560x1920 (5MP)
Vari-focal, Remote Focus (IB8382-T/-ET)
Fixed-focal (IB8382-F3/-EF3)
IB8382-T/IB8382-ET: f = 3 ~ 9 mm
IB8382-F3/IB8382-EF3: f = 3.6 mm
IB8382-T/IB8382-ET: F1.2 ~ F2.3
IB8382-F3/IB8382-EF3: F2.1
P-iris (IB8382-T/IB8382-ET)
IB8382-T/IB8382-ET:
35° ~ 78° (Horizontal)
27° ~ 54° (Vertical)
44° ~ 100° (Diagonal)
IB8382-F3/IB8382-EF3:
92° (Horizontal)
76° (Vertical)
105° (Diagonal)
1/5 sec. to 1/32,000 sec.
WDR Enhanced
Removable IR-cut filter for day & night function
IB8382-T/IB8382-ET:
0.04 Lux @ F1.2 (Color)
0.001 Lux @ F1.2 (B/W)
IB8382-F3/IB8382-EF3:
0.089 Lux @ F2.1 (Color)
0.001 Lux @ F2.1 (B/W)
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built in)
Built-in IR illuminators, effective up to 30 meters
with Smart IR
IR LED*8
Slot type: SD/SDHC/SDXC card slot
Seamless Recording
H.264 & MJPEG
15 fps @ 2560x1920
15 fps @ 2408x1536
30 fps @ 1920x1080
In both compression modes
4 simultaneous streams
Above 65 dB
70 dB
Adjustable resolution, quality and bitrate; Smart Stream
Adjustable image size, quality and bit rate, time stamp,
text overlay, flip & mirror, configurable brightness,
contrast, saturation, sharpness, white balance, exposure
control, gain, backlight compensation, privacy masks,
scheduled profile settings, 3D noise reduction, video
rotation, defog
Two-way Audio (full duplex)
G.711, G.726
External microphone input
Audio output
Live viewing for up to 10 clients
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP,
IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS,
QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
10Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard Cat. 5e & Cat.
6 cables which are compliant with the 3P/ETL standard.
Supported, specification available at www.onvif.org
Five-window video motion detection
Line crossing detection, field detection, loitering
detection
Alarm and Event
Alarm Triggers
Alarm Events
General
Smart Focus System
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Casing
Safety Certifications
Operating Temperature
Warranty
System Requirements
Operating System
Web Browser
Other Players
Included Accessories
CD
Others
Dimensions
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
VIVOTEK USA
VIVOTEK Europe
2050 Ringwood Avenue,
Randstad 22-133, 1316BW Almere,
San Jose, CA 95131
The Netherlands
T: 408-773-8686 F: 408-773-8298
T: +31(0)36-5298-434
E: salesusa@vivotek.com
E: saleseurope@vivotek.com
Video motion detection, manual trigger, digital input,
periodical trigger, system boot, recording notification,
camera tampering detection, audio detection
Event notification using digital output, HTTP, SMTP, FTP
and NAS server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD card
IB8382-T/IB8382-ET: Remote Focus
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
DC 12V power input
Digital input*1
Digital output*1
System power and status indicator
DC 12V
IEEE 802.3at PoE
IB8382-T:
Max. 8 W (DC12V)
Max. 9.5 W (PoE)
IB8382-ET/-EF3:
Max. 21/8 W (DC12V-Heater on/off)
Max. 25/9.5 W (PoE-Heater on/off)
IB8382-F3:
Max. 7.5 W (DC12V)
Max. 9 W (PoE)
Ø 88 x 293 mm
Net: 1264 g
Weather-proof IP66-rated housing
Vandal-proof IK10-rated metal housing (Casing only)
IB8382-T/-ET:
CE, LVD, FCC Class A, VCCI, C-Tick, UL
IB8382-F3/-EF3:
CE, LVD, FCC Class A, VCCI, C-Tick
IB8382-T/-F3:
Starting Temperature: -10°C ~ 50°C (14°F~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F~ 122°F)
IB8382-ET/-EF3:
Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F)
IB8382-T/-ET: 36 months
IB8382-F3/-EF3: 24 months
Microsoft Windows 7/8/Vista/XP/2000
Mozilla Firefox 7~10 (Streaming only)
Internet Explorer 7/8/9/10/11
VLC: 1.1.11 or above
Quicktime: 7 or above
User's manual, quick installation guide, Installation
Wizard 2
Quick installation guide, warranty card, sun shield, wall
mount bracket, waterproof RJ45 Ethernet enclosure,
alignment sticker / desiccant bag, waterproof connector,
screw
293 mm
80 mm
VIVOTEK India
602, Best sky Tower, Plot No. F-5,
Netaji Subhash Place, Pitam Pura, Delhi-110 034
T: +91-11-45137465
E: salesindia@vivotek.com
Ver. 10
